15) Repeat with the second BLACK

RA/RB pole at the front of the tent.

Thread the RB pole through the

outermost of the 3 holes on the

BLACK R3 pole. If the roof is too tight

move back one hole before threading

through the eyelet in the roof. Ensure

the end of the BLACK R3 pole

extends out through the pocket on

the front wall. Attached the Velcro

strips on the front wall around the

pole.

17) Insert the BLACK R4 / R5

pole into the end of the R3 pole

that extends through the pole sock

at the front of the tent.

1) Clear your site making sure there

are no sharp objects. Try to choose

a site that is flat and clear.

2) Sort the poles into their matching

colour. Once sorted, connect each

colour pole length together as per

the pole chart.

3) Spread your tent out with floor

facing down. The front is the end

with the large awning roof

attached.

4) Peg out the four corners of the

tent. Pull the floor as tight as

possible. To ensure the floor sits flat it

may be easier to peg in the

following sequence. Pegs should

be at a 45

o

angle away from the

tent for greatest hold.

7) Thread the BLUE E1 pole

through the sleeve that runs along

the RHS of the tent. Thread the

poles from the rear of the tent

inserting the pole through the black

webbing loop before threading

through the pole sleeve and place

behind the button pin on the pole.

EB

EA

EB

EA

9) Cover the pole by wrapping the

end of the pole sleeve over the

pole sock and attach the Velcro.

11) Insert the remaining BLUE EA

and EB poles into the end of each

section and raise the pole so that

the outside wall sits taught. You will

need two people to do this.

5) Peg out the remaining peg

points ensuring the floor sits flat.

#1

#2

#3

#4

8) At the front of the tent thread

the BLUE E2 pole up through the

pole sock on the side of the front

awning from the inside to the

outside. Thread through the black

webbing loop before inserting into

the pole sleeve and connecting to

the E1 pole. Loop webbing over

button pin.

6) Open all doors and windows.

This allows air to enter the tent and

makes pitching easier.

10) Repeat with the GREEN pole

RA

RB

13) Thread the BLACK R1 to R3

poles inside the tent by threading

through the pole sock at the top of

the front wall.

14) Insert the BLACK RB/RA

pole into the hole at the end of the

R1 pole and then through the

eyelet at the rear of the roof and

extend until the wall sits tight.

Attach the Velcro strips on the rear

wall.

12) Repeat with the GREEN EA

and EB poles.

RA

RB

16) Place white “Witch Hat” spike

washers onto pole spikes of both

RB poles to prevent water running

down during heavy rain.

R3

R1

E1

E1

E2

E1

E2

EB

EA

EB

EA

R2

R3

R1

R5

R4

ATLAS

/////////

CANVASSERIES

FREEDOM

CAMPING

BY
