4 SPEAKER PLACEMENT

Speaker Placement

Color-Coding System

The HKS 4 and the HKTS 11 use the channel

color-coding system established by the Con-

sumer Electronics Association to make setting up

your home theater speaker system as easy as

possible. Your system includes a set of colored

stickers that may be placed near the speaker ter-

minals of each of the satellite speakers. In addi-

tion, the included speaker wires have colored

bands at each end to assist you in connecting

them correctly. Use the brown sticker and cable

for the Surround Back Left speaker, and the tan

sticker and cable for the Surround Back Right

speaker. Although the wires included with

your HKS 4 speakers are color-coded for the Sur-

round Back Left and Right channels, they are

interchangeable with the wires supplied with the

HKTS 11 system. It doesn’t matter which satel-

lite speaker is used for any of the front or rear

positions. (The center speaker and powered sub-

woofer of the HKTS 11 are already color-coded.)

When Used as Front Speakers

Front speakers should be placed the same dis-

tance from each other as they are from the lis-

tening position. They should be placed at about

the same height from the floor as the listeners’

ears, or they may be angled toward the listeners.

When Used as Surround Speakers

For 5.1-channel applications, the two surround

speakers should be placed slightly behind the lis-

tening position and, ideally, should face each

other and be at a level higher than the listeners’

ears. If that is not possible, they may be placed

on a wall behind the listening position, facing

forward.

In 7.1-channel systems, place the side surround

speakers slightly behind the listening position, as

shown in the diagram to the left. The surround

back speakers should be placed on the rear wall,

facing forward, the same distance apart as the

main front speakers.

In 6.1-channel systems, you may use a pair of

HKS 4 speakers for the surround back speakers

in place of a single rear center speaker. Using

two speakers will provide a more diffuse sur-

round effect, and will also increase the total

sound output for the surround back channel

without overworking any individual speaker.

Place the two speakers on the rear wall the

same distance apart as each speaker is from the

listener, but at least four feet apart.

The surround back speakers in a 6.1- or 7.1-

channel system should be placed at the same

height as the surround speakers, about 1.5 to

1.8 meter above the floor.

The surround speakers should not call attention

to themselves. Experiment with their placement

until you hear a diffuse, ambient sound accom-

panying the main-program material heard in the

front speakers.

Satellites and Surrounds

The satellite speakers may be placed on a shelf.

They may be wall-mounted using the supplied

brackets.

1,5-1,85 m

Surround Back Speakers

(7.1-Channel System)

Surround Back Speakers

(6.1-Channel System)

(place at least 1.2m apart)

Side Surround Speakers

Surround Speakers
