Bruksanvisning

e

W11354968 Rev. A

This manual contains useful information, please read it carefully.

Manufactured by:

Industrias Acros Whirlpool

Address:

Carretera Panamericana km. 280

Celaya Gto. Tel: 461 618 55 00

STM W11354975 Rev. A

Use and Care

Guide

Nominal current

Electrical frequency

Voltage

THIS DOCUMENT COVERS THE FOLLOWING MODELS FROM THE

WHIRLPOOL BRAND:

AT9007G, AT091FG, AT091FA, AT096FG, AT091FQ

1.0 A

60 Hz

127 V~

Technical features

In order to reduce the risk of fi re, electric

shock or personal injury when using your

refrigerator, follow these basic precautions:

• Read all the instructions carefully before using your refrigerator.

• Leaving a refrigerator abandoned can cause that someone may get

stuck in it while playing around and suffocate.

• If you are planning on changing your refrigerator, please do it in a safe

way for everyone.

• We recommend removing the refrigerator doors of your old unit at

disposal or at least, secure the doors with a resistant rope.

• Never leave the refrigerator unattended for unexperienced children to

play with it or walk in the refrigerator.

• Never clean the refrigerator parts with fl ammable liquids; the fumes may

cause fi re or explosions.

• This appliance is not intended for use by persons (including children

whose physical, sensory or mental abilities are different or reduced, or

lack experience or knowledge, unless such persons receive supervision

or training for the operation of the device by a person responsible for your

safety.

• Do not use extensions or adapters without an electrical ground terminal.

• Children must be supervised around the refrigerator.

Make sure the refrigerator is not used as a toy.

FOR YOUR SAFETY

• Do not store gasoline or any other fl ammable gases or explosive substances

(such as aerosol cans) around this or any other kitchen appliance.

Fumes may cause fi re or explosions.

• If the electrical cord is damaged, this must be replaced by the manufacturer,

authorized repair service technician or by someone qualifi ed. Avoid risks.

• This device is intended for use in domestic and similar applications, such as:

a) Kitchen areas for personnel working in stores, offi ces and other work

environments;

b) Farms, hotels, motels and other work environments;

c) In bed and breakfast type environments;

d) For the preparation of food and similar commercial applications.

KEEP THESE INSTRUCTIONS

Risk of Electrical Shock

This appliance must be connected to an electrical ground.

Do NOT modify the electrical cord. If the electrical plug

doesn’t fi t, have a qualifi ed electrician to install a proper

electrical outlet on the wall.

Do NOT use a cord extension for this refrigerator.

Contact a qualifi ed electrician if you have doubts about the

electrical grounding of the refrigerator.

Not following these precautions correctly may cause injury

or even death.

Important Safety Instructions

Electrical grounded wall

outlet for 3-prong plugs

Electrical plug with

3 terminals

Electrical

cord

Electrical ground

terminal

Correct Installation

Before plugging your refrigerator to a power supply

• Keep the refrigerator away from outdoor weather.

• Plug the refrigerator only in an electrical grounded wall outlet.

Make sure power supply is within the accepted standards.

• Do not store food in the refrigerator before allowing some time

for the refrigerator to cool.

• Only use the refrigerator as it’s been specifi ed in this guide.

How to install the refrigerator

Follow these steps before turning on your new refrigerator:

1. Remove all accessories and shelves from inside.

2. Place the refrigerator under the following recommendations:

• Leave a minimum space of 3” (7,5 cm) between top of the refrigerator and

the cabinets.

• Leave at least a space of 2” (5 cm) between the refrigerator condenser on

the back of the fridge and the wall.

• Leave a space of 1/2” (1,25 cm) on each side of the refrigerator to ease

installation.

• If the refrigerator will be placed against a side wall,

leave some additional space to allow the door to

open.

3. Level the refrigerator.

• Follow these instructions to rise or lower the height of

the refrigerator. See Figure 1.

• For more accuracy, check the level using a level

on top of the refrigerator. Check if the refrigerator

rocks back to front or side to side when closing and

opening the door. Adjust if needed.

• We recommend leaving the refrigerator slightly

leaned back, so the door can close by itself.

4. Let the refrigerator stand for 2 to 3 hours before

connecting to a power supply, this will allow the gas

and oil to settle before starting the cooling process

Plug the refrigerator

The voltage required for its operation is 127 V~ at a

nominal frequency of 60 Hz. Use 15 or 20 A fuses.

