Operation Guide 5208

E-40

Charging Guide

The following table shows the amount of time the watch needs to be exposed to light

each day in order to generate enough power for normal daily operations.

Exposure Level (Brightness)

Outdoor Sunlight (50,000 lux)

Sunlight Through a Window (10,000 lux)

Daylight Through a Window on a Cloudy Day (5,000 lux)

Indoor Fluorescent Lighting (500 lux)

Approximate

Exposure Time

8 minutes

30 minutes

48 minutes

8 hours

• For details about the battery operating time and daily operating conditions, see the

“Power Supply” section of the Specifications (page E-52).

• Stable operation is promoted by frequent exposure to light.

E-41

Recovery Times

The table below shows the amount exposure that is required to take the battery from

one level to the next.

Approximate Exposure Time

Level 5 Level 4 Level 3 Level 2 Level 1

3 hours 35 hours 10 hours

10 hours 133 hours 36 hours

16 hours 216 hours 58 hours

194 hours - - - - - - - - - - - - - - - -

Exposure Level

(Brightness)

Outdoor Sunlight

(50,000 lux)

Sunlight Through a

Window (10,000 lux)

Daylight Through a

Window on a Cloudy

Day (5,000 lux)

Indoor Fluorescent

Lighting (500 lux)

▲

▲

▲

• The above exposure time values are all for reference only. Actual required exposure

times depend on lighting conditions.

E-42

Adjusting Home Positions

Strong magnetism or impact can cause the hands of the watch to be off. If this

happens, perform the applicable home position adjustment procedures in this section.

• Hand home position adjustment is not required if the analog time and digital time are

the same in the Timekeeping Mode.

To adjust home positions

1. In the Timekeeping Mode, hold down A for about five seconds. You can release the

button after “H.SET” appears on the display.

• Though “ADJ” will appear on the display after about two seconds, do not release

the button yet. Keep it depressed until “H.SET” appears.

E-43

Correct hour and

minute hand positions

• The hour and minute hands should move to 12 o’clock

(their home position), and “0:00” will flash on the

display.

• If the hour and minute hands are not at 12 o’clock,

use D (+) and B (–) to move them there.

• Holding down either button will cause the hands to

move at high speed. Once started, high-speed hand

movement will continue even if you release the button.

To stop high-speed hand movement, press any button.

High-speed hand movement started with the D (+)

button will stop automatically after 12 revolutions of

the minute hand. If started with the B (–) button, it

will stop after one revolution of the minute hand.

2. After everything is the way you want, press A to return to the Timekeeping Mode.

• After performing home position adjustment, enter the Timekeeping Mode and check

to make sure that the analog hands and the digital display indicate the same time. If

they do not, perform home position adjustment again.

E-44

Reference

This section contains more detailed and technical information about watch operation.

It also contains important precautions and notes about the various features and

functions of this watch.

Button Operation Tone

The button operation tone sounds any time you press one of the watch’s buttons. You

can turn the button operation tone on or off as desired.

• Even if you turn off the button operation tone, alarms, the Hourly Time Signal, and

other beepers all operate normally.

E-45

To turn the button operation tone on and off

1.

In the Timekeeping Mode, hold down

A

for about two

seconds, until “ADJ” appears on the display.

• Your current Home City code will be flashing on the

screen.

2. Press C nine times until the current button operation

tone setting (

or ) appears.

3. Press D to toggle the setting between

(tone on)

and

(tone off).

4. Press A to exit the setting screen.

E-46

Power Saving Function

The Power Saving function enters a sleep state

automatically whenever the watch is left in an area for a

certain period where it is dark (except if the watch is in the

Stopwatch or Timer mode). The table below shows how

watch functions are affected by the Power Saving

function.

E-47

Elapsed Time in Dark

60 to 70 minutes

6 or 7 days

Display

Blank

Operation

All functions enabled, except for the display

• Beeper tone, illumination, and display disabled

• Analog timekeeping stopped at 12 o’clock

• Wearing the watch inside the sleeve of clothing can cause it to enter the sleep state.

• The watch will not enter the sleep state between 6:00 AM and 9:59 PM. If the watch

is already in the sleep state when 6:00 AM arrives, however, it will remain in the

sleep state.

To recover from the sleep state

Perform any one of the following operations.

• Move the watch to a well-lit area.

• Press any button.

E-48

Auto Return Features

• If you leave the watch in the Alarm Mode, or with the battery level indicator displayed

for two or three minutes without performing any operation, it automatically returns to

the Timekeeping Mode.

• If you leave the watch with a flashing setting on the display for two or three minutes

without performing any operation, the watch automatically exits the setting screen.

Scrolling

The B and D buttons are used in various modes and setting screens to scroll

through data on the display. In most cases, holding down these buttons during a scroll

operation scrolls through the data at high speed.

Initial Screens

When you enter the World Time Mode or Alarm Mode, the data you were viewing

when you last exited the mode appears first.

E-49

Timekeeping

• Resetting the seconds to 00 while the current count is in the range of 30 to 59

causes the minutes to be increased by 1. In the range of 00 to 29, the seconds are

reset to 00 without changing the minutes.

• The year can be set in the range of 2000 to 2099.

• The watch’s built-in full automatic calendar makes allowances for different month

lengths and leap years. Once you set the date, there should be no reason to change

it except after you have the watch’s battery replaced or when battery power drops to

Level 5.

• The current time for all city codes in the Timekeeping Mode and World Time Mode is

calculated in accordance with the Coordinated Universal Time (UTC) for each city,

based on your Home City time setting.

Illumination Precautions

• Illumination may be hard to see when viewed under direct sunlight.

• Illumination automatically dims if it is lit and an alarm or time up alarm sounds.

• Frequent use of illumination runs down the battery.
