Bruksanvisning

Install the SIM card and battery

Remove the back cover and insert the SIM card.1.

Insert the battery and replace the back cover.2.

Charge the battery

Plug the supplied travel 1.

adapter into the multifunction

jack.

When charging is 2.

nished,unplug

the travel adapter.

Do not remove the battery from the phone before •

unpluggingthetraveladapterrst.Otherwise,the

phone may be damaged.

To save energy, unplug the travel adapter when •

not in use. The travel adapter does not have

a power switch, so you must unplug the travel

adapter from the outlet to interrupt the power

supply. The travel adapter should remain close to

the socket when in use.

Insert a memory card (optional)

Your phone accepts microSD™ or microSDHC™

memory cards up to 16 GB (depending on memory card

manufacturer and type).

Formatting the memory card on a PC may cause •

incompatibility with your phone. Format the

memory card only on the phone.

Frequent writing and erasing of data will shorten •

the life span of memory cards.

Do not use a sharp things when you take the •

memory card out of your phone.

Remove the back cover.1.

Insert a memory card with the gold-coloured 2.

contacts facing up.

Push the memory card in the memory card slot until 3.

it locks in place.

Replace the back cover.4.

Instructional icons

Note: notes, usage tips, or additional

information

→

Followed by: the order of options or menus

you must select to perform a step; for

example: In Menu mode, select Messages

→ Create message (represents Messages,

followed by Create message)

[ ]

Square brackets: phone keys; for example:

[

] (represents the Power/End key)

< >

Angled brackets: softkeys that control

different functions at each screen; for

example: <OK> (represents the OK softkey)

Turn your phone on or off

To turn your phone on,

Press and hold [1.

].

Enter your PIN and press <2. OK> (if necessary).

To turn your phone off, repeat step 1 above.

Access menus

To access your phone’s menus,

In Idle mode, press <1. Menu> to access Menu mode.

YoumayneedtopresstheConrmkeytoaccess•

Menu mode depending on your region or service

provider.

When you are using the smart home screen, you •

cannotusetheConrmkeytoaccessMenumode.

Use the Navigation key to scroll to a menu or option.2.

Press <3. Select>, <Save>,ortheConrmkeyto

conrmthehighlightedoption.

Press <4. Back> to move up one level; Press [

] to

return to Idle mode.

When you access a menu requiring the PIN2, you •

must enter the PIN2 supplied by the SIM card.

For details, contact your service provider.

Samsung is not responsible for any loss of •

passwords or private information or other

damages caused by illegal software.

Manage your SIM cards

Your phone supports Dual SIM mode that enables you

to use two SIM cards at the same time without changing

them. Learn to activate SIM cards and change the card

settings.

To activate SIM cards

In Menu mode, select 1. Settings→SIM cards

management.

Select 2. Network and scroll left or right to a SIM

card.

Press <3. Change> to activate the card.

To switch SIM cards automatically

In Menu mode, select 1. Settings→SIM cards

management.

Select 2. SIM auto switch.

Select 3. SIM auto switch to activate the auto switch

feature.

Set the starting and ending time to use the SIM 4.

card.

To change the names and icons of the SIM cards

In Menu mode, select 1. Settings→SIM cards

management.

Select 2. Register card.

Select a SIM card.3.

Change the name and the icon of the card.4.

Press <5. Back>.

Repeat steps 3-5 for another SIM card.6.

Make a call

In Idle mode, enter an area code and a phone 1.

number.

Press [2.

] to dial the number.

To end the call, press [3.

].

Answer a call

When a call comes in, press [1. ].

To end the call, press [2.

].

Adjust the volume

To adjust the volume of the ringtone

In Menu mode, select 1. Settings → Sound proles.

Scrolltotheproleyouareusing.2.

Ifyouareusingthesilentprole,youarenot

allowed to adjust the volume of the ringtone.

Press <3. Edit> → Volume.

Scroll to 4. Call alert.

Scroll left or right to adjust the volume level and 5.

press <Save>.

To adjust the volume of voice during a call

While a call is in progress, press the Navigation key up

or down to adjust the volume.

Innoisyenvironments,youmayhavedifculty

hearing the calls while using the speakerphone

feature. For better audio performance, use the

normal phone mode.

Change your ringtone

In Menu mode, select 1. Settings → Sound proles.

Scrolltotheproleyouareusing.2.

Ifyouareusingthesilentprole,youarenot

allowed to change the ringtone.

Press <3. Edit> → Voice call ringtone.

Select a memory location (if necessary).4.

Select a ringtone.5.

Toswitchtoanotherprole,selectitfromthelist.

Call a recently dialled number

In Idle mode, press [1. ] to display a list of recent

numbers.

