Getting started

RQT6627

6

Disc information

∫ Discs that can be played

Use discs with the above logos and that conform to specifications. The unit cannot play other discs correctly. Do not use irregularly shaped discs (e.g.

heart-shaped), as these can damage the unit.

It may not be possible to play CD-R, CD-RW, DVD-R and DVD-RAM in all cases due to the type of disc or condition of the recording.

∫ Discs that cannot be played

DVD-ROM, CD-ROM, CDV, CD-G, iRW, DVD-RW, CVD, SACD, Divx

Video Discs and Photo CD, DVD-RAM that cannot be removed from their

cartridge, 2.6-GB and 5.2-GB DVD-RAM, and “Chaoji VCD” available on

the market including CVD, DVCD and SVCD that do not conform to

IEC62107.

∫ Built-in decoders

You can play discs with these symbols.

∫ Video systems

≥This unit can play PAL and NTSC, but your television must match the

system used on the disc.

≥PAL discs cannot be correctly viewed on an NTSC television.

≥This unit can convert NTSC signals to PAL 60 for viewing on a PAL

television (➜ page 18, Video—NTSC Disc Output).

≥Output is interlace (576I) when playing PAL discs.

∫ Playing DVDs and Video CDs

The producer of these discs can control how they are played so you may

not always be able to control play as described in these operating

instructions (for example if the play time is not displayed or if a Video CD

has menus). Read the disc’s instructions carefully.

∫ DVD-RAM discs

The DVD-RAM you can play on this unit are those recorded with DVD

video recorders, DVD video cameras, personal computers, etc. using

Version 1.1 of the Video Recording Format (a unified video recording

standard).

≥Remove discs from their cartridges before use and return them when

you are finished, making sure that the labels of the disc and cartridge

face the same way.

≥Some parts of the disc, for example where one program ends and

another begins, may not play smoothly.

∫ DVD-R discs

Panasonic DVD-R recorded and finalized on a Panasonic DVD video

recorder or DVD video camera are played as DVD-Video on this unit.

∫ CD-R and CD-RW discs

This unit can play CD-R/RW (audio recording disc) recorded with CD-DA,

video CD, SVCD (conforming to IEC62107), WMA, MP3, or JPEG. Close

the sessions or finalize the disc after recording.

See page 11 for more information about WMA, MP3, and JPEG.

∫ HighMAT discs

This unit is compatible with HighMAT discs containing WMA, MP3, and/or

JPEG files.

∫ Disc structure

Disc structure and the labels given to the items on discs depend on the

disc type.

Track: the smallest division on DVD-Audio, CDs and Video CDs, or a

single WMA/MP3 file.

Chapter: the smallest division on DVD-Video.

Group: collections of tracks on DVD-Audio and equivalent to folders or

albums on data discs.

Title: the largest division on DVD-Video, usually an entire movie.

Program: the division on DVD-RAM equivalent to a single recording.

Picture: a single JPEG file.

Play list: the largest grouping on a HighMAT disc, or a group of scenes

on DVD-RAM.

Scene: DVD-RAM program sections specified and grouped into play

lists on a DVD video recorder.

Content: covers tracks and pictures on HighMAT discs.

∫ To clean discs

DVD-Audio, DVD-Video, Video CD, CD

Wipe with a damp cloth

and then wipe dry.

DVD-RAM, DVD-R

≥Clean with a DVD-RAM/PD disc cleaner (LF-K200DCA1, where

available).

≥Never use cloths or cleaners for CDs etc.

∫ Handling precautions

≥Do not write on the label side with a ball-point pen or other writing

instrument.

≥Do not use record cleaning sprays, benzine, thinner, static electricity

prevention liquids or any other solvent.

≥Do not attach labels or stickers to discs. (Do not use discs with exposed

adhesive from tape or left over peeled-off stickers.)

≥Do not use scratch-proof protectors or covers.

≥Do not use discs printed with label printers available on the market.

DVD-RAM

DVD-Audio

DVD-Video DVD-R

SVCD

Video CD CD CD-R/RW

Shown as

“DVD-VR” on

the display

Conforming to

IEC62107

`

[RAM] [DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3]

[JPEG]

RQT6627

Getting started

7

The remote control

∫ Batteries

≥Insert so the poles (i and j) match those in the remote control.

