Bruksanvisning Clas Ohlson AX300 Kopplingsur

Bruksanvisning

English

GREAT BRITAIN • customer service

tel: 08545 300 9799 e-mail: [email protected] internet: www.clasohlson.com/uk

Ver. 20131209

Choose PROG CD using

the left arrow [ ← ].

Push [ SET ].

Choose ON or OFF using the

arrows [ ← → ].

Choose thedesired programme using thearrows [ ← → ].

To deactivate all programmes

1

2

3

4

1

2

3

4

• The ON countdown starts when you push [ CD ].

ON during the countdown and thereafter OFF.

• The OFF countdown starts when you push [ CD ].

OFF during the countdown and thereafter ON.

64

2

8

10

3

5 7 9

1

2

3

4

5

6

7

8

9

10

Short random: choose CLOCK.

Long random: choose CD.

Push [ RANDOM ].

“RND” flashes for short random.

“L-RND” flashes for long random.

Programmable random function

1

2

3

1

2

3

4

Setting the countdown timer

1

2

3

4

3

2

4

1

1

2

3

PROG

CD

Note: If you want thetime switch to switch on one day and switch

off another day, you need to use 2 programmes. In this example

theswitch will switch on at 20.00 hrs Monday and switch off at

06.00 hrs Tuesday. If you want to programme theswitch to switch

on at 20.00 hrs on Monday you can e.g. use PROG 1 ON and set

thetime and date. Then advance to PROG 2 OFF without setting

any times for 1 OFF and 2 ON. In programme 2 OFF setup mode

you should enter Tuesday 06.00.

To deactivate aprogramme

Push [ SET ].

Push [ ON/OFF ] to deactivate

theprogramme. A cross

shows that theprogramme

is deactivated.

Push [ SET ] 3 times to exit

thecancel mode.

Advance to CLOCK using thearrows [ ← → ].

Push [ SET ].

Push [ ON/OFF ] to deactivate all theprogrammes.

A cross indicates that theprogrammes are deactivated.

Push [ SET ] 4 times to exit thecancel mode (cancel all).

Repeat steps 1–4 if you change your mind and don’t

want to cancel theprogrammes.

Countdown Timer

This countdown timer starts in either theON or OFF mode

and counts down when activated. In theON mode thetimer

switch emits 230 V. In theOFF mode thetimer switch does not

emit any voltage.

Push [ SET ].

Set the hour using the arrows [ ← → ].

Push [ SET ].

Set the minutes using the arrows [ ← → ].

Push [ SET ].

Set the seconds using the arrows [ ← → ].

Push [ SET ].

Stop the countdown by pushing [ CD ] or [ ON/OFF ].

Random function

Short random: Operates for 1–2 hours at a time.

Long random: Operates for 2–3 hours at a time.

Programmable random: Operates for 1–2 hours at a time.

Choose programme 20 using thearrows [ ← → ].

Push [ RANDOM ].

Set thetime within which you

wish therandom function to

operate.

“RND” is shown on thedisplay.

• The programmable random function is only possible on

programme 20.

• Turn the random function off using [ RANDOM ] or [ ON/OFF ].

Manual ON/OFF

Push [ ON/OFF ].

Troubleshooting

Problem Solution

The LCD display has frozen

and the buttons don’t

respond when you

push them.

Push [ RESET ] to reset the timer.

The timer switch’s settings

are lost when it is not

connected to the mains.

Change the batteries.

The timer switch does not

perform the programmed

ON/OFF operations.

Make sure that the programmes

are not deactivated.

Activate the programmes.

The timer switch does not

perform the programmed

ON/OFF operations at

certain times.

Make sure that the random

function is not activated. Make

sure that no other programmes

or countdown functions are

activated at the same time.

Technical Specification

Programmes 20

Rated voltage 230 V AC, 16 A

Max Load 3680 W Resistive load

Shortest operating time 1 minute
