6 7

INSTALLATIONTROUBLESHOOTING

480mm

560mm

*

Gas supply connection location

830mm

Gas supply connection location

*

480mm

Figure 4–60cm and 75cm models cut-out

Figure 4–90cm models cut-out

INSTALLATION INSTRUCTIONS

This appliance must be installed by an authorised person

and in compliance with :

1. AS/NZS 5601.1 Gas Installations Part 1: General

Installations, and AS/NZS 5601.2 Gas Installations

Part 2: LP Gas installations in caravans and

boats for non-propulsive purposes, or the relevant

installation code for gas appliances in your country.

2. The local gas fitting regulations, municipal building

codes, electrical wiring regulations and any other

relevant statutory regulations.

3. The particular instructions as given below.

CAUTION

Cooktops are supplied for use with natural gas (NG).

To use on LPG the injectors MUST be changed using

the conversion kit supplied. Refer LP Conversion on

page 12.

4. A certificate of compliance MUST be given to the

customer after the appliance is successfully installed.

5. This appliance must be earthed.

FAULT POSSIBLE CAUSES REMEDY

Burner will not light

even though the sparker

is working.

• Knob not held down long enough

in ‘High’ position for flame safeguard

(where fitted) to engage

• Repeat lighting procedure and hold knob

down for 5 seconds in ‘High’ position

(refer page 4)

• Gas supply valve turned off • Turn on gas supply to appliance

• Wrong knob turned • Ensure the knob you are turning corresponds

to the burner you want to light

• Port blockage in ignition area • Ensure that ports in ignition area are clean

and dry

• Ignition spark plugs wet or dirty • Dry or clean ignition spark plugs

No spark is obtained

when control knob

is activated

• Electricity supply is disconnected or

switched off

• Switch on electricity or check fuses

• Ignition spark plugs wet or dirty • Dry or clean ignition spark plugs

Flames uneven or

tending to lift

• Flame ports blocked or wet • Clean or dry ame ports

• Burner incorrectly tted • Ensure this component is tted correctly

Flames not staying on

when knob released

• Knob not held down long enough

in ‘High’ position for flame safeguard

(where fitted) to engage

• Repeat lighting procedure and hold knob

down for 5 seconds in ‘High’ position

(refer page 4)

• Knob not set between ‘High’ and

‘Low’

• Knob MUST be set between these positions.

• Dirt or spillage on ame safeguard

sensor (where fitted)

• Clean ame safe guard sensor tip

Low heat, slow cooking

• Incorrect cooking pot or pan being used • Refer to Figure 3 (page 5)

Benchtop or knobs

overheating

• Incorrect cooking pot or pan used • Check Figure 3 for correct pot or pan to be used

• Pot or pan not located on burner

properly

• Ensure pot or pan is centrally located

on burner

If you have a problem with the cooktop, check the table below. You may be able to solve the problem and this will

save you from paying for a service call. You will have to pay for a service call even in the warranty period if the

problem is one listed below.

If the above points have been checked and there is still a problem with the cooktop, please call the Service Centre.
