Operation Guide 5208

E-30

D

Start Stop

Elapsed Time

➤

Re-start Clear

D

➤

Stop

D

➤

D

➤

A

Split Time

D

Start Split

➤

Split release

Clear

A

➤

Stop

A

➤

D

➤

A

Two Finishes

D

Start Split

➤

Stop

Clear

A

➤

Split release

D

➤

A

➤

A

First runner finishes.

Display time of first

runner.

Second runner

finishes.

Display time of

second runner.

To measure times with the stopwatch

• The split time screen alternates between a split indicator (SPL) and the split time at

two-second intervals.

E-31

Illumination

An LED (light-emitting diode) illuminate the display for

easy reading in the dark.

To illuminate the display

In any mode (except when a setting screen is on the

display), press B to turn on illumination.

• You can use the procedure below to select either 1.5

seconds or 3 seconds as the illumination duration. When

you press B, the illumination will remain on for about

1.5 seconds or 3 seconds, depending on the current

illumination duration setting.

l

l

l

l

l

l

l

l

l

l

l

l

l

l

l

l

l

l

l

E-32

To specify the illumination duration

1. In the Timekeeping Mode, hold down A until the

display contents start to flash. This is the setting screen.

2. Press C 10 times until the current illumination duration

setting (LT1 or LT3 ) appears.

3. Press D to toggle the setting between LT1

(approximately 1.5 seconds) and LT3 (approximately 3

seconds).

4. Press A to exit the setting screen.

E-33

Power Supply

This watch is equipped with a solar cell and a rechargeable battery that is charged by

the electrical power produced by the solar cell. The illustration shown below shows

how you should position the watch for charging.

Example: Orient the watch so its face is

pointing at a light source.

• The illustration shows how to position a

watch with a resin band.

• Note that charging efficiency drops when

any part of the solar cell is blocked by

clothing, etc.

• You should try to keep the watch outside of

your sleeve as much as possible. Charging

is reduced significantly if the face is

covered only partially.

Solar cell

E-34

Important!

• Storing the watch for long periods in an area where there is no light or wearing it in

such a way that it is blocked from exposure to light can cause rechargeable battery

power to run down. Be sure that the watch is exposed to bright light whenever

possible.

• This watch uses a rechargeable battery to store power produced by the solar cell, so

regular battery replacement is not required. However, after very long use, the

rechargeable battery may lose its ability to achieve a full charge. If you experience

problems getting the rechargeable battery to charge fully, contact your dealer or

CASIO distributor about having it replaced.

• Never try to remove or replace the watch’s rechargeable battery yourself. Use of the

wrong type of battery can damage the watch.

• The current time and all other settings return to their initial factory defaults whenever

battery power drops to Level 5 (pages E-36 and E-37) and when you have the

battery replaced.

• Turn on the watch’s Power Saving function (page E-46) and keep it in an area

normally exposed to bright light when storing it for long periods. This helps to keep

the rechargeable battery from going dead.

E-35

To check the current battery level

When the battery level is at Level 1 (HI) or Level 2 (MID), the corresponding battery

level indicator (HI or MID, page E-8) will appear only if you press C in the

Timekeeping Mode. For other battery levels, the applicable indicator appears

automatically.

Battery level indicator

E-36

Function Status

All functions enabled.

All functions enabled.

Key operation tone, alarm, Hourly Time

Signal, and illumination disabled.

All hands stop at 12 o’clock. All operations

disabled.

All functions, including timekeeping,

disabled and initialized.

Level

1

2

3

4

5

Battery Level Indicator

(Charge Soon Alert)

•

The battery level indicator shows the current power level of the rechargeable battery.

E-37

• The indicator at Level 3 tells you that battery power is very low, and that

exposure to bright light for charging is required as soon as possible.

• At Level 5, all functions are disabled and settings return to their initial factory

defaults. Once the battery reaches Level 2 after falling to Level 5, reconfigure the

current time, date, and other settings.

•

Display indicators reappear as soon as the battery is charged from Level 5 to Level 2.

• Leaving the watch exposed to direct sunlight or some other very strong light source

can cause the battery power indicator to show a reading temporarily that is higher

than the actual battery level. The correct battery level should be indicated after a few

minutes.

E-38

• Performing illumination, or beeper operations during a

short period may cause

(recover) to appear on the

display.

After some time, battery power will recover and

(recover) will disappear, indicating that the above

functions are enabled again.

• If

(recover) appears frequently, it probably means

that remaining battery power is low. Leave the watch in

bright light to allow it to charge.

Recover indicator

E-39

Charging Precautions

Certain charging conditions can cause the watch to become very hot. Avoid leaving

the watch in the areas described below whenever charging its rechargeable battery.

Also note that allowing the watch to become very hot can cause its liquid crystal

display to black out. The appearance of the LCD should become normal again when

the watch returns to a lower temperature.

Warning!

Leaving the watch in bright light to charge its rechargeable battery can cause it

to become quite hot. Take care when handling the watch to avoid burn injury.

The watch can become particularly hot when exposed to the following

conditions for long periods.

• On the dashboard of a car parked in direct sunlight

• Too close to an incandescent lamp

• Under direct sunlight
