OPERATION

Before use

Remove all securing tapes. Wash inside the

appliance with lukewarm water and bicarbonate of

soda (5 ml to 0.5 litre of water).

Do not use soap or detergent as the smell may

linger. Dry thoroughly.

Control panel

minmax

A

B

CD

E

ONSUPERALARM

minmax

ON

FG

A - Alarm light - Red

B - Fast freeze switch

C - Fast freeze light - Amber

D - Freezer Pilot light - Green

E - Freezer Thermostat control knob

F - Fridge Pilot light - Green

G - Fridge Thermostat control knob

Control Panel

A. Alarm light

If the alarm light (A) illuminates, it indicates that the

temperature within the freezer has reached a level

where safe food storage is no longer ensured.

When the freezer is first switched on, the alarm light

will stay on until the temperature has dropped to a

safe level for the storage of frozen food.

B. Fast freeze control switch

When you place fresh food in the appliance, press the

fast freeze control switch.

C. Fast freeze light

The fast freeze light is illuminated, to show that the

fast freeze function is working.

D. Freezer pilot light

The pilot light is illuminated to show that the freezer

section is on.

E. Freezer thermostat control knob

Turn the thermostat control knob clockwise to

required setting.

F. Refrigerator pilot light

The pilot light is illuminated to show that the

refrigerator section is on.

G. Refrigerator thermostat control knob

Turn the thermostat control knob clockwise to

required setting.

Start your appliance

Allow the appliance to stand for 2 hours after

installation.

Insert the plug into the wall socket. The pilot light (D)

will illuminate to show that the appliance is on.

Turn the thermostat control (G) to a midway setting.

The pilot light (F) will illuminate. Leave the appliance

for approximately 4 hours for the correct temperature

to be reached before placing food inside.

To switch either section off the appliance turn the

thermostat control to position “■” .

Temperature control

The temperature within the freezer is controlled by

the thermostat control (E) situated at the top of the

cabinet.

To operate the freezer proceed as follows:

Turn the thermostat control knob beyond the «

■»

position.

When you first start the freezer, we suggest that you

turn the thermostat control to a medium setting. For

easier turning of this control, use a small coin.The

internal temperature of the freezer is automatically

adjusted by the thermostat to ensure safe food

storage.

16

INSTALLATION

Positioning

This appliance should only be installed at a location

where the ambient temperature corresponds to the

climate classification indicated on the rating plate,

which is located at the left on the inside of the

appliance.

The following table shows which ambient

temperature is correct for each climate classification:

SN +10°C to + 32°C

N +16°C to + 32°C

ST +18°C to + 38°C

T +18°C to + 43°C

It should be located in a dry atmosphere, out of

direct sunlight and away from extreme temperature

e.g. not next to a boiler or radiator, or in a very cold

room e.g. an outhouse, where the temperatures may

fall below 10°C (50°F). If these temperatures are

exceeded i.e. colder or warmer, then the appliance

may not operate correctly.

You should also ensure that air can circulate freely

around the back and the top of the cabinet. There

must also be at least 100 mm (4”) distance between

the top of the cabinet and any overhanging kitchen

furniture (A). Ideally, the appliance should not be

positioned beneath overhanging furniture (B).

There should also be a gap of 25 mm either side of

the appliance. Do not obstruct the space

underneath. The back of the cabinet may be placed

close to the wall but must not touch it. DO NOT

install in places with restricted ventilation.

Adjust the level of the appliance by screwing out the

adjustable foot, or feet, at the bottom of the cabinet

using your fingers.

D200

Important

IF YOU ARE DISCARDING AN OLD APPLIANCE

THAT HAS A LOCK OR CATCH ON THE DOOR,

YOU MUST ENSURE THAT IT IS MADE

UNUSABLE TO PREVENT YOUNG CHILDREN

BEING TRAPPED INSIDE.

Rear spacers

In the bag with the documentation, there are two

spacers which must be fitted as shown in the figure.

Slacken the screws and insert the spacer under the

screw head, then re-tighten the screws.

Important

It must be possible to disconnect the appliance from

the mains power supply; the plug must therefore be

easily accessible after installation.

Depending upon the position which you choose for

your appliance, you may wish to reverse the way in

which the door opens. To do this, refer to instructions

on “Door reversal”.

NP008

100 mm15 mm

15 mm

A

B

D594
