Bruksanvisning Currys Essentials C20FHW17 Värmefläkt

Bruksanvisning

Product Overview

Unpacking

Remove all items from the packaging. Retain the packaging. If you dispose of it

please do so according to local regulations.

The following items are included:

• If items are missing or damaged, please contact Partmaster (UK only).

• Tel: 0344 800 3456 for assistance.

Heating Operation

Position the heater upright on the oor away from curtains, furniture or wall

coverings before plugging your heater into the mains socket.

It is normal for the heater to emit some smell and fumes when it is turned on for

the rst time or when turned on after not being used for a long period of time. This

smell will disappear when the heater has been turned on for a short while.

Cleaning

Your heater should be cleaned regularly to prevent dirt and dust from building

up which will aect its performance. Ensure the air inlet and the air outlet are not

blocked. This can be done with a vacuum cleaner, using the brush attachment.

Ensure you unplug your heater from the mains socket and wait for the heater to

cool down completely before cleaning.

Hints & Tips

My heater does not work when I turn it on

• Check that your heater is plugged in and the power is turned on at the mains

socket.

• Check that your heater is in an upright position.

• Check if the thermostat setting is too low.

• Try replacing the fuse in the plug.

• If the heater still doesn’t work, do not try to repair the heater yourself.

If your heater’s power is automatically cut o follow the steps

below:

1. Unplug your heater and allow it to cool down.

2. Inspect your heater. Clean the air inlet and the air outlet with a vacuum

cleaner if necessary. If there is any sign of physical damage (e.g. melting,

or burning of the case), do not attempt to use your heater. Please leave all

maintenance work to qualied personnel.

3. Plug-in the heater and switch it on again. If it cuts o again, move the heater

to a better ventilated location.

Safety Protective Devices

Overheat Protection System

The power to the heater will automatically cut o if the temperature of the heater

exceeds a certain limit. In the event of overheating, the heater will stop operating.

Switch the heater o and allow it to completely cool. The heater will then resume

operating as normal.

Tip-over Protective Switch

When you use the heater in an upright position on a at and stable surface, the

tip-over protective switch will be on. In the event the heater is knocked over, the

heater will stop functioning automatically.

Specications

Model C20FHW17

Supply Voltage 220 - 240V~ 50Hz

Power Input 1200W (Low Heat)

2000W (High Heat)

Features and specications are subject to change without prior notice.

The Main Unit

Thermostat

Control

Heating Light

• Turn the Power Control to the “◐” (low heat) or “●” (high heat) position.

• Turn the Thermostat Control to the desired position. It is recommended

to select the “MAX” position to get the heater to pre-heat. It will take 5-10

minutes for the heater to fully heat up.

• When the room reaches the desired temperature, turn the Thermostat

Control slowly anti-clockwise.

This unit will not operate unless positioned on a at stable surface or if the

thermostat is set too low.

Fan Operation

The fan can be switched on independently of the heating elements.

Turn the Power Control to “

” position, the heater will blow cool air out from the

air outlet.

The heater or the fan will not operate by turning the Power Control when the

thermostat setting is too low.

• Do not override the tip-over protective switch as this may cause a hazard.

• Using the unit on a deep pile carpet may activate the tip-over protective switch.

Instruction

Manual

Instruction Manual

Power Control

The heater or the fan will not operate by turning the Power Control when the

thermostat setting is too low.

Switching the Unit O

• Turn the Power Control to the “OFF” position.

• Turn the Thermostat Control to the “MIN” position.

• Unplug from the mains supply.

C20FHW17_IB_170713_grace.indd 4-6 13/7/17 6:19 pm
