Bruksanvisning Currys Essentials C20CHW18 Värmefläkt

Bruksanvisning

IB-C20CHW18-200605V3

Thank you for purchasing your new product.

We recommend that you spend some time reading this instruction manual in order that

you fully understand all the operational features it oers.

Read all the safety instructions carefully before use and keep this instruction manual for

future reference.

2kW Convector Heater

Instruction Manual

C20CHW18

This product is only suitable for well-insulated spaces or occasional use.

Product Overview

Unpacking

Remove all items from the packaging. Retain the packaging. If you dispose of it please do so

according to local regulations.

The following items are included:

• Main Unit

• Foot x 2

• Screw x 4

Assembly

Before using the heater, the feet (supplied) must be tted to the unit. Attach the feet to the base

of the heater using the screws provided (2 for each foot), taking care to ensure that they are

located correctly in the bottom ends of the heater’s side.

Fit the screws in the

adjacent position

• If items are missing or damaged, please contact Partmaster (UK only).

• Tel: 0344 800 3456 for assistance.

Handle

Power Switch

Air Outlet

Thermostat

Control

Operation

Position the heater upright on the oor away from curtains, furniture or wall coverings before

plugging your heater into the mains socket.

• Press the Power Switch to the “750W” or “1250W” position, the indicator will illuminate

when the heating element is ON. For maximum heat output, press both Power Switch.

• Turn the Thermostat Control to the desired position. It is recommended to select the “MAX”

position to get the heater to pre-heat. It will take 5-10 minutes for the heater to fully heat up.

• When the room reaches the desired temperature, turn the Thermostat Control slowly anti-

clockwise until the indicator goes o and the thermostat “click o” sound is heard.

• After this, the heater will keep the air temperature in the room at the set temperature

by switching on and o automatically. If the room temperature falls below the desired

temperature, the heater and indicator will turn on again until the room temperature reaches

the desired temperature.

Cleaning

Your heater should be cleaned regularly to prevent dirt and dust from building up which will

aect its performance. Ensure the air inlet and the air outlet are not blocked.

This can be done with a vacuum cleaner, using the brush attachment.

Hints & Tips

My heater does not work when I turn it on

• Check that your heater is plugged in and the power is turned on at the mains socket.

• Check that your heater is in an upright position.

• Check if the thermostat setting is too low.

• If the heater still doesn’t work, do not try to repair the heater yourself.

If your heater’s power is automatically cut o follow the steps

below:

1. Unplug your heater and allow it to cool down.

2. Inspect your heater. Clean the air inlet and the air outlet with a vacuum cleaner if necessary.

If there is any sign of physical damage (e.g. melting, or burning of the case), do not attempt

to use your heater. Please leave all maintenance work to qualied personnel.

3. Plug-in the heater and switch it on again. If it cuts o again, move the heater to a better

ventilated location.

Overheat Protection

The power to the heater will automatically cut o if the temperature of the heater exceeds a

certain limit. In the event of overheating, the heater will stop operating. Switch the heater o

and allow it to completely cool. The heater will then resume operating as normal.

• Ensure you unplug your heater from the mains socket and wait for the heater to

cool down completely before cleaning.

• Do not use any detergents or abrasives and do not allow any water to enter the

heater.

It is normal for the heater to emit some smell and fumes when it is turned on for the

rst time or when turned on after not being used for a long period of time. This smell

will disappear when the heater has been turned on for a short while.

C20CHW18_IB_Final200605V3.indd 1-3 05/06/2020 12:25
