6. USE
Switch ON/OFF a heater zone
To switch ON a heater Touch power key during 400 msec. Long beep
will be heard and "0" value will appear in target zone digit, indicating
power level.
1) If any cooking stage is in position 0, this display will switch OFF
automatically after 10 seconds and the zone OFF sequence will
sound.
2) If there is residual heat indication in the display which is ON but in 0
power, "0" will appear changing over.
3) If lock function is active you cannot switch ON a zone.
To switch OFF a heater Touch power key during 1,2 sec. 3 Short
beeps will be heard and nothing or "H" value will appear in target zone
digit if residual heat exists. Zone will be OFF.
1) If any cooking stage is in position 0, this display will switch OFF
automatically after 10 seconds and the zone OFF sequence will
sound.
2) If there is residual heat indication in the display which is OFF, "H"
will be displayed.
3) Even lock function is active you can switch OFF a zone.
4) If only one heater is active and this one is switched off, 4 Short beep
will be heard indicating all cook top is Off.
Increase / Decrease power level
With a short press on ‘+’ or ‘-‘ keys, Increase or decrease power in the
selected zones digit: 0-1-2-3...9-P
1. For Long Presses in + or - keys, power level increases /decreases
continuously. With a fast increase, power stops at level 9, and for a
higher power another short press is needed on the + key. No beep
sound is heard with fast increase / decrease.
2. Once arrived to P power level, pressing + key again does not
change power level to 0.Once arrived to 0 power level, pressing - key
again does not change power level to P.
Child Lock
The action will be done when lock key is touched
Then, any time when a key will be touched, displays will show "L"
during 2sec. heating remains at the same state.
To deactivate Child Lock, follow the same process explained before.
Then Short beep will be heard and displays will show "n" letter. Hob will
remain unlocked.
Note: An automatic child lock will produce in 15 minutes after total
Switch OFF of the hob.
07 GB
To switch ON double extension ring, associated main zone must be
already ON and Indicating power level must be higher than 0.
8.1- Double zone ON
1st Short Press on extension key Switches ON extension ring. LED
over extension key turns ON if Extension ring is ON.
2nd Short Press on extension key Switches OFF extension ring.
Short beep each press on extension key.
8.2- Triple zone ON
1st Short Press on extension key Switches ON 1st extension ring. 1
LED over extension key turns ON if 1st extension ring is ON (left LED
in case of triple zone, middle and only LED in case of double zone) 2nd
Short Press on extension key Switches ON 2nd extension ring. 2
LEDs over extension key turn ON if 1st and 2nd extension rings are
ON
3rd Short Press on extension key. Switches OFF 1st and 2nd
extension rings.
Short beep each press on extension key.
Double / Triple zones
8 8
8
8
8
8
8 8
8
8
8
8
8 8
8
8
8
8
8 8
8
8
8
8
THE CHOICE OF COOKWARE - The following information will help
you to choose cookware which will give good performance.
Stainless Steel : highly recommended. Especially good with a
sandwich clad base. The sandwich base combines the benefits of
stainless steel (appearance, durability and stability) with the
advantages of aluminium or copper (heat conduction, even heat
distribution).
Aluminium : heavy weight recommended. Good conductivity.
Aluminium residues sometimes appear as scratches on the hob, but
can be removed if cleaned immediately.
Because of its low melting point, thin aluminium should not be used.
Cast Iron : usable, but not recommended. Poor performance. May
scratch the surface.
Copper Bottom / stoneware: heavy weight recommended. Good
performance, but copper may leave residues which can appear as
scratches. The residues can be removed, as long as the hob is
cleaned immediately. However, do not let these pots boil
dry. Overheated metal can bond to glass hobs. An overheated copper
pot will leave a residue that will permanently stain the hob.
Porcelain/enamel : Good perfomance only with a thiny smooth, flat
base.
Glass-ceramic : not recommended. Poor performance. May scratch
the surface.
3. With a zone ON at 0 power level, if the zone is hot, 0 will blink
alternatively.After 10 seconds, 0 will disappear an ‘H’ letter will appear
fixed on display.
4. When a heater is selected and ‘+’ & ‘-‘keys are touched at the same
time, power level will go to ‘0’ but heater will maintain selected during
10 seconds. If heater was temporized, timer will go to Off. This action
can only be developed in several cases depending touch control
configuration.The following examples are for information only.
Personal experience should then let you adapt these settings to your
taste and habits.
Bridge function
The bridge can be enabled only when both heaters are off. One heater
of the bridge has been selected, to activate bridge function touch
bridge key.
Abeep sounds and the zone LED is switched on if the zone is enabled.
Both bridge heaters will be selected at the same time.
Once the heaters selected, if the power level is not the desired power
level, by the + - keys.
Both bridge heater displays will show same power level.
The function will finish:
- If the bridge key is touched in setting mode
- If user selects power level “0”
8 8
8
8
8
8
