Instructional symbols

Note

notes, usage tips, or additional information

→

Followed by

the order of options or menus you must select to perform a step;

for example: Press < Menu > → Messages → Create new

message (represents Menu, followed by Messages, followed by

Create new message)

[ ]

Square brackets

phone keys; for example: [

] (represents the Power/Menu

exit key)

< >

Angled brackets

softkeys that control different functions at each screen; for

example: < OK > (represents the OK softkey)

Turn your phone on and off

1. Press and hold [

] for more than two seconds to switch on the

phone.

2. To turn your phone off, press and hold [

] for more than two

seconds.

Change the display language

1.

In Idle mode, press < Menu > → Settings → Phone settings →

Language.

2. Select a language.

Make a call

1. I

n Idle mode, enter an area code and phone number, and press

[

]

.

2. To end the call, press [

].

Answer a call

1. When the phone rings, press [

] to answer a call.

To reject the call, press < Reject > or [ ].

2. To end the call, press [ ].

Adjust the volume

1. In Idle mode, press < Menu > → Settings → Phone profi les.

2. Select the desired phone profi le and press < Options > → Edit.

3. Press [ left ] or [ right ] to select Phone sounds.

4. Press [ up ] or [ down ] up to select Phone sound volume.

5. Press [ OK ] and press [ left ] or [ right ] to adjust the volume.

6. Press < Save > to save.

Change a ringtone for calls

1. In Idle mode, press < Menu > → Settings → Phone profi les.

2. Select the desired phone profi le and press < Options > → Edit.

3. Press [ left ] or [ right ] to select Incoming calls.

4. Press [ up ] or [ down ] to select Voice call ringtone and

press [ OK ].

5. Press [ up ] or [ down ] to select a ring tone.

6. Press < Select > to save.

Call a recently dialled number

1. In Idle mode, press [ ].

2. Press [ left ] or [ right ] to select a call type.

3. Press [ up ] or [ down ] to select the number or name.

4. Press [ OK ] to view details of the call or [ ] to dial the number.

Phone layout and keys

Dial key

Make or answer a call.

In Idle mode, retrieve

recently dialled, missed,

or received numbers.

Keypad lock key

► Keypad lock mode

Soft keys

Perform actions indi-

cated at the bottom

line of the display.

Web access/

Confi rm key

In Idle mode, launch

the web browser.

In Menu mode, select

the highlighted menu

option or confi rm

an input.

Power/Menu exit key

Turn the phone on and

off (press and hold);

Ends a call; In Menu

mode, cancel input and

return to Idle mode.

Silent mode key

► Silent mode

Alphanumeric keys

4-way navigation key

In idle mode, access

default menus.

In Menu mode, scroll

through menu options.

Install the SIM card and battery

Charge the battery

1. Plug the supplied travel

adapter.

2. When charging is fi nished,

unplug the travel adapter

from the phone.

1. Remove the battery cover and insert the SIM card.

2. Insert the battery and replace the battery cover.

Battery cover

Battery

To AC power outlet

Your phone displays the following status indicators on the top of the screen:

Icon Description

Signal strength

Call in progress

SOS message feature activated

New text message (SMS)

Alarm activated

Bluetooth activated

Bluetooth headset or hands-free car kit connected

GPRS network starts

FM radio on

Phone profi les setting

Silent mode

Battery power level

Enter text

To change the text input mode

In a text input fi eld, press [ ] and select the input mode you want.

Press and hold [ ] to select the T9 word mode

1. Press [ 2 ] to [ 9 ] to start entering a word. Press each key only once

for one letter. The word you are entering appears on the display. It may

change with each keypress. Finish entering the word before editing or

deleting any keystrokes.

2. Press [ ] to insert a space and enter the next word.

ABC or abc mode

Press the keys labelled with the letter you want once for the fi rst letter,

twice for the second letter, and so on.

Number mode

Press the number keys corresponding to the digits you want.

Symbol mode

In the text input fi eld, press and hold [ ] to activate the symbol mode.

