S I E R R A D E S I G N S

SIERRA DESIGNS 1255 Powell Street Emeryville, CA 94608 Phone: 510-450-9555 Fax: 510-654-0705 Toll Free: 800-635-0461

tions these are the only points you will need to stake out.

For more severe or wet conditions you should stake out

points C, D, E, and F.

Erect the Tent

Insert the Delrin tips of the longer “front arch” pole into

the grommets at points C and D (Figure 3). Clip the Swift

Clip

™

located above the door over the center section of the

pole. Then attach the remaining Swift Clips

™

, following

the seam along the path of the pole, between points C and

D. Now, insert the Delrin tips of the shorter “rear pole”

into the grommets at points E and F, and attach the rear

Swift Clips

™

to this pole.

Figure 4: Flysheet (top view)

Flysheet

Drape the fly over the tent and position the zipper over the

tent door (Figure 4). Attach the Velcro to the front and rear

pole at points J and K. At points A, B, C, D, E, and F are

3/4” side-release buckles (Figure 5). Clip these buckles into

their corresponding mates on the tent floor and pull the

straps until the fly is taut. At points A and B, adjust the

webbing to be certain that the rainfly is fully covering the

tent body. Now pull out point G until the vestibule is taut

and stake it out. You can use a guy line to guy out the fly

at points H and I for increased ventilation.

Figure 5: Fly Clip

Ventilation

The best air flow through the tent is obtained by pitching

the tent with the foot area into the wind. With the rainfly

on, airflow is increased by guying out the rainfly away

from the tent walls. Additionally, the door can be folded

back and tied in an open position.

ULTRA LIGHT YEAR CD TENT CONTENTS

Tent Body & Rainfly: 1 Pitching Instructions: 1

Tent Poles: 2 Stake Sack: 1

Tent Stakes: 7* Pole Sack: 1

Guy Cord: 2

* Sierra Designs tents include stakes for pitching the body and fly under normal conditions.

Additional stakes may be required in severe conditons.

First Pitch

In order to familiarize yourself with your new tent, we

suggest that you “test pitch” it before embarking on a

wilderness trip.

Select a Site

Look for a level spot that is protected from the wind in

order to ensure sleeping comfort. Clear the area of debris

such as sharp stones and sticks which might abrade or

puncture the tent floor. Choose an area that will drain

well when it rains.

Unfurl the Tent and Assemble the Poles

Unfurl the tent and lay the tent floor flat on the ground

with the door unzipped. Carefully unfold the shock corded

pole sections and allow them to slide together. Do not

allow the poles to snap together: This can lead to serious

pole damage. Make certain that the insert of each pole sec-

tion is fully inserted into the next pole section (Figure 1).

You will have one long “front arch” pole and one short

“rear arch” pole (Figure 2).

Figure 1: Correct Pole Assembly

Figure 2: Arch Poles

Stake Out the Tent Floor

First stake down the adjustable webbing loop at the front

and rear of the tent at points A and B (Figure 3). Adjust

the webbing at these points so it is taut. In mild condi-

ULTRA LIGHT YEAR CD

Your Sierra Designs

ULTRA LIGHT YEAR CD

(Computer-aided Design)

tent is very easy to pitch

and maintain. Follow these

instructions to pitch your tent

quickly, safely and easily.

Figure 3: Tent Body (top view)
