Praktical Guidelines

Type of Water to be Used

This iron is designed for tap water. However, if

you have hard water we recommend to use a

mixture of 1/2 part tap water and 1/2 part distilled

water from drug stores or grocery stores.

Important

: Never use distilled water (battery

water). Do not add any additives (e. g. starch) to

the water.

To fill iron

1. Pull the plug out of the wall outlet.

2. Put the steam regulator

4

in position «

•

»

(= steam off).

3. Open sliding shutter

2

.

4. Place the iron in the upright position and fill

with water slowly through the tank opening

2

to the «max.» marking

L

(a), using the

beaker

q

.

5. Close sliding shutter.

Selecting the temperature

Connect the iron to a safely located wall outlet

and select the ironing temperature with the

temperature selector

1

(b). As soon as the pilot

light

8

goes out, the iron has reached the

temperature selected. To avoid water dripping,

always rest the iron upright while heating it up

keep the steam regulator

4

in position «

•

»

(= steam off) (c).

You will usually find the following symbols in your

garments:

The temperature selector

1

is marked with

these symbols:

min. The iron is connected

●

Synthetics (acrylic, acetate)

●●

Silk/rayon/nylon/polyester/

cotton blends/wool

●●●

Cotton/linen

max. Linen

Select the temperature you need according to

these symbols.

Spray, shot of steam, jet of steam

Before you start ironing, we recommend to press

the buttons 3 or 4 times, in order to activate

these functions.

Dry ironing

Set the steam regulator

4

in position «

•

»

(= steam off) (c) for dry ironing. The water

spray

7

may be used at any temperature

setting to dampen the laundry. The jet of steam

6

and the shot of steam

7

buttons can be

activated during dry ironing, provided that the

temperature selector

1

is within the continuous

red area

Steam ironing

(see «Table of features»)

Temperature selection

: Set the temperature

selector

1

within the red

range steam (b) and wait

until the iron has reached the selected

temperature (i. e. the pilot light

8

goes off).

Steam ironing is possible in the entire red range.

Steam ironing at lower temperatures may cause

water drops instead of steam. Should this

happen, turn the steam regulator

4

to the

position «

•

» (= steam off) (c).

Steam regulator

4

:

Select the quantity of

steam required (c) for

each garment with the

steam regulator

4

. You

can increase the quantity

by turning the steam

regulator clockwise (wide

markings) to the end of the red marking.

Caution: While ironing do not turn the steam

regulator further, otherwise hot water may come

out from the sole plate (see section

«Decalcifying/Self-cleaning»).

By turning the steam regulator anti-clockwise

you can reduce the quantity of steam or turn the

steam off «

•

» (= steam off) (see «Ironing

Guide»).

Constant steam

: Your braun steam iron ist

equipped with a special tank configuration to

provide constant steam even when the water

level in the tank is low.

Extra steam

*

(coming from the

steam vents in the sole

plate): For stubborn

creases and wrinkles,

collars and cuffs.

When ironing within

the red range

area the extra steam function can

be used. You can press the button

5

(d) for 3

seconds at intervals of no less than 15 seconds.

5

Jet of steam*

(coming from the outlets

p

at the slim pointed tip)

o

): Caution:

Keep children away from

the jet of steam and do

not hold your fingers in

front of the outlets

p

when activating this function.

When ironing within the red range

area the jet of steam function

6

can be used (e). To do so, press the button

6

at

intervals of no less than 5 seconds. The jet of

steam has been designed not only for steaming

hard to reach areas like pleats, inside of pockets

etc., but also for steaming hanging clothing (e. g.

velvet skirts, curtains, etc.) (g). The jet of steam

functions between horizontal and upright

positions. Be careful not to touch sensitive

textiles with the hot sole plate.

Shot of steam

*

(coming from the vents

in the sole plate):

When ironing within the

red area

the shot

of steam function can be

used. It gives an extra,

particularly powerful shot of steam penetrating

deep into the textiles in order to straighten

creases, collars and pleats. The function «shot

of steam» can be used in normal ironing and

also horizontally for steaming hanging clothing

(e. g. velvet skirts, curtains etc.) (g). Press the

shot of steam button

7

at intervals of no less

than 5 seconds. When steaming be careful not to

touch sensitive textiles with the hot sole plate.

* If pressed too frequently, it can drip. Should this

happen, wait a few seconds before using it

again.

Spray

(coming from the

nozzle

3

): The spray

function can be used at

any temperature, to

dampen laundry. To do

so, press the button

7

(water spray = blue).

Spray / shot of steam

2-function button:

With the models 2210 and

2212 the functions «water

spray» and «shot of

steam» can be activated

with a 2-function button.

The desired function can

be selected by turning the

button

7

as far as it will

go. The marking (blue =

water spray or red = shot

of steam) must point to

the respective function (f).

Turn the button from blue

(spray) to red (shot of

steam) anti-clockwise

and from red to blue clockwise (f).

Storage

After ironing, always pull the plug out of the wall

outlet. Set the temperature selector

1

to «min.»

(b) and the steam regulator

4

to «

•

» (= steam

off) (c).

To empty the iron hold it with the open water tank

opening

2

downwards (h) and shake it 1 or 2

times. The pivoting cord

9

conveniently winds

up around the cord storage

k

.

IMPORTANT

: Store the cool steam iron in a dry

place and always standing on its heel rest

j

.

The sole plate may be damaged by remaining

water if it is stored horizontally. The warranty

does not cover faults or damage resulting from

improper storage of the iron.

Maintenance and Cleaning

To remove residues of minerals/starch from the

sole plate always use steel wool. Never use a

scouring pad, vinegar or other chemicals. The

steam vents

m

and jet of steam outlets

p

may

be cleaned manually with a toothpick, if

necessary. Clean the sole plate regularly if you

use starch or other aids on the clothes for

ironing.
