3

motels, bed & breakfast and other residential

environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do

not use the appliance outdoors.

Do not store explosive or flammable

substances (e.g. gasoline or aerosol cans) inside or

near the appliance - risk of fire.

Use pots and pans with bottoms the same

width as that of the burners or slightly larger (see

specific table). Make sure pots on the grates do

not protrude beyond the edge of the hob.

Improper use of the grids can result in damage

to the hob: do not position the grids upside down

or slide them across the hob.

Do not let the burner flame extend beyond the

edge of the pan

Do not use : Cast iron griddles, ollar stones,

terracotta pots and pans. Heat diffusers such as

metal mesh, or any other types. Two burners

simultaneously for one receptacle (e.g. Fish

kettle).

Should particular local conditions of the delivered

gas make the ignition of burner difficult, it is

advisable to repeat the operation with the knob

turned to small flame setting.

In case of installation of a hood above the cooktop,

please refer to the hood instructions for the correct

distance.

The protective rubber feet on the grids represent

a chocking hazard for young children. After

removing the grids, please ensure that all the feet

are correctly fitted.

INSTALLATION

The appliance must be handled and installed

by two or more persons - risk of injury. Use

protective gloves to unpack and install - risk of

cuts.

The electrical and gas connections must

comply with local regulation.

Installation, including water supply (if any),

electrical connections and repairs must be carried

out by a qualified technician. Do not repair or

replaceanypart of the applianceunless specifically

statedin the usermanual. Keep childrenawayfrom

the installationsite. After unpackingtheappliance,

make sure that it has not been damaged during

transport. In the event of problems, contact the

dealer or your nearest Aftersales Service. Once

installed, packaging waste (plastic, styrofoam

parts etc.) must be stored out of reach of

children - risk of suffocation. The appliance must

be disconnected from the power supply before

any installation operation - risk of electric shock.

During installation, make sure the appliance does

not damage the power cable - risk of fire or electric

shock. Only activate the appliance when the

installation has been completed.

WARNING : Modification of the appliance and

its method of installation are essential in order to

use the appliance safely and correctly in all the

additional countries

Use pressure regulators suitable for the gas

pressure indicated in the instruction.

The room must be equipped with an air

extraction system that expels any combustion

fumes.

The roommust also allow properair circulation,

as air is needed for combustion to occur normally.

The flow of air must not be less than 2 m³/h per

kW of installed power.

The air circulation system may take air directly

from the outside by means of a pipe with an inner

cross section of at least 100 cm²; the opening must

not be susceptible to blockages.

The system can also provide the air needed for

combustion indirectly, i.e. from adjacent rooms

fitted with air circulation tubes as described above.

However, these rooms must not be communal

rooms, bedrooms or rooms that may present a fire

hazard.

Liquid petroleum gas sinks to the floor as it

is heavier than air. Therefore, rooms containing

LPG cylinders must also be equipped with vents

to allow gas to escape in the event of a leak.

This means LPG cylinders, whether partially or

completely full, must not be installed or stored

in rooms or storage areas that are below ground

level (cellars, etc.). It is advisable to keep only the

cylinder being used in the room, positioned so

that it is not subject to heat produced by external

sources (ovens, fireplaces, stoves, etc. ) which

could raise the temperature of the cylinder above

50°C.

Should you find it difficult to turn the knobs for the burner, please

contact the After-sales Service, who can replace of the burner tap if

found to be faulty.

The openings use for the ventilation and dispersion of heat must never

be covered.

Carry out all cabinet cutting works before

fitting the appliance in place and remove all wood

chips and sawdust.

Do not remove the appliance from its polystyrene

foam base until the time of installation.

If the appliance is not installed above an oven,

a separator panel (not included) must be installed

in the compartment under the appliance.

Connection with rigid pipe (copper or steel):

If the gas pressure is different from the

recommended pressure, a suitable pressure

regulator must be fitted to the inlet pipe in

accordance with the current national regulations.

Use an appropriate cabinet to ensure that the

appliance operates properly: To install the oven

under the counter (see diagram) or in a kitchen

unit, the cabinet must have the dimensions as the

picture.
