Bruksanvisning Clas Ohlson AX300 Kopplingsur

Bruksanvisning

English

GREAT BRITAIN • customer service

tel: 08545 300 9799 e-mail: [email protected] internet: www.clasohlson.com/uk

Ver. 20131209

Timer Switch

Art.no 32-8618 Model AX300

Please read theentire instruction manual before use and save

it for future reference. We reserve theright for any errors in text

or images and for making any necessary technical changes to

this document. If you should have any questions concerning

technical problems please contact our Customer Services.

Description

• Ideal for extra security, energy saving and convenience.

• Programmable for 20 ON/OFF settings.

• Timer with countdown.

• 3 RANDOM functions.

• 12/24 hour clock.

• Max. load 16 A, 3680 W.

• The time switch is only intended for indoor use in dry areas.

AX300 Timer Switch

Batteries

Remove thebattery cover on

theback. (Pry open carefully at

thedepressions).

Insert thetwo button cell batteries

LR44, supplied, between thecontacts

according to themarkings.

1

1

2

2

3

Setting theclock

1

2

3

4

5

6

7

8

9

10

Go to Clock, using thearrows [ ← → ].

Push [ SET ].

Set theday using thearrows [ ← → ]

(Mo,Tu, We, Th, Fr, Sa, Su) (Monday – Sunday).

Push [ SET ].

Set thehour using

the arrows [ ← → ].

Push [ SET ].

Sets theminutes

using thearrows[ ← → ].

Push [ SET ].

Set theseconds using thearrows [ ← → ].

Push [ SET ].

3

5 7 964

2

8

10

Programming thetimer

You can programme up to 20 on/off operations. The following

example shows how this is done:

Setting programme 1

It will switch on at 08:15 hrs Monday and switch off at 15:45 hrs

on Monday: MO 8:15 ON / MO 15:45 OFF.

Push thearrows [ ← → ] until thedisplay shows “PROG 1 ON”.

Push [ SET ]. The display will now show “SET” and theday

of theweek will flash.

Push thearrows [ ← → ] to choose

theday/s to activate PROG 1.

The days will appear one at atime,

in order MO to SU (Monday to

Sunday), then all days MO – FR

(from Monday to Friday), then all

days MO - SA (Monday – Saturday),

then theweekend (Saturday –

Sunday) and finally all week, MO –

SU (Monday to Sunday). The day in

theexample is Monday (MO).

1

2

3

5

4

6

7

8

3

5 7

1

2

4 6 8

Push SET when thedisplay shows “MO”.

The hours will now start to flash. Adjust thehour using

thearrows [ ← → ] until you get thehour 8.

Push [ SET ].

The minutes will now start to flash. Adjust them to 15

using thearrows [ ← → ].

Push SET to exit thesetup of PROGRAM 1 ON. Push

thearrows [ ← → ] until thedisplay shows “PROG 1 OFF”.

Set theday and thetime in thesame way.

• Push [ RANDOM ] whilst in thetime setup mode to change

between 12/24 hour display.

• Push both arrows at thesame time for 3 seconds in

theCLOCK mode to change to summer time. The hour

setting will advance anhour and thesun symbol lights up on

thedisplay. Push both arrows at thesame time for 3 seconds

in theCLOCK mode to return to normal time.

• If you want to programme several programmes, push

thearrows [ ← → ] until thedisplay shows “PROG 2 ON”.

You can set thedesired number of programmes in

thesame way.

• If no button is pushed for one minute, thetimer switch will

return to clock display mode.

• The programmes are organised in acycle with theclock

and countdown functions

CLOCK

→ Program 1-20 →

CD

count down funktion.

Replace thecover (make sure that thelong battery

contacts are inside thebattery compartment).

Disposal

Follow local ordinances when disposing of this product.

If you are unsure about how to dispose of this product

contact your municipality.
