To ensure adequate ventilation, the back panel

of the cabinet must be removed. It is advisable

to install the oven so that it rests on two strips

of wood, or on a completely flat surface with an

opening of at least 45 x 560 mm as the picure.

Donotinstalltheappliancebehindadecorative

door - risk of fire.

If the appliance is installed under the worktop,

do not obstruct the minimum gap between the

worktop and the upper edge of the oven - risk of

burns.

if the range is placed on a base, it must be

leveled and fixed to the wall by the retention chain

provided, to prevent the appliance slipping from

the base.

WARNING: In order to prevent the appliance

from tipping, the retentionchainmust be installed.

Refer to the instructions for installation.

GAS CONNECTION

WARNING : Prior to installation, ensure that the

local distribution conditions (type of gas and gas

pressure) and the configuration of the appliance

are compatible.

Check that the pressure of the gas supply is

consistent with the values indicated in Table 1

(“Burner and nozzle specifications”).

WARNING : The configuration conditions of

this appliance are stated on the label (or data

plate).

WARNING : This appliance is not connected

to a combustion products evacuation device. It

must be installed and connected in accordance

with current installation regulations. Particular

attention must be paid to the relevant

requirements regarding ventilation.

If the appliance is connected to liquid gas,

the regulation screw must be fastned as tightly as

possible.

IMPORTANT : When the gas cylinder or gas

container is installed, it must be properly settled

(vertical orientation).

WARNING : This operation must be perfomed

by a qualified technician

Use only flexible or rigid metal hose for gas

connection.

Connection with a rigid pipe (copper or steel)

Connection to the gas system must be carried

out in such a way as not to place any strain of

any kind on the appliance. There is an adjustable

L-shaped pipe fitting on the appliance supply

ramp and this is fitted with a seal in order to

prevent leaks. The seal must always be replaced

after rotating the pipe fitting (the seal is provided

with the appliance). The gas supply pipe fitting is

a threaded 1/2 gas cylindrical male attachment.

Connecting a flexible jointless stainless steel

pipe to a threaded attachment

The gas supply pipe fitting is a threaded 1/2 gas

cylindrical male attachment. These pipes must

be installed so that they are never longer than

2000 mm when fully extended. Once connection

has been made, make sure that the flexible metal

pipe does not touch any moving parts and is not

compressed. Only use pipes and seals that comply

with current national regulations.

IMPORTANT : If a staineless steel hose is used,

it must be installed so as not touch any moving

part of the furniture (e.g.drawer). It must pass

thorugh an area where there are no obstructions

and where it is possible to inspect it across its

entire length.

Theappliance shouldbe connectedto themain

gas supply or to a gas cylinder in compliance with

the current national regulations. Before making

the connection, make sure that the appliance is

compatible with the gas supply you wish to use.

If it is not, follow the instructions indicated in the

paragraph "Adapting to different types of gas".

After connection to the gas supply, check for

leaks with soapy water. Light up the burners and

turn the knobs from max position 1* to minimum

position 2* to check flame stability.

Connection to the gas network or the gas

cylinder may be carryout using a flexible rubber

or steel hose, in accordance with current national

legislation.

4

ELECTRICAL WARNINGS

IMPORTANT: Information about current and

voltage consumption is provided on the rating

plate.

The rating plate is on the front edge of the

oven (visible when the door is open).

It must be possible to disconnect the appliance

from the power supply by unplugging it if

plug is accessible, or by a multi-pole switch

installed upstream of the socket in accordance

with the wiring rules and the appliance must

be earthed in conformity with national electrical

safety standards.

The power cable must be long enough to connect the appliance,

once fitted in its housing, to the main power supply. Do not pull the

power supply cable.

Do not use extension leads, multiple sockets

or adapters. The electrical components must not

be accessible to the user after installation. Do not

use the appliance when you are wet or barefoot.

Do not operate this appliance if it has a damaged

power cable or plug, if it is not working properly,

or if it has been damaged or dropped.

If the supply cord is damaged, it must

be replaced with an identical one by the

manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard -

risk of electric shock.
