English

IMPORTANT

SAFETY

INSTRUCTIONS

When using an electrical

appliance, basic precautions are

required to always be followed,

including the following.

Read all instructions before using

this appliance.

DANGER

To reduce the risk of electric

shock:

1. Do not reach for an appliance

that has fallen into water.

Unplug immediately.

2. Do not use while bathing or in a

shower.

3. Do not place or store appliance

where it can fall or be pulled into

a tub or sink. Do not place in or

drop into water or other liquid.

4. Except when charging, always

unplug this appliance from the

electrical outlet immediately

after using.

5. Unplug this appliance before

cleaning.

WARNING

To reduce the risk of burns, re,

electric shock, or injury to

persons:

1. This appliance is not intended

for use by persons (including

children) with reduced physical,

sensory or mental capabilities,

or lack of experience and

knowledge, unless they have

been given supervision or

instruction concerning use of the

appliance by a person

responsible for their safety.

Children should be supervised

to ensure that they do not play

with the appliance.

2. Use this appliance only for its

intended use as described in

this manual. Do not use

attachments not recommended

by the manufacturer.

3. Never operate this appliance

when it has a damaged cord or

plug, when it is not working

properly, after it has been

dropped or damaged, or after it

has been dropped into water.

Return the appliance to an

authorized service center for

examination and repair.

4. Keep the cord away from heated

surfaces.

5. Never drop or insert any object

into any opening.

6. Do not use outdoors or operate

where aerosol (spray) products

are being used.

7. Do not use this appliance with a

damaged or broken blade, as it

has the potential to result in

facial injury.

8.

Always attach plug to appliance

rst, then to outlet. To disconnect,

turn all controls to “o󰀨” then

remove plug from outlet.

SAVE THESE

INSTRUCTIONS

• The following symbol indicates that a

specic detachable power supply unit is

required for connecting the electrical

appliance to the supply mains. The type

reference of power supply unit is marked

near the symbol.

• Charge the appliance correctly according

to these Operating Instructions. (See

“Charging”.)

• If the battery uid leaks out, stop using

and remove the battery.

• Do not use any blade and screws other

than the one dedicated as it may cause

defect in performance.

• This appliance contains battery that is

only replaceable by skilled persons.

Please contact an authorized service

center for the details of repair.

• Do not use non-rechargeable batteries.

Parts identication

(Fig. 1)

AMain body

1 Protective cap

2 Power switch

2: High speed

1: Low speed

0: O󰀨

3 Battery

capacity lamp

4 Charge status

lamp

5 Appliance

socket

BBlade

* With screws

2pcs

CCharging stand

(RC9‑95)

6 Charging plug

7 Stand socket

DAC adaptor

(RE9‑82)

8 Adaptor

9 Power plug

: Cord

;

Appliance plug

Accessories

ECleaning brush

FLubrication oil

Charging (Fig. 2)

• Make sure that the appliance is turned o󰀨.

1

Connect the appliance plug to the

stand socket.

2

Place the appliance on the charging

stand.

3

Insert the adaptor into a household

outlet.

• Check that the charge status lamp

(Red) glows.

• Charging is completed after approx.

1 hour.

► Display while charging

While charging

(Low battery

capacity)

While charging

After charging is

completed

5 seconds later

after charging is

completed

( :Glows, :Blinks, :Turns o󰀨)

4

Disconnect the adaptor after charging

is completed.

► Charging without the charging stand

(Fig. 3)

Plug the AC adaptor into the main body

and the household outlet.

► Notes

• When charging the appliance for the rst

time or when it has not been in use for

more than 6 months, the charging time

may change or the charge status lamp

may not glow for a few minutes. It will

eventually glow if kept connected.

• Recommended ambient temperature for

charging is 15 °C – 35 °C (59 °F – 95 °F).

It may take longer to charge, or the

charge status lamp will blink quickly and

the battery may fail to charge properly in

extremely high or low temperatures.

• 1 full charge will provide approximately 60

minutes of continuous operation. (Based

on dry usage at 20 °C – 30 °C

[68 °F – 86 °F])

The operating time may di󰀨er depending

on the frequency of use and the operating

method.

• The battery will deteriorate if not used for

over 6 months, so make sure to perform a

full charge at least once every 6 months.

