Bruksanvisning Canon EF75-300mm F4-5.6 III Objektiv

Bruksanvisning

CT1-8532-003 1208SZ © CANON INC. 2006

●❻

●❼

4. Hood

The lens hood can keep unwanted light out of the lens, and

also protects the lens from rain, snow, and dust.

Fit the hood to the hood mount, then turn it in the direction

of the arrow to attach it securely

❻

.

The hood can be reverse-mounted on the lens for storage

❼

.

• Partofthepicturemaybeblockedifthehoodisnot

attached properly.

• Whenattachingordetachingthehood,graspthebaseof

the hood to turn it. To prevent deformation, do not grasp

the rim of the hood to turn it.

5. Filters

You can attach filters to the filter mounting thread on the

front of the lens.

• Onlyonefiltermaybeattached.

• UseapolarizingCanonfilter.

n

The lens length is measured from the mount surface to

the front end of the lens. Add 21.5 mm to include the

E-58 lens cap and dust cap, and 24.2 mm for the E-58 II.

n

Thesizeandweightlistedareforthelensonly,exceptas

indicated.

n

Aperture settings are specified on the camera. The

camera automatically compensates for variations in the

aperturesettingwhenthecameraiszoomedinorout.

n

AlldatalistedismeasuredaccordingtoCanon

standards.

n

Productspecificationsandappearancearesubjectto

change without notice.

n

Caseandhoodnotprovidedwithsomemodels.

n

Filters sold separately.

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

Do not make any changes or modifications to the equipment

unless otherwise specified in the instructions. If such changes

or modifications should be made, you could be required to stop

operation of the equipment.

This equipment has been tested and found to comply with the

limits for a class B digital device, pursuant to part 15 of the FCC

Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Consultthedealeroranexperiencedradio/TVtechnicianfor

help.

This Class B digital apparatus complies with Canadian ICES-003.

Specifications

Angle of view

Lens

construction

Minimum

aperture

Max.magnificationandfieldofview

Min. focusing

distance

Filter diameter

Max.diameter

and length

Weight Hood Case

Diagonal Vertical Horizontal

EF80-200mmf/4.5-5.6II 30°-12° 17°-7° 25°-10° 7-10 22-27

80mm:0.07X/368×548mm(14.5”×21.6”)

200mm:0.16X/152×225mm(6”×8.9”)

1.5m/4.92ft 52 mm

69×78.5mm

(2.7”×3.1”)

250g/8.8oz ET-54 LP1014

EF75-300mmf/4-5.6II 32°11’-8°15’ 18°11’-4°35’ 27°-6°50’ 9-13 32-45

75mm:0.07X/371×555mm(14.6”×21.9”)

300mm:0.25X/96×142mm(3.8”×5.6”)

1.5m/4.92ft 58 mm

73.8×122mm

(2.9”×4.8”)

500g/17.6oz ET-60 LP1019

EF75-300mmf/4-5.6III 32°11’-8°15’ 18°11’-4°35’ 27°-6°50’ 9-13 32-45

75mm:0.07X/372×558mm(14.6”×22”)

300mm:0.25X/95×142mm(3.7”×5.6”)

1.5m/4.92ft 58 mm

71×122mm

(2.8”×4.8”)

480g/16.8oz ET-60 LP1019

EF90-300mmf/4.5-5.6 27°-8°15’ 15°10’-4°35’ 22°40’-6°50’ 9-13 38-45

90mm:0.08X/311×464mm(12.2”×19.4”)

300mm:0.25X/95×141mm(3.7”×5.6”)

1.5m/4.92ft 58 mm

71×114.7mm

(2.8”×4.5”)

420g/14.8oz ET-60 LP1019

COPY
