The Home Office states (in FB2):

“If your home has more than one floor , at least one alarm should

be fitted on each level. In this case a combination of Optical and

Ionisation alarms, preferably interconnected, will give the best

protection.”

FIVE YEAR PRODUCT GUARANTEE

Ei Electronics guarantees this Smoke Alarm for five years from date

of purchase against any defects that are due to faulty materials or

workmanship. This guarantee only applies to normal conditions of

use and service, and does not include damage resulting from acci

-

dent, neglect, misuse, unauthorised dismantling, or contamination

howsoever caused. This guarantee excludes incidental and conse

-

quential damage. If this Alarm should become defective within the

guarantee period, it must be returned to the EiCo, with proof of pur

-

chase, carefully packaged, with the problem clearly stated (see sec

-

tion Getting Your Smoke Alarm Serviced - in the “User Instructions”

leaflet). We shall at our discretion repair or replace the faulty unit.

Do not interfere with the Smoke Alarm or attempt to tamper with it.

This will invalidate the guarantee, but more importantly may expose

the user to shock or fire hazards.

This guarantee is in addition to your statutory rights as a consumer.

Aico Ltd., Mile End Business Park,

Maesbury Rd, Oswestry, Shropshire SY10 8NN, U.K.

Telephone : 0870 758 4000.

Website : www.aico.co.uk

Ei Electronics. Shannon, Co.Clare, Ireland.

Website : www.eielectronics.com

TROUBLESHOOTING

ALARM SOUNDS FOR NO APPARENT REASON:

(1) Identify the alarm source. On all interconnected units, the red

light under the test button or on the cover will flash rapidily only

on the unit which is the source of the alarm.

(2) Check for fumes, steam etc. from the kitchen or bathroom.

Paint and other fumes can cause nuisance alarms.

(3) Press the hush button on the Ei151TL & Ei150. On the

Ei151TLH & Ei155H press the combined test/hush button.

(4) If alarm does not stop, switch off mains and remove unit (see

figure 1).

(only remove alarm with red light flashing, the others are prob

-

ably satisfactory).

ALARMS BEEPS CONTINUOUSLY:

(1) Alarms may be in ‘hush mode’. Press the test button for 10 sec

-

onds to reset the unit (

Ei151TL or Ei150 only).

(2) Cells may be flat due to mains failure (Ei151TL, 154TL,

156TLH only). Check the green mains light is on. If not, check

fuse, circuit breakers and wiring connections.

(3) If the above fails to turn on the green light, a fault may exist.

Switch off mains and remove the unit (see figure 1). Or press

the hush button on the Ei151TL / 150 or press the combined

test/hush button on the Ei156TLH / 155H

(4) If the green mains light is on and the action in (1 ) above has not

silenced the beeping, a fault may exist. Remove the unit (see

figure 1).

INTERCONNECTED ALARM DO NOT ALL SOUND:

(1) Hold test button for 10 seconds after first alarm has sounded to

ensure signal is transmitted to all units.

(2) Switch off mains and check that live, neutral and interconnect

cables have been correctly connected and that the connec

-

tions are tight.

FREQUENT NUISANCE ALARMS OCCUR:

(1) Close kitchen / bathroom door when in use.

(2) Ensure that the alarm is sited at least 6m away from sources of

fumes.

(3) Contamination from insects, paint or paint fumes may have oc

-

curred. Clean the alarm - see “User Instructions” leaflet.

(4) If the problem persists, resiting of the unit should be consid

-

ered. Alternatively, replace the unit with an Optical unit, as

-

suming that the problem is with an Ionisation type alarm.

14

PAGE 14,15 & 1

B12931

REV-2

IDEALLY INSTALL IN THE CENTRE OF CEILING AT LEAST

300mm (12”) FROM LIGHT FITTINGS. KEEP IONISATION

ALARMS AWAY FROM KITCHENS TO PREVENT NUISANCE

ALARMS. INTERCONNECT ALL ALARMS.

ENSURE LIVE MAINS IS CORRECTLY CONNECTED TO

BROWN SMOKE ALARM WIRE ON THE INTERCONNECTED

ALARMS. OTHERWISE UNITS WILL BE DAMAGED.

DO NOT FIT ACTUAL ALARM UNTIL ALL BUILDING WORK IS

COMPLETED TO AVOID CONTAMINATION. AFTER

CHECKING OPERATION, COVER SMOKE ALARM WITH

DUST COVER UNTIL REQUIRED FOR USE.

DO NOT MEGGER THE ALARM. DISCONNECT THE ALARM

BEFORE APPLYING HIGH VOLTAGE TO HOUSE WIRING.

CHECK OPERATION OF ALARM

GREEN MAINS LIGHT IS ON.

TEST BUTTON OPERATES ON ALL ALARMS.

4

8

4

4

8

4

230V AC SMOKE & HEAT ALARMS

RECHARGEABLE LITHIUM CELL BACKUP

HUSH

TEST

IONISATION

WITH HUSH

MODELS Ei151TL

& Ei150 (WITHOUT

BACKUP CELLS)

SITING & INSTALLATION

INSTRUCTIONS

READ THIS FIRST

OPTICAL

WITH HUSH

MODELS Ei156TLH

&

Ei155H (WITHOUT

BACKUP CELLS)

HEAT

MODELS

Ei154TL

LEAVE WITH USER

CONT.

15
