-- GB -- DIRECTIONS FOR USE
Before operating the heater, please read these instructions thoroughly to avoid damage and
hazardous situations. Any use of this heater other than that stipulated in this instruction manual
may cause fire, electric shock or injury, and voids all warranties.
Warranty does not apply to any defect, deterioration, loss, injury or damage caused by, or as a result of, the
misuse or abuse of this heater. The rights dictated by State law are not prejudiced. None of the terms of this
warranty are to be taken as excluding any conditions or warranties implied by State law, which cannot be
excluded or modified.
Before any operation remove the packaging and check product integrity. In case of defects or damages do
not try to repair it yourself but contact your dealer.
Do not let children play with the packaging and protect the environment by disposing of the packaging in
accordance with the national regulations for waste processing.
1. Your product
The product is sold without accessories.
Depending on the version, a bracket for wall mounting may be present on the back of the product. To
fix it to the wall we suggest you use nylon rawplugs and cross head screws included.
Contact your dealer immediately if the product is damaged or the bracket missing.
2. For your own safety
This heater provides an additional source of heating, and must solely be used for this purpose.
Make sure that your supply rating corresponds to what is specified on the rating plate, e.g. 230V AC,
50Hz.
Don't leave your home while the appliance is in operation: always ensure that the switch or the timer
is on the “O” position and the thermostat set to minimum “¿”.
Switch off the product and unplug it if you are not going to use it for long periods;
While in operation, place the heater in a safe position:
- at least 1.0m away from inflammable objects or furniture;
- if wall mounted, not fixed to synthetic or plastic surfaces;
- leaving the air outlets free: 1m free space in front of the heater and 50cm free space behind it;
- never placed immediately under a socket.
Do not let animals or children touch or play with the appliance. Careful! The air outlet grille becomes
very hot during operation (over 80°C/176°F).
WARNING: in order to avoid overheating, never cover the heater. Do not hang anything on the
heater and do not cover it while it’s working. This is clearly written on the product or shown by the
symbol
This product may not be used by people (children included) with reduced physical, sensorial or mental
capacities, or with inadequate experience and knowledge, unless they are under the supervision of a
person responsible for their safety or have been suitably instructed by the latter. Children must be
supervised to ensure they do not play with the product.
Do not use the heater in the presence of explosive gases, solvent or varnish vapors or, in any case,
inflammable vapors/gases.
If the cable is damaged and you have to change it, do not do the job yourself! Take the product to an
authorized repair center as the repair must be carried out by a specialist, in order to avoid any risk of
damage.
Do not use this heater close to showers, baths, water basins or swimming pools.
Do not clean the product while plugged in, and never immerse it in water.
Do not wind the cable around the device when it is in operation, or pull it across sharp edges.
The appliance must be positioned so that the plug is always accessible.
3. Safe positioning
Only ever use the appliance in an upright position;
When portable, always maintain a distance of at least 1m between the product and any inflammable
object/surface.
When the product is wall mounted, make sure that the minimum distances reported in pictures 1 and
2 are respected. Do not place the heater so that the air flow blows directly towards the wall.
As the heater is a class 2 product, earth connection is not required.
The heater has an IPX1 protection level against water and, if wall mounted may be installed in
bathrooms. In any case you have to respect the national installation standard and safety requirements
valid in your State.
Never install/use this appliance in the Zones 0, 1 or 2 illustrated in picture 3:
On no account must any switch / button be accessible by people in the shower or in the bathtub.
4. Wall mounting
After carefully reading section 3, proceed with installation following the sequence shown in picture 4.
To hang on the product proceed as follows:
- Lay the base of the product on the base of the wall bracket coupling the plastic ribs created to
make the lodging easier;
- Push a little bit the product downwards and move the upper side of the product near the bracket;
- Check that the upper holed rib of the bracket fits the dedicated pivot created on the back grid of
the heater. Moderately shake the heater after installation to be sure it is correctly fixed.
To release the product from the bracket proceed as follows:
- Use your hand to push downwards the upper rib of the bracket as much as necessary to release the
product by pulling it on the top.
- Once the product has been unlocked on the upper side just pull it upwards to release it from its base.
1
2
3
4
click!
