Bruksanvisning Samsung SGH-B220B Mobiltelefon

Bruksanvisning

Phone layout

Instructional icons

Note: notes, usage tips, or additional information



Followed by: the order of options or menus you

must select to perform a step; for example: Press

<Menu>  Messages (represents Menu, followed

by Messages)

[ ]

Square brackets: phone keys; for example: [ ]

(represents the Power/Menu exit key)

< >

Angled brackets: softkeys that control different

functions at each screen; for example: <OK>

(represents the OK softkey)

Turn your phone on or off

1. To turn your phone on, press and hold [ ].

2. To turn your phone off, press and hold [

].

Make a call

1. In Idle mode, enter an area code and a phone

number.

2. Press [

] to dial the number.

3. To end the call, press [

].

Answer a call

1. When a call comes in, press [ ].

2. To end the call, press [

].

Adjust the volume

To adjust the volume of the ringtone

1. In Idle mode, press <Menu>  Settings  Sound

settings  Incoming call  Call alert volume.

2. Scroll left or right to adjust the volume level.

3. Press <

Save>.

To adjust the volume of voice during a call

While a call is in progress, press the navigation key up or

down to adjust the earpiece volume.

Change your ringtone

1. In Idle mode, press <Menu>  Settings  Sound

settings  Incoming call  Ringtone.

2. Select a ringtone category

 a ringtone.

3. Press <

Save>.

Call a recently dialled number

1. In Idle mode, press [ ].

2. Scroll left or right to select a call type.

3. Scroll up or down to select a number or name.

4. Press [

OK] to view details of the call or [ ] to dial

the number.

Enter text

To change the text input mode

Press and hold [ ] to switch to an input mode.

Depending on your region, you may be able to

access an input mode for your specic language.

Press [ ] to change case or switch to Number mode.

Press and hold [ ] to switch to Symbol mode.

T9 mode

1. Press the appropriate alphanumeric keys to enter an

entire word.

2. When the word displays correctly, press [ ] to insert

a space. If the correct word does not display, press

[0] to select an alternate word.

•

•

•

ABC mode

Press the appropriate alphanumeric key until the

character you want appears on the display.

Number mode

Press the appropriate alphanumeric key to enter a

number.

Symbol mode

Press the appropriate alphanumeric key to select a

symbol.

To move the cursor, press the navigation key.

To delete characters one by one, press <Clear>. To

delete all of the characters, press and hold <Clear>.

To insert a space between characters, press [ ].

To enter punctuation marks, press [1].

•

•

•

•

Install the SIM card and battery

1. Remove the battery cover and insert the SIM card.

2. Insert the battery and replace the battery cover.

Charge the battery

1. Plug the supplied travel adapter.

2. When charging is nished, unplug the travel adapter.

Do not remove the battery from the phone before

unplugging the travel adapter rst. Otherwise, the

phone may be damaged.

Battery coverBattery cover

SIM cardSIM card

BatteryBattery

To AC power outletTo AC power outlet

Add a new contact

1. In Idle mode, enter a phone number and press

<Options>.

2. Select

Save contact  a memory location (phone or

SIM)  New.

3. Select a number type (if necessary).

4. Enter contact information.

5. Press <

Save> or [OK] to add the contact to memory.

Send and view messages

To send a text message

1. In Idle mode, press <Menu>  Messages  Create

message  Text message.

2. Enter the message text.

3. Press <

Options>  Save and send or Send only.

4. Enter a destination number.

5. Press <

Options>  Send to send the message.

To view text messages

1. In Idle mode, press <Menu>  Messages  My

messages  Inbox.

2. Select a text message.

Activate the mobile tracker

This feature helps track your phone when it is stolen

or when someone tries to use your phone using other

SIM card, the phone will automatically send the preset

tracking message to family or friends. This feature may

be unavailable due to certain features supported by your

service provider.

1. In Idle mode, press <

Menu>  Settings  Security

 Mobile tracker.

2. Enter your password and press <

OK>.

3. Scroll left or right to

ON.

4. Scroll down and press [

OK] to open the recipient list.

5. Press <

Options>  Phonebook to open your

contact list.

6. Scroll to a contact and press [

OK].

7. Select a number (if necessary).

8. When you are nished selecting contacts, press

<Select> to return to the recipient list.

9. Press <

Options>  Save to save the recipients.

10. Scroll down and enter the sender's name.

11. Press <

Save>  <Accept>.

The rst time you access the mobile tracker, you will be

asked to accept the end user agreement to activate the

mobile tracker.

Activate and send an SOS message

In an emergency, you can send SOS messages to your

family or friends for help.

To activate the SOS message

1. In Idle mode, press <Menu>  Messages  SOS

messages  Sending options.

2. Scroll left or right to

On.

3. Scroll down and press [

OK] to open the recipient list.

4. Press [

OK] to open your contact list.

5. Scroll to a contact and press [

OK].

6. Select a number (if necessary).

7. When you are nished selecting contacts, press

<Select> to return to the recipient list.

8. Press <

Options>  OK to save the recipients.

9. Scroll down and set the number of times to repeat the

SOS message.

10. Press <

Save>  <Yes>.

To send an SOS message

1. With the keys locked, press [ ] four times to send

an SOS message to preset numbers.

The phone switches to SOS mode and sends the

preset SOS message.

2. To exit SOS mode, press [

].

Set and use alarms

To set a new alarm

1. In Idle mode, press <Menu>  Applications 

Alarm.

2. Scroll to an empty alarm location and press [

OK].

3. Set alarm details.

4. Press <

Save>.

To stop an alarm

When the alarm sounds,

Press any key to stop an alarm without snooze.

Press <Conrm> or [OK] to stop an alarm with

snooze, or press <Snooze> or any key to silence the

alarm for the snooze period.

To deactivate an alarm

1. In Idle mode, press <Menu>  Applications 

Alarm.

2. Scroll to the alarm you want to deactivate and press

[OK].

3. Scroll down (if necessary).

4. Scroll left or right to

Off.

5. Press <

Save>.

If you have removed the battery after setting an alarm,

the alarm will be deactivated.

•

•

1

4-way navigation key

In ldle mode, access My menu mode

(up) or user-dened menus (left/right/

down); In Menu mode, scroll through

menu options

2

Web access/Conrm key

In ldle mode, access the web

browser; In Menu mode, select the

highlighted menu option or conrm

an input

3

Dial key

Make or answer a call; In Idle mode,

retrieve recently dialled, missed, or

received numbers;

Send an SOS message



Activate and send an SOS message

4

Voice mail service key

In ldle mode, access voice mails

(press and hold)

5

Keypad lock key

In ldle mode, lock the keys (press

and hold)

6

Alphanumeric keys

7

Softkeys

Perform actions indicated at the

bottom of the display

8

Power/Menu exit key

Turn the phone on and off (press and

hold); End a call;

In Menu mode, cancel input and

return to Idle mode

9

Silent mode key

In ldle mode, activate or deactivate

Silent mode (press and hold)

Your phone displays the following status indicators on the top of

the screen:

Icon Description

Signal strength

GPRS network connected

Call in progress

Connecting to secured

web page

Connected with PC

Call diverting activated

Roaming (outside of normal

service area)

New message

SOS message feature

activated

Icon Description

Keys locked

Alarm activated

FM radio on

Silent mode activated

(set to vibrate)

Silent mode activated

(muted)

Ringer mode: vibration

Mute mode activated

(during a call)

Battery power level

1

2

3

4

5

6

7

8

9