• If there is noise from the radio or other

sources while using or charging the

appliance, move to a di󰀨erent location to

use the appliance.

Operating Instructions

Instrucciones de funcionamiento

AC/Rechargeable Professional Hair Trimmer

Máquina de corte profesional recargable / Ac

Model No.

Modelo n.º

ER-XT70

4

1

2



















 













1

1

2

3

2

a

5

3

6

7 8

1

3

2

(image)

► Note the following precautions

• The supply cord cannot be replaced.

If the cord is damaged, the AC

adaptor should be scrapped.

- Failure to do so may cause an

accident or injury.

CAUTION

► Protecting the skin

• Do not press the blade strongly

against the skin.

• Do not use the appliance for any

purpose other than trimming hair

and beards.

• Do not directly apply the blades on

ears or rough skin (such as

swellings, injuries or blemishes).

- Doing so may cause injury to skin or

ears.

• Check that the blades are not

damaged or deformed before use.

- Failure to do so may cause skin injury.

► Note the following precautions

• Do not allow metal objects or trash

to adhere to the power plug, the

appliance plug or the charging plug.

- Doing so may cause electric shock or

re due to a short circuit.

• Disconnect the adaptor from the

household outlet when not using.

- Failure to do so may cause electric

shock or re due to electrical leakage

resulting from insulation deterioration.

Proper handling when

disposing of the battery

DANGER

• The rechargeable battery is

exclusively for use with this

appliance. Do not use the battery

with other appliances.

• Do not charge the battery after it has

been removed from the appliance.

• Do not throw into re or apply heat.

• Do not hit, disassemble, modify, or

puncture with a nail.

• Do not let the positive and negative

terminals of the battery get in

contact with each other through

metallic objects.

• Do not carry or store the battery

together with metallic jewellery such

as necklaces and hairpins.

•

Do not use or leave the battery where

it will be exposed to high

temperatures, such as under direct

sunlight or near other sources of heat.

• Never peel o󰀨 the tube.

- Doing so may cause overheating,

ignition, or explosion.

WARNING

• After removing the rechargeable

battery, do not keep it within reach

of children and infants.

- The battery will harm the body if

accidentally swallowed.

If this happens, consult a physician

immediately.

• If the battery uid leaks out and

comes in contact with the eyes, do

not rub the eyes. Thoroughly rinse

with clean water, such as tap water.

- Failure to do so may cause eye injury.

Consult a physician immediately.

CAUTION

• If the battery uid leaks out and

comes in contact with the skin or

clothes, rinse o󰀨 with clean water,

such as tap water.

- Failure to do so may cause

inammation.

Important information

• This appliance is designed for

professional use to trim hair and beards.

It can be operated on either an AC

adaptor or rechargeable battery.

• Apply the lubrication oil to the blade

before and after each use.

Failure to apply the lubrication oil may

cause the following problems.

- The appliance has become blunt.

- Shorter operating time.

- Louder sound.

- Blade becomes rusty.

- Blade life becomes short due to too

much friction.

- Blade movement becomes slower.

• Do not drop or hit against other objects.

Doing so may cause injury.

• You should not allow permanent wave

lotion, hair dye or hair spray to come into

contact with the main body or the blade.

Doing so may result in cracking or

corrosion.

Safety precautions

Follow these instructions.

To prevent accidents, injuries or damage to

property, please follow the instructions below.

■ The following chart indicates the

degree of damage caused by

improper operation.

DANGER

Indicates potential

hazard that will result

in serious injury or

death.

WARNING

Indicates potential

hazard that could

result in serious

injury or death.

CAUTION

Indicates potential

hazard that could

result in minor injury

or property damage.

WARNING

► This appliance

• This appliance has a built‑in

rechargeable battery. Do not throw

into re, apply heat, or charge, use,

leave, or store in a high temperature

environment.

- Doing so may cause overheating,

ignition, or explosion.

• Do not modify or repair.

- Doing so may cause re, electric

shock, or injury.

Contact an authorized service center

for repair (replacement of battery etc).

• Never disassemble except when

disposing of the appliance.

- Doing so may cause re, electric

shock, or injury.

► Power supply

• Do not connect or disconnect the

adaptor to a household outlet with a

wet hand.

- Doing so may cause electric shock or

injury.

