6

However, if the appliance is working in unfavourable

room conditions such as

- poor ventilation,

- high temperature,

- frequent door openings,

it may be necessary to select a more suitable

setting.

In determining the correct temperature control

setting all these factors have to be considered and

some experimentation may be necessary.

When altering the temperature setting, allow 24

hours for the temperature to stablise before making

further changes

To obtain a lower temperature, turn the thermostat

control towards max; to obtain a higher temperature

turn the control towards min. For easier turning of this

control, use a small coin.

Freezing fresh food

In any 24 hour period you can freeze up to 14 kg of

fresh food.

When you first start the freezer or after a period of

non-use, press the fast freeze switch 12 hours

before you want to freeze your food (the yellow light

(C) illuminates).

If the freezer is already in operation, the fast-freeze

switch should be pressed about 2-3 hours before

freezing fresh food.

This time can be shortened, depending on the

quantity of food to be frozen. After the time has

elapsed place the food to be frozen in the upper

compartment of the freezer as these are the coldest

parts.

In order to freeze the quantity indicated on the rating

plate, arrange the food directly in contact with the

cooling surfaces. If the food is frozen in the baskets,

the maximum quantity that can be frozen is slightly

less.

Once the food is completely frozen (which could take

up to 24 hours) press again the fast freeze switch;

the yellow light (C) goes out.

Distribute the frozen food packages in the other

compartments, so that the top compartments can be

used for a further freezing operation.

- The food to be frozen must be fresh and of the

best quality.

- Do not allow fresh food to touch food which is

already frozen.

- During the freezing process, ensure that the

freezer door remains closed.

Frozen food storage

When you first start the freezer or if the freezer has

been out of use for some time, we advise you to run

your appliance for at least 12 hours in the «fast

freeze» mode before storing frozen food.

To obtain the best performance from this appliance,

you should:

If large quantities of food are to be stored, remove all

drawers and baskets from appliance and place food

on the cooling shelves.

Pay careful attention not to exceed load limit stated

on the side of the upper section (where

applicable).

Do not exceed the storage period indicated by the

manufacturer.

Finally, do not open the door frequently or leave it

open longer than is absolutely necessary.

Important

Do not put carbonated liquids, (fizzy drinks etc.), in

the freezer compartment.

Ice Iollies, if consumed immediately after removal

from the freezer, can possibly result in a low

temperature skin burn.

Do not remove items from the freezer if your hands

are damp/wet, as this could cause skin abrasions or

“frost/freezer burns”.

Important

In the event of a power cut do not open the door.

The food in the freezer will not be affected if the

power cut is short and if the freezer is full. Should

the food begin to thaw, it must be consumed quickly

and must not be re-frozen.

15

TECHNICAL SPECIFICATIONS

DIMENSIONS

Height 200 cm

Width 60 cm

Depth 60 cm

POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz

TOTAL POWER ABSORBED 200 W

AVERAGE DAILY UNITS ELECTRICITY * 0.959 kWh

GROSS CAPACITY Fridge 184 l

Cellar zone 88 l

Freezer 88 l

NET CAPACITY Fridge 180 l

Cellar zone 80 l

Freezer 82 l

STAR RATING

* This figure is based on standard test results in accordance with European Standard EN 153.

Actual consumption will depend on how the appliance is used and where it is located.
