6

loosen.

• Position the Counterweight so the Tonearm

oats in a position between down and up.

• Gently slide the Counterweight towards the

Tonearm Pivot Point so the stylus will rest on

your Stylus Tracking Force Pressure Scale

Gauge.

• Make ne adjustments to the Counterweight

until the desired Tracking Force is achieved.

The recommended setting for the included

Sumiko Olympia Cartridge is 2.0 grams.

Other cartridges may differ.

• Tighten the Allen Wrench Screw by turning

clockwise with the Medium Allen Wrench.

Installing the Belt

The Belt must be installed around the Pulley and

the Platter. The Pulley has two speed positions for

the Belt (Figures 12 and 13 on page 9). The

wider position is 45 rpm and the position above is

for 33 rpm. To install the Belt:

• Place the Belt below the 45 rpm groove

towards the bottom of the Pulley.

• Using two hands, pull the Belt outward

following a path beyond the outer edge of the

Platter in each direction keeping the Belt as

level as you can.

• With the Belt pulled beyond the diameter of

the Platter, rest the Belt on the Platter edge

furthest from the Pulley and gently release the

Belt so it rests on the Platter’s edge on both

sides of this point.

• Lift the Belt to the proper position on the

Pulley.

• Turn the Platter to automatically level the

Belt.

Record Clamps?

Record clamps are used by some to reduce

vibrations caused by records that are warped.

If you choose to use a record clamp, it is

recommended you do not use a heavy one. Some

may think heavier is better, but excess weight will

put added strain on the spindle and bearing of the

MTI100, and there is no real benet to doing this.

Effective lighter options exist in the world if you

wish to employ record clamps.

Playing a Record

• Place a record on the record mat on top of the

platter.

• The record should be clean(ed) using your

preferred method.

• Select the Phono (PH) Input using the Input

Knob or Remote Control.

• Press the Input Knob to start the motor and turn

the platter. Note the Input Knob will only turn

on the motor with PH selected.

• Place Tonearm Lift in the up position which is

with the lever facing up.

• Release the Tonearm from the Tonearm Rest

and place it above the start of the record.

• When positioned at the desired point, pull the

Tonearm Lift towards you, lowering the Stylus

onto the record.

End of the Record

• When the Stylus reaches the end of the record,

lift the Tonearm by the handle and place it back

in the Tonearm Rest.

• To stop the motor from spinning the platter,

push the Input Knob or switch to another input.

Pulley

Belt

Figure 07– Top view- Belt and Pulley