• Do not use when the AC adaptor is

damaged or when the tting into the

household outlet is loose.

• Do not damage the cord or the

power plug.

• Do not deface, modify, forcefully

bend or pull the cord or the power

plug. Also, do not place anything

heavy on, twist or pinch the cord.

- Doing so may cause electric shock or

re due to a short circuit.

Keep the appliance dry.

• Do not use in a way that would

exceed the rating of the household

outlet or the wiring.

-

Exceeding the rating by connecting too

many plugs to one household outlet

may cause re due to overheating.

•

Use only the supplied AC adaptor and

the charging stand with this

appliance. Do not use the AC adaptor

and the charging stand with any other

appliance. (See “Parts identication”.)

- Failure to do so may cause burn or

re due to a short circuit.

• Fully insert the power plug.

- Failure to do so may cause re or

electric shock.

•

Regularly clean the power plug, the

appliance plug and the charging plug

to prevent dust from accumulating.

- Failure to do so may cause re due to

insulation failure caused by humidity.

► Preventing accidents

• Do not place within reach of children

or infants.

-

Putting parts or accessories in the

mouth may cause an accident or injury.

• If the lubrication oil is consumed

accidentally, do not induce vomiting,

drink a large amount of water, and

contact a physician.

• If the lubrication oil comes into

contact with eyes, immediately wash

thoroughly with running water, and

contact a physician.

- Failure to do so may result in physical

problems.

►

In case of an abnormality or malfunction

• Immediately stop using and remove

the adaptor if there is an abnormality

or malfunction.

- Failure to do so may cause re,

electric shock, or injury.

<Abnormality or malfunction cases>

• The main body, charging stand or

AC adaptor is deformed or

abnormally hot.

• The main body, charging stand or

AC adaptor smells of burning.

• There is an abnormal sound during

use or charging of the main body.

- Immediately request inspection or

repair to an authorized service center.

• If the shape of the plug does not t the

power outlet, use an attachment plug

adaptor of the proper conguration.

Lubrication (Fig. 4)

• Apply the lubrication oil to the blade

before and after each use.

1

Apply a drop of the lubrication oil to

each indicated point.

2

Turn on the power and allow to run for

approximately 5 seconds.

How to use

• When using for the rst time be sure to

charge the appliance.

• Apply the lubrication oil to the blade

before and after each use.

• The appliance may not operate in an

ambient temperature lower than

approximately 5 °C (41 °F).

Turn the power switch on. (speed selection)

2: High speed

→ In normal use

1: Low speed

→ If you have sensitive

skin or are concerned

about irritation.

0: O󰀨

• After use, turn it o󰀨 and clean it.

skin

• Do not press the

blade strongly

against the skin

when trimming with

the switch down.

•

Do not apply the

blade on ears when

using it around them.

► Note

• The lamps will turn o󰀨 approximately 5

seconds after operating the switch.

However, if the battery remaining is low, it

will not turn o󰀨 and one battery capacity

lamp and the charge status lamp blinks.

(When the power is turned o󰀨, the lamps

turn o󰀨 after 5 seconds.)

Charging is required when the one battery

capacity lamp and the charge status lamp

blinks. You can trim 5 minutes after this is

displayed. (This will di󰀨er depending on

usage.)

► About the approximate remaining

charge

Battery capacity

High

Low

( :Glows, :Blinks, :Turns o󰀨)

AC operation

If you connect the AC adaptor to the

appliance in the same way as for charging,

and turn on the power, you can use it.

• The charge status lamp glows when using

the AC operation.

• If the remaining battery is too low, the

blades may move slowly or stop, even

with the AC operation. In this case,

charge the battery for 1 minute or more.

• The battery will be discharged, even with

the AC operation.

Maintenance

• Do not use thinner, benzine or other

chemicals. Doing so may cause failure,

cracking or discoloration of the parts.

Clean the main body only with a soft cloth

slightly dampened with tap water or soapy

tap water.

The symbol on the left means

“Do not wash the product with

water”.

How to clean

► Main body, Blade (Fig. 5)

• You can clean the blade to the main body

attached. However, recommended to

detach the blade and brush it carefully at

the end of the day.

1. Remove the blade.

2. Brush o󰀨 any hair trimmings.

• Brush any hair trimmings out from

between the stationary blade and the

moving blade while pressing down the

cleaning lever (a) to raise the moving

blade.

