Bruksanvisning Panasonic CQ-HX1003W Bilradio

Bruksanvisning

E

N

G

L

I

S

H

CQ-HX1083/1003W

9

E

N

G

L

I

S

H

CQ-HX1083/1003W

8

When Driving

Keep the volume level low enough to be aware of

road and traffic conditions.

When Washing Your Car

Do not expose the product, including the speakers

and CDs, to water or excessive moisture. This could

cause electrical shorts, fire, or other damage.

When Parked

Parking in direct sunlight can produce very high

temperatures inside your car. Give the interior a

chance to cool down before switching the unit on.

Use the Proper Power Supply

This product is designed to operate with a 12 V DC,

negative ground battery system.

Disc Mechanism

Do not insert coins or any small objects. Keep

screwdrivers and other metallic objects away from

the disc mechanism and disc.

Service

This product is made of precision parts. Do not at-

tempt to disassemble or adjust any parts. For re-

pair, please consult your nearest authorized

Panasonic service station.

For Installation

This product should be installed in a horizontal po-

sition with the front end up at a convenient angle,

but not more than 30x.

Note:

≥ The preset memory is cleared to return to the

original factory setting when the power connector

or battery is disconnected.

Panasonic welcomes you to our ever growing family of electronic product owners. We know that this prod-

uct will bring you many hours of enjoyment. Our reputation is built on precise electronic and mechanical

engineering, manufactured with carefully selected components and assembled by people who take pride in

their work. Once you discover the quality, reliability, and value we have built into this product, you too will

be proud to be a member of our family.

Use this Product Safely

Before Reading these Instructions

≥ This operating instruction manual is for 2 models; CQ-HX1083W and CQ-HX1003W. All illustrations

throughout this manual rpresent model CQ-HX1083W unless otherwise specified. The following table de-

scrives the differences between 2 models.

CQ-HX1083W CQ-HX1003W

Models

Features

MP3/WMA playback Yes None

This can only be controlled through

the main unit.

This can only be controlled through

the remote control unit.

Operations with neither mark can be performed ei-

ther by the main unit or the remote control unit.

CQ-HX1083W

CQ-HX1003W

Indicates features applicable to

CQ-HX1083W only.

Indicates features applicable to

CQ-HX1003W only.

Note:

≥ Be careful not to lose the included operation

guide, which you may need when operating the

unit. Store it in a location such as one of the door

pockets in your car.

S

E

T

S

E

T

PWRPWRPWR BANDBANDBAND

FACEFACEFACE SS

•

AS

•

A

DISPDISPDISP DIMDIMDIM

MENUMENUMENU

RETRETRET

11222333

44555666

77888

00

99

##

MUTEMUTEMUTE

SCANSCANSCAN

DIMMERDIMMERDIMMER

RANDOMRANDOMRANDOM

NUMBERNUMBERNUMBER

REPEATREPEATREPEAT

RETURNRETURNRETURNSOURCESOURCESOURCE

VOLVOLVOL

Car AudioCar Audio

≥ Remote control unit (1) ≥ Removable face plate

case (1)

≥ Wiping cloth for the

touch panel (1)

≥ Operating instructions

(1)

≥ Operation guide (1)

≥ Installation hardware

(screws, power con-

nector, etc.) (page 56)

≥ Lithium battery

(CR2025) (1)

Accessories

Touch Sensor Control

Instead of turning a knob or pushing a button to ac-

tivate or change a setting, simply place your finger

lightly on the corresponding area of the panel.

Display Color and Patterns

You are free to choose whatever color you like to

light up the entire display. You can further cus-

tomize your display with 5 spectrum analyzer pat-

terns.

Double Security

Due to original Shutter LCD technology, the panel

turns completely black when you turn off the unit.

But for perfect security, you can actually remove the

entire front panel and take it with you when you

leave your car.

CD Player

≥ CD-R/RW playback

≥ MP3 and WMA playback

≥ Super One-Chip Digital Circuit

CQ-HX1083W

Features
