6 | English

u Keep cutting tools sharp and clean. Properly main-

tained cutting tools with sharp cutting edges are less

likely to bind and are easier to control.

u Use the power tool, accessories and tool bits etc. in

accordance with these instructions, taking into ac-

count the working conditions and the work to be per-

formed. Use of the power tool for operations different

from those intended could result in a hazardous situation.

u Keep handles and grasping surfaces dry, clean and

free from oil and grease. Slippery handles and grasping

surfaces do not allow for safe handling and control of the

tool in unexpected situations.

Service

u Have your power tool serviced by a qualified repair

person using only identical replacement parts. This

will ensure that the safety of the power tool is maintained.

Safety instructions for jigsaws

u Hold the power tool by insulated gripping surfaces,

when performing an operation where the cutting ac-

cessory may contact hidden wiring or its own cord.

Cutting accessory contacting a "live" wire may make ex-

posed metal parts of the power tool "live" and could give

the operator an electric shock.

u Use clamps or another practical way to secure and

support the workpiece to a stable platform. Holding

the workpiece by hand or against your body leaves it un-

stable and may lead to loss of control.

u Keep hands away from the sawing area. Do not reach

under the workpiece. Contact with the saw blade can

lead to injuries.

u Only bring the power tool into contact with the work-

piece when switched on. Otherwise there is danger of

kickback if the cutting tool jams in the workpiece.

u Ensure that the footplate always rests securely while

sawing. A jammed saw blade can break or lead to kick-

back.

u When the cut is completed, switch off the power tool

and then pull the saw blade out of the cut only after it

has come to a standstill. In this manner you can avoid

kickback and can place down the power tool securely.

u Always wait until the power tool has come to a com-

plete stop before placing it down. The application tool

can jam and cause you to lose control of the power tool.

u Use only undamaged saw blades that are in perfect

condition. Bent or dull saw blades can break, negatively

influence the cut, or lead to kickback.

u Do not brake the saw blade to a stop by applying side

pressure after switching off. The saw blade can be dam-

aged, break or cause kickback.

u Use suitable detectors to determine if utility lines are

hidden in the work area or call the local utility com-

pany for assistance. Contact with electric lines can lead

to fire and electric shock. Damaging a gas line can lead to

explosion. Penetrating a water line causes property dam-

age or may cause an electric shock.

Products sold in GB only:

Your product is fitted with an BS 1363/A approved electric

plug with internal fuse (ASTA approved to BS 1362).

If the plug is not suitable for your socket outlets, it should be

cut off and an appropriate plug fitted in its place by an au-

thorised customer service agent. The replacement plug

should have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible

shock hazard and should never be inserted into a mains

socket elsewhere.

Product Description and

Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-

structions may result in electric shock, fire

and/or serious injury.

Please observe the illustrations at the beginning of this oper-

ating manual.

Intended Use

The power tool is intended for making separating cuts and

cut-outs in wood, plastic, metal, ceramic plates and rubber

while resting firmly on the workpiece. It is suitable for

straight and curved cuts with mitre/bevel angles of up to

45°. Note the saw blade recommendations.

Product Features

The numbering of the product features refers to the diagram

of the power tool on the graphics page.

(1)

Stroke rate preselection thumbwheel (GST80PBE)

(2)

On/off switch

(3)

On/off switch locking mechanism

(4)

Hex key

(5)

Sawdust blower device switch

(6)

Pendulum action adjusting lever

(7)

Base plate

(8)

Guide roller

(9)

Saw blade

A)

(10)

Shock protection guard

(11)

Handle (insulated gripping surface)

(12)

Screwdriver

(13)

Lifting rod

(14)

Anti-splinter guard

A)

(15)

Scale for mitre/bevel angles

(16)

Base plate screw

(17)

Positioning cam/mark

(18)

Threaded hole for the base plate

(19)

Guide for parallel guide

(20)

Locking screw for parallel guide

A)

1 609 92A 514 | (26.03.2019) Bosch Power Tools
