Bruksanvisning Acros AT091FG Kyl-frys

Bruksanvisning

Replace the tank:

Fit and lock the valve again, as shown in the fi gure.

Important:

Before replacing the tank, verify that the

valve is correctly installed.

Install the tank on the side hooks

and in the hole in the door.

Verify that the tank is fi rmly installed.

Note the absence of spaces between the

support and the door.

Water dispenser (some models)

Your refrigerator has a system that allows you to dispense cold water without

opening the door, thus avoiding excessive door openings, consequently,

reducing energy consumption.

Filling tank:

To fi ll up water in the tank, turn the lid on and fi ll

it with a jug.

After fi lling, close the funnel cover, turning it to

the initial (closed) position.

Important:

Exclusive use for water.

Any other liquid may cause malfunction of the product.

Only use potable water to fi ll the tank.

The manufacturer is not responsible for damage caused to the system if the

tank is supplied with any other type of liquid other than water.

Dispensing water:

Press a container or a glass against the lever until the

desired level of water is completed.

The container to collect water retains any

drops that may fall while you are dispensing water.

Use a dry cloth to clean or dry the container to collect water.

Cleaning the tank:

Clean the tank frequently. For cleaning, never use the

dishwasher. Remove the water tank by turning it and

withdrawing it in the direction indicated in the fi gure.

Hold the tank and remove the lid.

Disengage the tip of the valve by turning it to the

left until you feel that the piece is loose.

Remove it and clean it carefully.

Use sponge or soft cloth moistened with

detergent or neutral soap. Rinse well

and dry with a clean dry cloth.

Important:

Do not remove the body of the

valve, indicated in the fi gure.

Tank

Turn the funnel lid outwards to fi ll the tank

Recipient to

collect water

Lever

VERY IMPORTANT

IT IS THE RESPONSIBILITY OF THE USER TO VERIFY THE FOLLOWING

INFORMATION BEFORE CALLING THE TECHNICIAN:

If you followed the instructions in the installation, use and care manual

correctly, and have questions about the operation of the refrigerator, this guide

offers solutions to problems you can detect and correct in your home.

IF THE REFRIGERATOR DOES NOT WORK

• Connect the plug directly, DO NOT USE CORD EXTENSIONS.

• Check the ELECTRICAL CONTACT, IT COULD BE DAMAGED, connect

another device and test if it works.

• Avoid starting several devices at the same time; THE ELECTRICAL

INSTALLATION MAY OVERLOAD.

• Verify that the TEMPERATURE CONTROL IS IN THE ON-OFF POSITION.

• Make sure the refrigerator is NOT NEXT TO A HEAT SOURCE such as an

oven, stove or direct sunlight.

• THE DOORS MUST CLOSE HERMETICALLY, check the magnetic gasket of

the doors.

• LEVEL THE REFRIGERATOR, remove the wooden bases and adjust the

leveling screws (fi gure 1).

• DO NOT OVERLOAD THE REFRIGERATOR, the circulation of cold air will

be defi cient.

• Set the TEMPERATURE control knob to MED (medium cold) and wait at least

24 hours before making a new temperature change.

YOU HAVE NOTICED THAT THE REFRIGERATOR WORKS FOR

EXTENDED PERIODS

• Check that the CONDENSER IS FREE OF DUST AND LINT (fi gure 1)

• AVOID OPENING THE DOOR CONTINUOUSLY or for prolonged periods.

• DO NOT STORE HOT FOODS and keep them covered.

IF YOU HEAR STRANGE SOUNDS

• Check that there are NO OBJECTS OVER OR BEHIND THE REFRIGERTOR.

• The COMPRESSOR DOES NOT WORK PROPERLY, it may be that a low

voltage is present, verify the intensity of the light, if it is low this indicates

that it has a low voltage, speak to your company of light to correct the power

supply (fi gure 1).

MAGNETIC GASKET

LEVELING SCREWS

CONDENSER

COMPRESSOR

IF AFTER FOLLOWING

THESE INSTRUCTIONS,

THE REFRIGERATION IS

MALFUNCTIONING, PLEASE

CONTACT OUR TECHNICAL

SUPPORT CENTER

Figure 1

Remove the shelves

Adjust the refrigerator’s racks according to the way the refrigerator is used.

To remove the shelves:

1. Remove all items from the shelves.

2. Lift the top.

3. Slide the grill out.

To replace the shelves:

1. Place the back of the shelf

on the rails located on the side walls.

2. Guide the front of the grill onto the rails.

3. Slide it in until it stops.

How to use the multi position rack

1. Remove all items from the rack.

2. Grab the rack with both hands from the bottom

part and slide upwards and out as indicated on the

image. Release and reposition.

How to use the Crisper drawer

Do not pull out the crisper drawer. Turn down the

drawer as the image.

For cleaning, lift slightly and slide towards you until

release.

Noises that you may hear

Your new refrigerator may can make sounds, most of them are normal, but hard

surfaces like the fl oor, kitchen walls and the refrigerator itself can make them

more noticeable.

Soft whisper, soft whistling

These can be the fan and the air moving.

Knocking sounds or rattle noises

The thermostat emits a well-defi ned knock like sound when the refrigerator

stops and when it starts to work again.

The defroster control clock also emits the same type of sound when the defrost

cycle begins.

Sounds of water

After the refrigerator stops, a drip in the pipeline can be heard for a few

minutes.

Water can also be heard running into the water collection tray and a peculiar

sound like water falling on a hot surface during defrosting cycles.

Before calling the technician

How to replace the light bulb

1. Unplug the refrigerator or disconnect power

supply.

2. Replace the light bulb using another one with

for refrigerators (15 W).

3. Plug refrigerator o reconnect power supply.

NOTE: Do not use any light bulb, make sure

to replace the light bulb with a similar

light bulb suitable for refrigerators.

autorizado o por personal calficado con el fin de evitar un peligro.

Este aparato no se destina para utilizarse por personas (incluyendo niños) cuyas capacidades fisicas,

sensoriales o mentales sean diferentes o esten reducidas, o carezcan de experiencia o conocimiento,

a menos que dichas personas reciban una supervision o capacitacion para el funcionamiento del aparato

por una persona responsable de su seguridad.

No utilizar extensiones o adaptadores sin puesta a tierra.

No almacene o use gasolina, gases inflamables o sustancias explosivas tales como latas de aerosol con un agente

inflamable dentro o cerca de este o cualquier electrodoméstico, los vapores pueden causar incendios o explosiones.

Este aparato está destinado para utilizarse en aplicaciones domésticas y similares, tales como:

Áreas de cocina para personal que labora en tiendas, oficinas y otros ambientes de trabajo;

Granjas, hoteles, moteles y otros ambientes tipo residencial;

En ambientes tipo alojamiento y desayuno;

Para la preparación de alimentos y aplicaciones comerciales similares.

Fabricado por

Industrias Acros Whirlpool, S. de R.L. de C.V.

Carretera Panamericana km. 280,

Celaya Gto. Tel. (461) 618 55 00

W11347791 Rev. A STM W11226608 Rev. B

AT9007G, AT091FG, AT091FA, AT096FG, AT091FQ

d

Accesorio de alambrón

ENGLISH - 4

ESPAÑOL - 1

MANUAL W11347791 - W11354968.indd 1-2MANUAL W11347791 - W11354968.indd 1-2 24/04/19 15:1824/04/19 15:18
