Bruksanvisning Switel S57D Samba Mobiltelefon

Bruksanvisning

19

20a

20b

21

18

CAUTION!

ATTENTION!

WARNING!

Service hotline

In the case of technical problems, contact our Service hotline. Switzerland: Tel.

0900001675(nationalcharges,Swisscomattimeofgoingtoprint:CHF2.60/

min). In the case of claims under the terms of guarantee, contact your sales

outlet.

Maintenance

Cleanthesurfaceofthehousingwithasoft,uff-freecloth.Donotuseany

cleaning agents or solvents.

Guarantee

SWITEL equipment is produced and tested according to the latest production

methods. The implementation of carefully chosen materials and highly deve-

loped technologies ensure trouble-free functioning and a long service life. The

terms of guarantee do not apply when a device malfunction was caused by the

mobile telecommunications network operator/provider. The terms of guarantee

do not apply to the batteries or power packs used in the products. The period of

guarantee is 24 months from the date of purchase.

Alldecienciesrelatedtomaterialormanufacturingerrorswithintheperiodof

guaranteewillberedressedfreeofcharge.Rightstoclaimsunderthetermsof

guarantee are annulled following tampering by the purchaser or third parties.

Damage caused as the result of improper handling or operation, normal wear

and tear, incorrect positioning or storage, improper connection or installation

orActsofGodandotherexternalinuencesareexcludedfromthetermsof

guarantee. In the case of complaints, we reserve the right to repair defective

parts,replacethemorreplacetheentiredevice.Replacedpartsordevicesbe-

comeourproperty.Rightstocompensationinthecaseofdamageareexcluded

where there is no evidence of intent or gross negligence by the manufacturer. If

your device does show signs of a defect within the period of guarantee, please

contact the sales outlet where you purchased the SWITEL device, producing

the purchase receipt as evidence. All claims under the terms of guarantee in

accordance with this agreement can only be asserted at the sales outlet. No

claims under the terms of guarantee can be asserted after a period of two years

from the date of purchase and hand-over of the product.

Disposal

In order to dispose of your device, take it to a collection point provided

by your local public waste authorities (e.g. recycling centre). According to

the laws on the disposal of electronic and electrical devices, owners are

obliged to dispose of old electronic and electrical devices in a separate

waste container. The adjacent symbol indicates that the device must not

be disposed of in normal domestic waste!

You are legally obliged to dispose of power packs and batteries at the

point of sale or in the corresponding containers provided at collection

points by local public waste authorities. Disposal is free of charge. The

symbols indicate that the batteries must not be disposed of in normal

domestic waste and that they must be brought to collection points provi-

ded by local public waste authorities. Packaging materials must be disposed of

according to local regulations.

Declaration of Conformity

ThisdevicefullstherequirementsstipulatedintheDirective1999/5/

EConradioequipmentandtelecommunicationsterminalequipment

andthemutualrecognitionoftheirconformity.Conformitywiththeabo-

vementioneddirectiveisconrmedbytheCEmarkonthedevice.Toviewthe

completeDeclarationofConformity,pleaserefertothefreedownloadavailable

on our web site www.switel.com.

ENGLISH

Multi Touch Smartphone S 57 D SAMBA

Note that you may certain services from your cellphone

need to enable this provider before you can use it.

Operating Instructions

Please read and observe the following information and keep the

operating manual nearby for future reference!

Safety information

 Riskofexplosion!

 Only use the power adapter plugs supplied!

 Only use batteries supplied or ones of the same type!

 Always treat batteries with due care and attention and only use

batteries as described.

 Never use standard and rechargeable batteries together.

 Never use rechargeable batteries or standard batteries with different

capacities or charge statuses together.

 Never use standard or rechargeable batteries which are damaged.

 Riskoffatalinjurywithheartpacemakers!

 Always keep the phone a safety distance of at least 15 cm to heart

pacemakers.

 Riskofsuffocationthroughsmallobjects,packagingandprotectivefoil!

