Bruksanvisning

Have your tool repaired by an expert

This appliance is manufactured in accordance with rele-

vant safety standards. Only experts must carry out repai-

ring of electrical appliances, otherwise considerable dan-

ger for the user may result.

Storing tools

When not in use tools should be stored in the dry, out of

reach of children.

Lubrication

The machine requires a small amount of light oil on the

blade guide otherwise no other user lubrication

ELECTRICAL INFORMATION

This product is complete with a pre-wired mains plug, it

is double insulated in accordance with EN 50144 – no

earth wire is required.

If the plug needs replacing follow these instructions.

Wire correctly

The wires in the mains lead are coloured in the following

way:

BLUE -Neutral

BROWN -Live

Securing wires

Secure wires carefully and firmly to the correct termi-

nals. Secure the mains cable in the plug cord grip firmly

Fit a 5-amp fuse. If a 13amp (BS1363) plug is used a (BS

1362) ASTA approved 5-amp fuse must be fitted.

Recycle/Dispose of old plug and cable

Prevent inadvertent connection to socket and risk of

electric shock

ENVIRONMENT

Recycle the packaging according to the identification

marks on it.

At the end of the product or its accessories life please

recycle where facilities exist - phone the Helpline for

current advice on recycling.

Helpline

For any queries relating to operational or safety

matters contact:

Ferm Customer Helpline on: 0115 966 1199

Monday-Friday 8am – 6pm

Saturday 9am – 1 pm

GUARANTEE

The guarantee conditions can be found on the separately

enclosed guarantee card.

We declare under our sole responsibility that this

product is in conformity with the following

standards or standardized documents

EN50144-2-10, EN50144-1

EN55014-1, EN55014-2, EN61000-3-2, EN61000-

3-3

in accordance with the regulations:

98/37/EEC

73/23/EEC

89/336/EEC

from 01-03-2000

GENEMUIDEN NL

W. Kamphof

Quality department

CE

ı

DECLARATION OF CONFORMITY

(

UK

)

Brown

(Live)

Blue

(Neutral)

Fuse

(5 Amp)

6 Ferm

Concentrate

Routine and repetition can lead to mistakes. Remember

that a slight lack of concentration can result in serious

injuries in a split second.

Keep work area clean

Cluttered areas and benches invite injuries.

Consider the work environment

Do not expose power tools to rain or use them in damp

or wet locations. Keep work area well lit. Do not use

power tools in the presence of flammable liquids,

vapours or gases.

Guard against electric shock

This unit contains dangerous voltages. Use a RCD (resi-

dual current device) to provide protection against elec-

trical shock. Prevent body contact with grounded surfa-

ces (e.g. pipes, radiator, ranges or refrigerators).

Keep children and pets away

Do not let children or pets come into contact with the

tool, extension cable or work area.

Do not force the tool

It will work better and safer at the rate for which it was

intended.

Use the right tool

Do not force small tools or attachments to do the job of a

heavy-duty tool. Do not use tools for purposes for which

they were not intended; for example do not use a circular

saw for cutting trees or logs.

Do not abuse cable

Never carry the tool by the cable or pull it to disconnect

it from the power socket. Keep the cable away from heat,

oil and sharp edges. Do not touch the metal plug pins

when connecting or removing the plug.

Secure work

Use clamps or a vice to hold work. It is safer than using

your hand and it frees both hands to operate the tool.

Do not over-reach

Keep a proper footing and balance at all times.

Disconnect tools from power supply

When not in use, before servicing and when changing

accessories such as blades, bits and cutters. Always

switch off and unplug the saw from the power

supply before making adjustments or changing

blades.

Remove adjusting keys and wrenches

Ensure that they are removed from the tool before swit-

ching on.

Avoid unintentional starting

Do not carry plugged in tools with your finger on the

switch. Check that the switch is off before plugging in to

socket.

Outdoor use extension cables

When the tool is used outdoors use only an extension

cable intended for outdoor use and marked accordingly.

Use a RCD (residual current device)

This provides protection against electrical shock. Do

not use in rain or damp conditions.

Connect a dust extraction device

Whenever there are facilities for fitting a dust of fume

extraction system, make sure it is connected and used.

Use recommended accessories

The use of any other accessory or attachment other than

recommended in the instructions or catalogue may pre-

sent a risk of personal injury. Use extension cables suita-

ble for the power input of the saw (minimum cable size

1.5mm2). When using a cable reel unwind the cable fully.

BEFORE USING THE SAW

Do not use this machine without the footplate

mounted. This saw is for hand held use only. Do not

fix to bench or clamp in vice. Make sure the saw is switched

OFF and unplugged from mains before adjusting, changing

blades or inspecting.

SELECTING SAW BLADES

Use universal fitting jigsaw blades suitable for Ferm jigsaws.

In general fine tooth pitch gives a slower cleaner cut – as a

guide chose a pitch of 2.5 to 4.00mm for wood and 1.00

to 1.50mm for metal. Blade material, tooth profile and

hardness is important, for the best performance.

Choose blades manufactured for the material you are

using.

FITTING/CHANGING SAW BLADES

Refer to illustration below.

When changing blades make sure that the blade

slot, clamp plate and guide wheel are free from

sawdust, swarf etc.

- Slide the clear safety shield to its upper position.

- Loosen both bolts (A) with the 3mm Allen key provided;

this is kept in a slot under the dust extractor opening.

- Insert the blade, with the teeth facing upwards towards

the saw, into the holder (C) on the jigsaw.

- Ensure the blade is fully home and is in the groove (D) and

the rear edge of the blade is in the groove of the roller.

- Make sure the clamping plate (E) is square to the blade

and tighten the bolts firmly to secure the blade.

- Stow the Allen key in its holder.

- Slide the clear safety shield to its lowest position.

Ferm 3