3. Attach the blade to the main body.

4. Apply the lubrication oil to the blade.

5. Attach the protective cap to the blade.

► Charging stand (Fig. 6)

Use the cleaning brush to clean hair

trimmings and dust in the charging plug or

in the hole on the bottom surface.

Removing and mounting the

blade (Fig. 7)

The blade can be attached/detached by a

driver as illustrated.

Replacement parts

Replacement parts are available at your

dealer or Service Center.

Replacement

parts for

ER-XT70

Blade with

screws 2pcs

WER9770

Lubrication oil WES003P

• We recommend Panasonic lubrication oil

WES003P.

Troubleshooting

Problem Action

The

appliance

does not

operate.

The

appliance

has become

blunt.

Operating

time is short.

Charge the appliance

when using for the rst

time.

Until problems are solved,

please follow each

procedure as follows;

1. Charge the appliance.

2. Clean the blade and

apply lubrication oil.

3. Replace the blade.

4. Replace the battery.

The

appliance

cannot be

charged.

Push the main body into

the charging stand or

appliance plug all the

way.

Charge within the

recommended charging

temperature of 15 °C

– 35 °C (59 °F – 95 °F).

Makes a

loud sound.

Apply lubrication oil.

Conrm that the blade is

properly attached.

If the problems still cannot be solved,

contact the store where you purchased the

appliance or a service center authorized by

Panasonic for repair.

Disposal of the

appliance (Fig. 8)

ATTENTION:

A lithium ion battery that is recyclable

powers the product you have purchased.

Please call 1-800-8-BATTERY for

information on how to recycle this battery.

Remove the built‑in rechargeable battery

before disposing of the appliance.

• The battery is to be disposed of safely.

• This gure must only be used when

disposing the appliance, and must not be

used to repair it. If you dismantle the

appliance yourself, it may cause

malfunction.

How to remove the battery

•

Remove the appliance from the AC adaptor.

• Slide the power switch to turn on the

power and then keep the power on until

the battery is completely discharged.

• Perform steps and lift the battery, and

then remove it.

• Take care not to short circuit the positive

and negative terminals of the removed

battery, and insulate the terminals by

applying tape to them.

Specications

Power source

See the name plate on

the AC adaptor.

(Automatic voltage

conversion)

Motor voltage

3.2 V

Charging time Approx. 1 hour

Thank you for purchasing this Panasonic product.

Gracias por comprar este producto Panasonic.

Betyg

Mer om denna bruksanvisning

Vi förstår att det är trevligt att ha en pappersbruksanvisning för din Panasonic ER-XT70 Skäggtrimmer. Du kan alltid ladda ner bruksanvisningen från vår hemsida och skriva ut den själv. Om du vill ha en originalbruksanvisning rekommenderar vi att du kontaktar Panasonic. De kanske kan tillhandahålla en originalbruksanvisning. Letar du efter bruksanvisningen för din Panasonic ER-XT70 Skäggtrimmer på ett annat språk? Välj ditt föredragna språk på vår hemsida och sök efter modellnumret för att se om vi har det tillgängligt.

Specifikationer

Alla bruksanvisningar för Panasonic Skäggtrimmer
Fler bruksanvisningar för Skäggtrimmer

Vanliga frågor om Panasonic ER-XT70 Skäggtrimmer

Vårt supportteam söker efter användbar produktinformation och svar på vanliga frågor. Om du hittar en felaktighet bland våra vanliga frågor uppskattar vi om du meddelar oss detta via vårt kontaktformulär.

Relaterade produkter

Bruksanvisning

Panasonic ER-GK80 Skäggtrimmer

Bruksanvisning

Panasonic ER-GY10 Skäggtrimmer

Bruksanvisning

Panasonic ER-GB43 Skäggtrimmer

Bruksanvisning

Panasonic ER-GB60 Skäggtrimmer

Bruksanvisning

Panasonic ER-RZ10 Skäggtrimmer

Bruksanvisning

Panasonic ER-GB44 Skäggtrimmer

Bruksanvisning

Panasonic ER-GB40 Skäggtrimmer

Bruksanvisning

Panasonic ER-GD50 Skäggtrimmer

Relaterade kategorier