Scroll left or right to a call type.2.

Scroll up or down to a number or name.3.

PresstheConrmkeytoviewdetailsofthecallor 4.

[

] to dial the number.

Use the smart home screen

The smart home screen allows you to access

applications, contacts, and calendar events or view the

clock from Idle mode.

When you are using the smart home screen, the

Navigation key does not work as shortcuts.

To add items to the smart home screen

In Menu mode, select 1. Settings → Display → Smart

home.

Press <2. Edit>.

Select the items to display on the smart home 3.

screen.

Press <4. Options> → Save.

PresstheConrmkey.5.

You can change the idle screen to another style.

In Menu mode, select Settings → Display → Smart

home and scroll left or right to a style you want.

To access the smart home items

Press the Navigation key to scroll through the items on

thesmarthomescreenandpresstheConrmkeyto

select an item.

Enter text

To change the text input mode

Press and hold [• ] to switch between T9 and ABC

modes. Depending on your region, you may be able to

accessaninputmodeforyourspeciclanguage.

Press [•

] to change case or switch to Number mode.

Press [•

] to switch to Symbol mode.

Press and hold [•

] to select an input mode or change

the input language.

T9 mode

Press the appropriate alphanumeric keys to enter an 1.

entire word.

When the word displays correctly, press [2. 0] to insert

a space. If the correct word does not display, press

the Navigation key up or down to select an alternate

word.

ABC mode

Press an appropriate alphanumeric key until the

character you want appears on the display.

Number mode

Press an appropriate alphanumeric key to enter a

number.

Symbol mode

Press an appropriate alphanumeric key to enter a

symbol.

To move the cursor, press the Navigation key.•

To delete characters one by one, press <• Clear>.

To delete all of the characters, press and hold

<Clear>

To insert a space between characters, press [• 0].

To enter punctuation marks, press [• 1].

Add a new contact

The memory location to save new contacts may

be preset depending on your service provider. To

change the memory location, in Menu mode, select

Contacts → <Options> → Settings → Save new

contact to → a memory location.

In Idle mode, enter a phone number and press 1.

<Options>.

Select 2. Add to Contacts → Create contact →

a memory location (if necessary).

Select a number type (if necessary).3.

Enter contact information.4.

PresstheConrmkeyorpress<5. Options> → Save

to add the contact to memory.

Send and view messages

To send a text message or multimedia message

In Menu mode, select 1. Messages → Create

message.

Enter a destination number and scroll down.2.

Enter the message text. 3. ►

Enter text

For sending as a text message, skip to step 5.

For attaching multimedia, continue with step 4.

Press <4. Options> → Add multimedia and add

an item.

PresstheConrmkeytosendthemessage.5.

To view a text or multimedia messages

In Menu mode, select 1. Messages → Inbox.

Select a text or multimedia message.2.

Make fake calls

You can simulate an incoming call when you want to get

out of meetings or unwanted conversations.

To activate the fake call feature

In Menu mode, select Settings → Call → Fake call →

Fake call hot key.

To make a fake call

In Idle mode, press and hold the Navigation key •

down.

When the keys are locked, press the Navigation key •

down four times.

Activate and send an SOS message

In an emergency, you can send SOS messages to your

family or friends for help.

To activate the SOS message

In Menu mode, select 1. Messages → Settings →

SOS messages → Sending options.

Press <2. Change> to select On.

ScrolldownandpresstheConrmkeytoopenthe3.

recipient list.

Press <4. Options> → Search to open your contact

list.

Select a contact.5.

Select a number (if necessary).6.

PresstheConrmkeytosavetherecipients.7.

Scroll down and set the number of times to repeat 8.

the SOS message.

Press <9. Back> → <Yes>.

To send an SOS message

With the keys locked, press [1. ] four times to send

an SOS message to preset numbers.

The phone switches to SOS mode and sends the

preset SOS message.

To exit SOS mode, press [2.

].

Use the camera

To capture photos

In Menu mode, select 1. Camera to turn on the camera.

Rotate the phone anti-clockwise to landscape view.2.

Aim the lens at the subject and make any 3.

adjustments.

PresstheConrmkeytotakeaphoto.Thephotois4.

saved automatically.

To view photos

In Menu mode, select My les → Images →aphotole.

Declaration of Conformity (R&TTE)

We, Samsung Electronics

declare under our sole responsibility that the product

GSM Mobile Phone : GT-C3752

to which this declaration relates, is in conformity with the following standards and/or

other normative documents.

