Bruksanvisning Florabest IAN 70720 Slangvinda

Bruksanvisning

3 GB/IE

Introduction / Safety advice

:DOO0RXQWHG+RVH%R[



Introduction

These operating instructions form a part

of this product. They contain important

information on safety, use and disposal.

Make yourself familiar with all the operating in-

structions and safety advice for the product before

installation. Use the product only as described and

for the indicated purpose. If you pass the product

on to anyone else, please ensure that you also

pass on all the documentation with it.



Proper use

This hose reel is intended for use as a practical or-

ganisational aid in the garden and has an auto-

matic winding-in function. Any use other than that

described or any modification of the product is not

permissible and may result in injury and/or dam-

age to the product. The manufacturer is not liable

for damage caused by improper use. The product

is not intended for commercial use.



Description of parts

and features

1

Wall holder

2

Hosepipe reel with hosepipe 19.5 m

3

Side cover

4

Hosepipe attachment 1.5 m

5

Tap attachment

6

Hosepipe connector

7

Screws (approx. ø 4.8 x 55 mm)

8

Dowels (approx. ø 8 x 38 mm)

9

Spray nozzle

10

Hosepipe connector with water stop function



Included items

1 x Wall holder

1 x Hosepipe reel with hosepipe 19.5 m

1 x Side cover

1 x Hosepipe attachment 1.5 m

1 x Tap attachment

1 x Hosepipe connector

4

x Screws (approx. ø 4.8 x 55 mm)

4 x Dowels (approx. ø 8 x 38 mm)

1 x Spray nozzle

1 x Hosepipe connector with water stop function

1 x Operating instruction



Technical data

Dimensions: approx. 480 x 255 x 415 mm

Hosepipe attachment:

approx. 12.5 mm x 1.5 m

Hose: approx. 12.5 mm x 19.5 m

Wall holder:

approx. 15 x 9.5 x 26.5 cm

Safety advice

CAUTION! DANGER OF INJURY!



KEEP THE PRODUCT OUT OF

THE HANDS OF CHILDREN.



THIS PRODU

CT IS NOT A TOY! This prod-

uct must not be used by children.



DANGER TO LIFE AND RISK OF ACCI-

DENTS FOR INFANTS AND CHILDREN!

Never leave children unsupervised with the

packaging materials. Danger of suffocation.

Keep out of the reach of children.

CAUTION! DANGER OF ELECTRIC

SHOCK! Make sure that no electrical cables

are damaged during installation of the product.

CAUTION! WATER DAMAGE! Make sure

that no water pipes are damaged during instal-

lation of the product. Observe the operating

instructions for your drill.

CAUTION! RISK OF INJURY! Ensure that

all parts are undamaged and have been as-

sembled appropriately. Risk of injury exists if

assembled incorrectly. Damaged parts can

effect safety and function.



Have the installation done by experienced

persons only.

 Do not open the housing. The springs are