Leveling

screw

Lower

Rise

Leveling

screw

Lower

Rise

Figure 1

Instructions to connect to ground

Procedure for electrical grounding

Your refrigerator is equipped with an electric

cord provided with a 3-terminal grounding

plug. To reduce the possibility of electric

shock to a minimum, the cord must be

connected to an electrical grounded wall

outlet for 3-prong plugs. The installation

must be grounded in accordance with the

National Electric Code and all local codes

and regulations.

If there is no outlet of this type, it is the responsibility and obligation of the

customer to install a wall outlet with 3 terminals and properly grounded by a

qualifi ed electrician.

How to use the refrigerator

Adjust temperature control

Your refrigerator has 2 controls that allow you to regulate the temperature in

the refrigerator and freezer compartment independently.

When you connect for the fi rst time:

• Set the refrigerator and freezer temperature controls to the Cold Medium

position ( ). Controls range from less cold ( ) to colder ( ).

• Moving the refrigerator control to OFF

stops the freezer and refrigerator from

cooling but does not disconnect from

electricity.

• Allow the refrigerator time to cool

completely before putting food in it.

Its cooling may take several hours.

Adjust the temperature control to keep

the food as cold as you want.

The positions suggested above are the

correct ones for normal home use.

Cold

Colder

Freezer

Cold

Colder

OFF

Refrigerador

Shelf extension accessory

This is a useful and practical accessory to store products

on 2 different heights

• Schedule maintenance for your refrigerator.

• This refrigerator is intended for domestic use only.

• This device is intended for use in domestic and similar applications, such as:

Kitchen areas for personnel working in stores, offi ces and other work

environments;

Farms, hotels, motels and other work environments;

In bed and breakfast type environments;

For the preparation of food and similar commercial applications.

Solo utilizar agua potable para llenar el tanque

MUY IMPORTANTE

ES RESPONSABILIDAD DEL USUARIO VERIFICAR LA SIGUIENTE INFORMACIÓN ANTES DE LLAMAR AL TÉCNICO:

Si usted siguió correctamente las instrucciones del manual de instalación, uso y cuidado, y tiene preguntas sobre el

funcionamiento del refrigerador, esta guía le ofrece soluciones a problemas que puede detectar y corregir en su hogar.

SI EL REFRIGERADOR NO FUNCIONA

•Conecte directa y correctamente la clavija, NO USE EXTENSIONES.

•Revise EL CONTACTO ELÉCTRICO, PODRÍA ESTAR DAÑADO, conecte otro aparato y pruebe si funciona.

•Evite poner a funcionar varios aparatos a la vez; LA INSTALACIÓN ELÉCTRICA SE SOBRECARGA.

•Verifique que el CONTROL DE TEMPERATURA ESTÁ EN POSICIÓN DE ENCENDIDO.

•Asegúrese de que NO ESTÉ JUNTO A UNA FUENTE DE CALOR como horno, estufa o luz directa del sol.

•LAS PUERTAS DEBEN CERRAR HERMÉTICAMENTE, revise el empaque magnético de las puertas.

•NIVELE EL REFRIGERADOR, retire las bases de madera y ajuste los tornillos niveladores (FIGURA 1).

•NO SOBRECARGUE EL REFRIGERADOR, la circulación de aire frío será deficiente.

•Coloque la perilla de control de TEMPERATURA EN MED (frío medio) y espere por lo menos 24 horas antes de hacer un

nuevo cambio de temperatura.

NOTA QUE EL REFRIGERADOR TRABAJA POR PERIODOS PROLONGADOS

•Verifique que el CONDENSADOR ESTÉ LIBRE DE POLVO Y PELUSA (FIGURA 1).

•EVITE ABRIR CONTINUAMENTE LA PUERTA o por periodos prolongados.

•NO INTRODUZCA ALIMENTOS CALIENTES y manténgalos tapados.

SI ESCUCHA SONIDOS EXTRAÑOS

•Revise que NO HAYA OBJETOS SOBRE O DETRÁS DEL REFRIGERADOR.

•EL COMPRESOR NO TRABAJA CORRECTAMENTE, puede ser que un bajo voltaje estuviera presente. Verifique la intensidad

de la luz, si es baja esto nos indica que tiene un bajo voltaje, hable a su compañía de luz para que corrijan el suministro de

energía (FIGURA 1).

FIGURA 1

CONDEN

-SADOR

EMPAQUE

MAGNÉTICO

TORNILLOS

NIVELADORES

COMPRESOR

SI DESPUÉS DE SEGUIR LAS

INSTRUCCIONES

DE ESTA GUÍA, EL REFRIGERADOR

NO FUNCIONA LLAME A

LOS CENTROS DE SERVICIO

INDICADOS

Antes de llamar al técnico

ENGLISH - 3ESPAÑOL - 2
