Bruksanvisning Panasonic DMP-BDT310 Blu-ray spelare

Bruksanvisning

8

VQT3B62

Precautions of Wireless LAN connection

The following limits are in place regarding the usage of this unit or

Wireless LAN adaptor. You must be aware of these limits before using

these devices.

Panasonic will in no way be responsible for any incidental damage which

may arise due to a failure to obey these limits, or to any condition of use or

disuse of these devices.

≥ Data transmitted and received over radio waves may be

intercepted and monitored.

≥ This unit or Wireless LAN adaptor contain delicate electronic

components.

Please use these devices in the manner in which it was intended and

follow the following points:

–Do not expose these devices to high temperatures or direct sunlight.

–Do not bend, or subject these devices to strong impacts.

–Keep these devices away from moisture.

–Do not disassemble or alter the device in any way.

STEP 4 : Settings

After connecting your new player for the first time and

pressing [Í], a screen for the basic settings will appear.

Preparation

Turn on the television and select the appropriate video

input on the television.

1 Press [Í].

Setup screen appears.

If this unit is connected to a Panasonic TV (VIERA)

supporting HDAVI Control 2 or later via an HDMI cable,

then setting information on the TV such as “On-Screen

Language” is acquired by this unit.

2 Follow the on-screen instructions and

make the settings with [3, 4] and press

[OK].

After completing “Easy Setting”, you can perform “Network

Easy Setting”.



≥ You can perform this setup anytime by selecting “Easy Setting” in the

Setup menu. ([HOME]

>“Setup”>“Player Settings”>“Others”)

Touch Free Sensor [BDT310] [BDT210]

By setting “Sensor” in “Touch Free Sensor” to “On”, you can open or close

the tray just by waving your hand over the TOUCH-FREE SENSOR on the

upper side of the unit. (This will also work when in stand-by.)

≥ Be aware that the TOUCH-FREE SENSOR may function unintentionally

in the following cases:

–When your hand or arm, an object, a small child, or a small animal

comes close to the upper part of the unit

–When an object is placed on top of the unit and vibration is applied

–When connecting a cable etc. to the rear of the unit

≥ Reactive distance of the sensor is automatically set in accordance with

the installation conditions at the time of power supply connection and

when the open/close button is pressed. To prevent an incorrect setting,

do not place your hands or objects above the unit at these times.

≥ Depending on the usage conditions, the TOUCH-FREE SENSOR may

stop working or the reactive distance may become shorter. In such

cases, press the tray open/close button once.

∫ Wireless LAN connection

– [BDT310] [BDT210] : Wireless LAN is built in. (There is

no need to connect a Wireless LAN Adaptor.)

– [BDT111] [BDT110] : Connect the Wireless LAN Adaptor

DY-WL10 (optional).

≥ For up to date compatibility information on your Wireless

router refer to

http://panasonic.jp/support/global/cs/

(This site is in English only.)

≥ The unit is not compatible with public wireless LAN

services (Hotspot etc.) provided in airports, stations, cafes

etc.

≥ [BDT111] [BDT110] :

– Only the Wireless LAN Adaptor DY-WL10 (optional) can

be used.

– Read the operating instructions for the Wireless LAN

Adaptor DY-WL10 (optional) thoroughly when using it.

– To simultaneously connect the Wireless LAN Adaptor

DY-WL10 (optional) and a LAN cable, use the extension

cable supplied with the DY-WL10.

LAN

10BASE-T/100BASE-TX

WIRELESS LAN

ADAPTOR

COMMUNICATION

CAMERA

Wireless router, etc.

Wireless LAN Adaptor

Internet

[BDT111]

[BDT110]

DLNA Certified

media server

LAN Cable

Easy Setting

Standby/on switch (Í/I)

Press to switch the unit from on to standby mode or

vice versa. In standby mode, the unit is still

consuming a small amount of power.

(8)

DMP-BDT310_110EG-VQT3B62.book 8 ページ ２０１１年５月１８日　水曜日　午後１２時３分
