Bruksanvisning Westinghouse GSP625 Ugn

Bruksanvisning

6 7

USING THE

HOTPLATE

INSTALLATION

GRILL TRAY

To insert the grill tray, fully open the drawer and position

the tray so that the slots on the outer edges t over the tabs

on the slides.

Place the grill tray insert into the grill tray.

BURNER CROWNS AND CAPS

• The burner crown must be tted correctly into the burner

cup or damage will occur during operation.

• To do this, ensure that the 2 ribs on either side of the

spark plug hole are positioned into the 2 slots on the

burner cup (see diagram).

• The burner cap is simply positioned over the top of the

burner crown.

NOTE: When the burner is correctly fitted it will sit level

on the hob.

TRIVETS

• The rubber feet on the trivets locate into the recesses

on the hob.

• Take care when placing the trivets as dropping them

may damage the hob or trivet.

• The wok trivet sits on top of the base trivet above the

wok burner.

burner crown

burner cup

CERAMIC HOTPLATES

The cooktop is made from ceramic glass, a tough, durable

material that withstands heating and cooling without

breaking. It is strong enough to hold the heaviest utensils.

However, it must be remembered that as it is GLASS, it may

break. Treat it accordingly!

Should you have any questions about the glass in your new

appliance, please contact the service centre by dialling 13 13 49.

The heating elements are concealed under the smooth glass

surface which has a pattern to show the location of the elements.

When cooking, turn the control to the required setting.

The ceramic cooktop glass will retain heat for a period of

time after the control is turned off. This will be indicated by

the hot surface warning light which will continue to glow until

the temperature drops below 60°C.

NOTE: If the ceramic glass is cracked switch off the

appliance to avoid the possibility of electric shock.

• Use pans with smooth, clean and dry bottoms to avoid

scratching or burning residue into the glass.

• Ensure the pan bottom is the same size as the

working element.

• We do not recommend ceramic glass pans because they

do not conduct heat well.

• Stainless steel or enamelled saucepans are best.

• Do not use pans with copper or aluminium bottoms

because they can leave traces which are difcult to

remove from the glass.

• If buying new utensils select enamelled steel pans with

2-3mm thick bottoms or stainless steel pans with sandwich

bottoms 4-6mm thick. The pan bottom should be at, or

preferably, slightly concave at room temperature so that it

lies flat on the glass surface when hot.

HOTPLATE DOS AND DON’TS

•

Do not place heat resistant mats, wire mats or

aluminium foil under pots and pans.

•

Do not allow pots and pans to boil dry, as damage

to both pan and hotplate may result.

•

Do not use the hotplate as extra bench space or as a

cutting board.

•

Do not allow children on or near the cooktop at

any time.

•

Do not allow large cookware to overhang the hotplate

onto the adjacent benchtop. This will cause scorching

to the benchtop surface.

•

Do not use round bottom woks or similar utensils which

could lead to overheating of the hotplates and possible

damage to the cooking surface.

•

Use the stored heat in the hotplate by turning the control

to off before the nal few minutes of cooking.

•

Do not slide pans across the surface of the ceramic glass

as it could result in scratching of the surface.

USING THE HOTPLATE

a flat or slightly

concave pan is

preferable for

ceramic hotplates

wok trivet

burner cap

trivets

wok burner

burner crown