≥Do not use rechargeable type batteries.

Do not:

≥mix old and new batteries.

≥use different types at the same time.

≥heat or expose to flame.

≥take apart or short circuit.

≥attempt to recharge alkaline or manganese batteries.

≥use batteries if the covering has been peeled off.

Mishandling of batteries can cause electrolyte leakage which can damage

items the fluid contacts and may cause a fire.

Remove if the remote control is not going to be used for a long period of

time. Store in a cool, dark place.

∫ Use

Aim at the sensor (➜ page 3, Control reference guide), avoiding

obstacles, at a maximum range of 7 m directly in front of the unit.

The QUICK SETUP screen appears when you press [SETUP] the first

time after purchase and assists you to make necessary settings.

Preparation

Turn on the television and select the appropriate video input on the

television to suit the connections for the player.

[1] Press [Í] to turn on the unit.

[2] Press [SETUP] to

show the QUICK

SETUP screen.

e.g. Units for the United

Kingdom

[3] Press [3, 4, 2, 1] to

select the menu

language and press [ENTER].

[4] Press [3, 4] to select “Yes” to continue and

press [ENTER].

[5] Press [3, 4, 2, 1] to select the item and press

[ENTER].

≥Audio language (➜ page 18)

≥Subtitle language (➜ page 18)

≥TV Type (➜ page 18)

≥TV Aspect (➜ below)

≥Video Out (AV/Component)

§

(➜ page 18)

≥Progressive Out (Component) (➜ below)

Only displayed when setting “Video Out (AV/Component)” to “Y PB

PR”.

§

≥Speaker Setting (➜ page 18)

≥PCM Digital Output (➜ page 19)

§

Applies only to the United Kingdom and Continental Europe.

[6] Press [ENTER] and then [SETUP] to end the

settings.

To return to the previous screen

Press [RETURN].

To access this screen again later

➜ page 18, Others—QUICK SETUP

∫ TV Aspect

Select “4:3” (regular) or “16:9” (widescreen) to suit your television.

If you have a regular 4:3 television, you can also select how video on

some discs is shown (➜ page 18, Video—TV Aspect).

≥4:3 Pan&Scan (Factory preset)

Widescreen software is expanded to fill the screen

of a 4:3 aspect television (unless prohibited by the

producer of the disc).

≥4:3 Letterbox

Widescreen software is shown in the letterbox style

on a 4:3 aspect television.

∫ To enjoy progressive video

1. Connect to the component video input terminals on a 480P

compatible television. (Video will not be displayed correctly if

connected to an incompatible television.)

2. In QUICK SETUP, set “Video Out (AV/Component)” to “Y PB PR”, and

set “Progressive Out (Component)” to “Enable (NTSC Disc Only)”.

3. When playing NTSC discs, change video output mode to “480P” (➜

page 17).

≥All televisions manufactured by Panasonic and that have 480P input

connectors are compatible. Consult the manufacturer if you have

another brand of television.

≥If the unit is connected to the television through VIDEO OUT, S VIDEO

OUT or SCART (AV), output will be interlace, irrespective of the settings.

R6, AA, UM-3

Quick setup

[1]

Í

OPEN/CLOSE

DOUBLE RE-MASTER DEPTH ENHANCER

Í

/ I

Í

SLEEP

A.SRD

AUDIO ONLY

DEPTH ENH

GROUP

DIRECT NAVIGATOR

TOP

MENU

DISPLAY

SUBTITLE AUDIO

ANGLE/PAGE QUICK REPLAY

RETURN

MENU

PLAY LIST

SKIP

STOP

PLAY

SLOW/SEARCH

CANCEL

SETUP

OPEN/CLOSE

321

98

S

10

0

7

654

PAU SE

ENTER

RETURN

[2]0[6]

[3]`[6]

[1]

SELECT

SETUP

QUICK SETUP

Select the menu language.

ENTER RETURN

English

Deutsch

Español

Svenska

Français

Italiano

Português

Nederlands
