Before using your dishwasher for the first time:

1. Ensure that the electrical and water connections comply

with the installation instructions

2. Remove all packaging from inside the appliance

3. Set the water softener

4. Pour 1 litre of water inside the salt container and then fill

with dishwasher salt

5. Fill the rinse aid dispenser

The water softener

The dishwasher is equipped with a water softener designed to

remove minerals and salts from the water supply, which would

have a detrimental or adverse effect on the operation of the

appliance.

The higher the content of these minerals and salts, the harder

your water is.

Water hardness is measured in equivalent scales, Clarke

degrees, French degrees and mmol/l (millimol per litre).

The softener should be adjusted according to the hardness of

the water in your area. Your local Water Authority can advise

you on the hardness of the water in your area.

The water softener must be set in both ways: manually, using

the water hardness switch and electronically, using the function

push buttons on the control panel.

a) Setting manually

1. Open the dishwasher door.

2. Remove the lower basket from the dishwasher.

3. Turn the water hardness switch to position 1 or 2 (see

table).

4. Replace the lower basket.

The dishwasher is factory set

at position 2.

b)Setting electronically

(The dishwasher must be switched off)

The dishwasher is factory set at level 5.

1. Press the On/Off push button. All programme selection push

buttons indicator lights will illuminate (setting mode).

If only one programme selection push button indicator light

is illuminated, this means that a washing programme has

been selected.

The programme must be cancelled: press simultaneously

the function push buttons 2 and 3 for about 2 seconds, the

indicator light of the set programme push button starts

flashing for about 2 seconds. After about 2 seconds the

indicator lights of all the programme selection push buttons

will illuminate indicating that the set programme has been

cancelled and that the machine is now in setting mode.

2. Press simultaneously function push buttons 2 and 3, until

the indicator lights of the function push buttons 1, 2 and 3

start flashing.

3. Press the function push button 1, the indicator lights of

function push buttons 2 and 3 turn off while the indicator

light of the push button 1 goes on flashing, at the same time

the END OF CYCLE indicator light illuminates, along with a

sequence of audible signals.

The current level is indicated by the number of flashes of

the END OF CYCLE indicator light and of audible signals

heard.

Example:

5 flashes + 5 audible signals = level 5.

4. To change the level, press push button 1. Each time the

push button is pressed the level changes. (For the selection

of the new level see the chart).

Examples:

if the current level is 5, by pressing push button 1 once,

level 6 is selected.

if the current level is 10, by pressing push button 1 once,

level 1 is selected.

5. To memorise the operation, switch off the dishwasher by

pressing the On/Off push button or wait about 60 seconds

after which the dishwasher will automatically return to

setting mode.

Prior to using for the first time

6

AA07

Clarke

degrees

°TH

(french degrees)

mmol/l

(millimol per litre,

international unit for the

hardness of water)

Range

manually

electronically

64 - 88

53 - 63

46 - 52

36 - 45

28 - 35

23 - 27

18 - 22

13 - 17

5 - 12

< 5

9,0 - 12,5

7,6 - 8,9

6,5 - 7,5

5,1 - 6,4

4,0 - 5,0

3,3 - 3,9

2,6 - 3,2

1,9 - 2,5

0,7 - 1,8

< 0,7

IV

IV

IV

IV

IV

III

III

II

I/II

I

91 - 125

76 - 90

65 - 75

51 - 64

40 - 50

33 - 39

26 - 32

19 - 25

7 - 18

< 7

2

2

2

2

2

2

1

1

1

1

level 10

level 9

level 8

level 7

level 6

level 5

level 4

level 3

level 2

level 1

yes

yes

yes

yes

yes

yes

yes

yes

yes

no

10

9

8

7

6

5

4

3

2

1

Water hardness

Adjusting

the water

hardness setting

Use

of salt

Number of flashes of

the END OF CYCLE

indicator light and of

audible signals