SAFETY EN 60950-1 : 2006 + A11 : 2009

SAR EN 50360 : 2001 / AC 2006

EN 62209-1 : 2006

EMC EN 301 489-01 V1.8.1 (04-2008)

EN 301 489-07 V1.3.1 (11-2005)

EN 301 489-17 V2.1.1 (05-2009)

RADIO EN 301 511 V9.0.2 (03-2003)

EN 300 328 V1.7.1 (10-2006)

We hereby declare that [all essential radio test suites have been carried out and that]

the above named product is in conformity to all the essential requirements of Directive

1999/5/EC.

The conformity assessment procedure referred to in Article 10 and detailed in Annex[IV]

ofDirective1999/5/EChasbeenfollowedwiththeinvolvementofthefollowingNotied

Body(ies):

BABT, Forsyth House,

ChurcheldRoad,

Walton-on-Thames,

Surrey, KT12 2TD, UK*

Identicationmark:0168

The technical documentation kept at :

Samsung Electronics QA Lab.

which will be made available upon request.

(Representative in the EU)

Samsung Electronics Euro QA Lab.

Blackbushe Business Park, Saxony Way,

Yateley, Hampshire, GU46 6GG, UK*

2011.04.15 Joong-Hoon Choi / Lab Manager

(place and date of issue) (name and signature of authorised person)

* It is not the address of Samsung Service Centre. For the address or the phone number of

Samsung Service Centre, see the warranty card or contact the retailer where you purchased

your product.

To capture videos

In Menu mode, select 1. Camera to turn on the camera.

Rotate the phone anti-clockwise to landscape view.2.

Press [3. 1] to switch to the camcorder.

Aim the lens at the subject and make any 4.

adjustments.

PresstheConrmkeytostartrecording.5.

Press the <6. Stop> to stop recording. The video is

saved automatically.

To view videos

In Menu mode, select My les → Videos →avideole.

Listen to music

In Menu mode, select 1. Music → Library.

Select a music category 2. →amusicle.

Control playback using the following keys:3.

Key Function

Conrm Pause or resume playback

Navigation

Left: Skip backward; Scan backward •

inale(pressandhold)

Right: Skip forward; Scan forward in •

ale(pressandhold)

Up/Down: Adjust the volume•

Key Function

1 Rate the current track

2 Select a sound effect

3 Change the repeat mode

4 ActivateordeactivateShufemode

Listen to the FM radio

Plug a headset into the phone.1.

In Menu mode, select 2. Apps → FM radio.

PresstheConrmkeytostarttheFMradio.3.

Press <4. Yes> to start automatic tuning.

The radio scans and saves available stations

automatically.

ThersttimeyouturnontheFMradio,youwillbe

prompted to start automatic tuning.

Control the FM radio using the following keys:5.

Key Function

Conrm Turn the FM radio on or off

Navigation

Left/Right: Fine-tune the frequency; •

Search for an available radio station

(press and hold)

Up/Down: Adjust the volume•

Back cover

Memory

card

Battery

To AC power outlet

SIM cards

Betyg

Mer om denna bruksanvisning

Vi förstår att det är trevligt att ha en pappersbruksanvisning för din Samsung GT-C3752 Mobiltelefon. Du kan alltid ladda ner bruksanvisningen från vår hemsida och skriva ut den själv. Om du vill ha en originalbruksanvisning rekommenderar vi att du kontaktar Samsung. De kanske kan tillhandahålla en originalbruksanvisning. Letar du efter bruksanvisningen för din Samsung GT-C3752 Mobiltelefon på ett annat språk? Välj ditt föredragna språk på vår hemsida och sök efter modellnumret för att se om vi har det tillgängligt.

Specifikationer

Alla bruksanvisningar för Samsung Mobiltelefoner
Fler bruksanvisningar för Mobiltelefoner

Vanliga frågor om Samsung GT-C3752 Mobiltelefon

Vårt supportteam söker efter användbar produktinformation och svar på vanliga frågor. Om du hittar en felaktighet bland våra vanliga frågor uppskattar vi om du meddelar oss detta via vårt kontaktformulär.

Relaterade produkter

Bruksanvisning

Samsung SM-N920C Galaxy Note 5 Mobiltelefon

Bruksanvisning

Samsung SM-S721B/DS Galaxy S Mobiltelefon

Bruksanvisning

Samsung GT-I9001/M16 Galaxy S Plus Mobiltelefon

Bruksanvisning

Samsung SGH-N710 Mobiltelefon

Bruksanvisning

Samsung GT-E1205L Mobiltelefon

Bruksanvisning

Samsung SPH-M300 Mobiltelefon

Bruksanvisning

Samsung GT-S5600T Mobiltelefon

Bruksanvisning

Samsung SGH-I900V (T-Mobile) Mobiltelefon

Relaterade kategorier
