Thank you for purchasing your new product.

We recommend that you spend some time reading this instruction manual in order that

you fully understand all the operational features it oers.

Read all the safety instructions carefully before use and keep this instruction manual for

future reference.

2KW Convector Heater

Instruction Manual

L20CHW25

• This product is only suitable for well-insulated spaces or occasional use.

• Before using this appliance, read all safety instructions carefully rst in the Safety

Warnings booklet and keep them for future reference.

Product Overview

Control Panel

Unpacking

Remove all items from the packaging. Retain the packaging. If you dispose of it please do so

according to local regulations.

The following items are included:

• Main Unit

• Foot × 2

• Instruction Manual and Safety Warnings

Assembly

Before using the heater, the feet (supplied) must be tted to the unit.

1. Release the screw from the unit.

• If items are missing or damaged, please contact Partmaster (UK only).

• Tel: 0344 800 3456 for assistance.

Operation

Position the heater upright on the oor away from curtains, furniture or wall coverings before

plugging your heater into the mains socket.

• Turn the Power Switch from “0” to the “I”, “ II” or “III” position to switch on the unit.

• Turn the Thermostat Control clockwise until you hear the “poop“ sound to switch on the

unit. Turn the Thermostat Control to “MAX” position for maximum output.

• Turn the Power Switch to “0“ position and the Thermostat Control to “MIN“ position.

• It is normal for the heater to emit some smell and fumes when it is turned on for

the rst time or when turned on after not being used for a long period of time. This

smell will disappear when the heater has been turned on for a short while.

• This unit will not operate unless positioned on a at stable surface or if the

thermostat is set too low.

• The heater will not operate by turning the Thermostat Control when the thermostat

setting is too low.

Cleaning

Your heater should be cleaned regularly to prevent dirt and dust from building up which will

aect its performance. Ensure the air inlet and the air outlet are not blocked.

This can be done with a vacuum cleaner, using the brush attachment.

Hints & Tips

My heater does not work when I turn it on

• Check that your heater is plugged in and the power is turned on at the mains socket.

• Check that your heater is in an upright position.

• Check if the thermostat setting is too low.

• If the heater still doesn’t work, do not try to repair the heater yourself.

If your heater’s power is automatically cut o follow the steps

below:

1. Unplug your heater and allow it to cool down.

2. Inspect your heater. Clean the air inlet and the air outlet with a vacuum cleaner if necessary.

If there is any sign of physical damage (e.g. melting, or burning of the case), do not attempt

to use your heater. Please leave all maintenance work to qualied personnel.

3. Plug-in the heater and switch it on again. If it cuts o again, move the heater to a better

ventilated location.

Overheat Protection

The power to the heater will automatically cut o if the temperature of the heater exceeds a

certain limit. In the event of overheating, the heater will stop operating. Switch the heater o

and allow it to completely cool. The heater will then resume operating as normal.

• Ensure you unplug your heater from the mains socket and wait for the heater to

cool down completely before cleaning.

• Do not use any detergents or abrasives and do not allow any water to enter the

heater.

1. Handle

2. Power Switch (0/I/II/III)

3. Thermostat Control

1

2

3

2. Install the feet into the unit with the removed screws. Make sure that the screws and feet are

rmly secured.