 Keep children away from the product and its packaging!

 Riskstohealthandtheenvironmentfrombatteries!

 Never open, damage or swallow batteries or allow them to pollute the

environment. They could contain toxic and ecologically harmful heavy

metals.

 Riskofhearingdamage!

 Avoid listening at full receiver volume.

 Riskofpropertydamage.

Preventexposuretoenvironmentalinuences,e.g.smoke,dust,

vibration, chemicals, moisture, heat and direct sunlight.

Onlyallowrepairstobecompletedbyqualiedpersonnel.

INTENDED USE

Thismobilephoneisdesignedfortelephoning,surngtheinternetand

sending / receiving SMS texts when connected to a mobile phone network.

Any other use is considered unintended use. Observe all local directi-

vesandregulations.Unauthorisedmodicationorreconstructionisnot

permitted. Under no circumstances open the device or complete any repair

work yourself.

PACKAGE CONTENTS

1 Smartphone, 1 Power adapter plug, 1 Operating instruction

OPERATING ELEMENTS

1 Take a call

2 One step back

 3 Phonebook/Contacts

4 View Apps and Widgets

5 Back to home screen

6 Display / write messages

7 Overview on open applications

8 WEB Browser

9 Speaker

10 Chargingsocket/Datatransmission(MiniUSB)

11 Flashlight

12 Cameralens

13 Display on/off, Press and hold 3 sec. to switch phone on/off

14 Cameralens

15 Earpiece

16 Headphone Jack

17 Volume control

18 Back cover

19 Micro SD

20 SIM card slot a) Normal b) Micro

21 Battery (Permanently installed)

STARTING UP

Inserting the SIM and microSD card

ATTENTION!

 The SIM / microSD card could be damaged.

 Pay attention that the SIM / microSD card remains clean and undama

ged. Insert the cards the correct way around.

 The battery or phone could be damaged.

Switch the mobile phone off before removing the back cover. Only switch it

on again when the back cover

has been replaced.

Removebackcover,insertSIMandmicroSDcard,replacebackcover

Charging the battery

 Chargethebatteryfor

at least 12 hours when

chargingforthersttimeand

ensure they are subsequently discharged and charged fully. This aids a

longservicelifeofthebattery.Chargethemobilephonedirectlyviathe

mini-USB port.

Technical data (All rights reserved)

MAKE A PHONE CALL

Answering a call

Hold symbol and drag to symbol.

Rejecting a call

Hold symbol and drag to symbol.

Answer a call with text message

Hold symbol and drag to symbol than select and text

message.

HOME SCREEN TIPS

Touch symbol  touch <WIDGETS> select <HOME SCREEN

TIPS>. Hold the symbol and drag it on one of the home screens.

UNLOCK SCREEN

Hold symbol.

SETTING THE LANGUAGE

Touch symbol Touch symbol <Language & input>

[select language] finished

Feature Value

S57DSAMBADual-SIMQuad-bandGSM(850/900/1800/1900MHz),3GWCDMA

2100 / 900, Android OS 4.2.2

W x H x D 72,0 x 144,0 x 7,9 mm

Weight 145,9 g (incl. battery)

Talking time max. 240 min.

Standby 250 h

Battery Li-Ion 1600 mAh

SAR Head: 0,159 W/kg

Mediaplayer MP4/3GP/WMV/H.264/H.263

MP3/WAV/AAC/AAC+/+eAAC+/AMR/MIDI

Camera 8 Megapixel

Display 5.0 inches QHD (540 x 960 pixels)

Memory (intern)

micro SD

4GBFLASH,1GBRAM

max. 32 GB

CPU 1.3GHz Quad-core

Power adaptor plug

Usingtheenergy-efcientpoweradaptormodelS57D(input100-240V

~50-60Hz0,3A,output5V/1Amax.)

17

13

3

1

2

4 8

7

5

6

9 10

111215 1416
