Bruksanvisning Florabest IAN 70720 Slangvinda

Bruksanvisning

4 GB/IE

Safety advice / Installation

preset; they may spring back.

 Never remove any screws from parts of the

housing.

CAUTION! RISK OF INJURY! Never let

the hose spring back by itself. Guide it careful-

ly back into the housing.

CAUTION! RISK OF INJURY! Never let go

of the hose if the automatic stop function is not

engaged.

CAUTION! RISK OF INJURY! Never

allow the hose to retract freely. This could result

in damage to the product.



Nev

er block the hose end with your fingers or

other objects during use.

 To avoid fr

ost damage, remove the hose reel

from the wall and store it dry during winter.

CAUTION! DANGER OF SLIPPING!

Ensure that the ground near the hose reel is

kept as dry as possible.



Turn t

he tap into the off position when the hose

reel is not in use.



The hose is not suitable for

delivering drinking water.



Installation



Fitting the water

hosepipe attachment

 Guide the short length of hosepipe attachment

4

from outside through the opening into the

side compartment of the hose reel. Remove the

screw-on cap from the hose reel hose connection

and guide it onto the hosepipe attachment

4

(see Fig. A).

 Insert the hosepipe attachment

4

firmly into

the toothed connection piece and screw the

cap back on (see Fig. B).

 Close the side compartment with the side cover

3

(see Fig. C).



Choosing the installation site

The hose reel is intended for outdoor use only and

cannot be connected to indoor taps.

 Choose a part of the wall surface with approx.

50 cm free to eac

h side so that the hose reel

can be turned through 180°.

 If you wish to take the hose around a wall corner,

mount the hose reel at least 1 m from the

corner and use a hose guide (not included).

Note: To prevent backflow do not install the hose

reel higher than the tap.

Or: Install a reflux preventer or a pipe interrupter

between tap and hose.



Mounting the wall holder

Important! The holder must be mounted

vertically (see Fig. E).



Use the four screws and dowels supplied. They

are suitable for mounting on brick, concrete or

wooden walls only. For mounting on other ma-

terials please use suitable screws and dowels.

Enquire in your local DIY shop for some suitable

screws and dowels for your particular wall.



Mounting the hose reel

 Push the hose reel

2

on to the wall holder

1

(see Figs. F + G).

 Attach the tap attachment

5

to the free end of

the hosepipe attachment

4

and screw it on to

the water hosepipe connector

6

(see Fig. D).

 Push the hosepipe connector with water stop

function

10

and the spray nozzle

9

on to the

long garden hose.

 Check that the hose reel

2

can turn through

180° (see Fig. H).

 Before first use turn the tap on and allow water

to run through the garden hose.

 Check the device for leaks and tighten any

loose connections if necessary.