Press the number keys corresponding to the symbols you want. You can

press [ left ] or [ right ] to display more symbols.

Send and view messages

Send a text message

1. In Idle mode, press < Menu > → Messages → Create new

message → Text message.

2. Enter the text message.

3. Press < Options > to select Send only or Save and send.

4. Enter the destination number.

5. Press < Options > → Send to send the message.

View text messages

1. In Idle mode, press < Menu > → Messages → My messages →

Inbox.

2. Select a text message to read.

Play music

1. In Idle mode, press < Menu > → Music.

2. Press [ OK ] to play music fi les.

3. During playback, use the following keys:

[ OK ] Pause or resume playback

[ left ] Restart playback. Press to return to the

previous fi le within 3 seconds after the

playback has started. Press and hold to scan

backward in a fi le.

[ right ] Skip to the next fi le. Press and hold to scan

forward in a fi le.

[ up ] Open the playlist

4. Press [ down ] to stop playback.

Use the camera

Capture photos

1. In Idle mode, press < Menu > → Camera.

2. Press < > and [ left ] or [ right ] to select the desired camera

settings.

3. Press [ OK ] to take a photo. The photo is saved automatically.

4. Press < Back > to take another photo.

View a photo

1. In Idle mode, press < Menu > → My fi les → Images →

My photos.

2. Select the photo you want.

Listen to the FM radio

Listen to the FM radio

1. Plug the supplied headset to the phone.

2. In Idle mode, press < Menu > → FM radio.

3. Press [ left ] or [ right ] to fi nd available radio stations.

4. Press < Options > → FM radio on.

5. To turn the radio off, press [ OK ].

Store radio stations

By automatic tuning:

1. From the radio screen, press < Options > → FM radio on.

2. Press < Options > → Self-tuning.

3. Press < Yes > to confi rm. Available radio stations are automatically

saved.

4. Press and hold [ left ] or [ right ] to fi nd the saved radio stations.

By manual setup:

1. From the radio screen, press [ left ] or [ right ] to fi nd the radio

station you want.

2. Press < Options > and select Add to Favourites.

Silent mode

Press and hold [ ] in Idle mode to disable all sounds on the

phone. To exit, press and hold this key again.

Keypad

lock mode

Press and hold [ ] in Idle mode to lock the keypad to ignore

accidental key pressing. To unlock, press and hold [ ].

SOS mode

Press the Volume key four times when the keypad is locked to send

an SOS message to preset numbers. Once the SOS message is

sent, the phone will change to SOS mode and will receive calls only

from the registered recipients. Upon receiving a call from the SOS

message recipients, the phone will automatically answer the call.

Press [ ] to exit SOS mode.

SIM Card

Voice mail server key

Access to the voice

mails (press and hold).

● To move the cursor, press the navigation keys.

●

To delete characters one by one, press < Clear >. To delete

characters on the left side of the cursor, press and hold

< Clear >.

● To insert a space between characters, press [ ].

● To enter punctuation marks, press [ 1 ].

Self-tuning is only activated after you perform the step 1.

Capture videos

1. In Idle mode, press < Menu > → Camera.

2. Press < > → Camcorder to switch to Camcorder mode.

3. Press < > and [ left ] or [ right ] to select the desired video

settings.

4. Press [ OK ] to start recording.

5. Press < > or [ OK ] to stop recording. The video is saved

automatically.

6. Press < > to record another video.

View videos

1. In Idle mode, press < Menu > → My fi les → Videos →

My video clips.

2. Select the video you want.

You can also view your photos or video clips while using

the camera. In the Camera or Camcorder mode, press

< > → Gallery → Photos or Video clips.

Do not remove the battery from the phone without unplugging

the travel adapter fi rst. Otherwise, the phone may be damaged.

Volume key

Adjust the phone’s

volume.

Sends an

SOS message when

pressed four times with

the keypad locked.

►

SOS mode

The volume through mono earphones is very low or

virtually inaudible. Use stereo earphones only.
