120v
LITHIUM-ION
TM
4 5
DESCRIPTION OF PRODUCT PARTS
Parts list (See Fig. 1)
1. Flat nozzle
2. Control panel
3. Speed/Cruiser lock lever
4. Trigger Switch
5. Support Harness Hook
6. Battery Pack Release Button
7. Air Inlet
8. Main Handle
9. Upper Tube
10. Lower Round Nozzle
Carefully remove the machine and parts from its
packaging. Identify all the parts packaged in the
carton against the parts list. Please contact our
customer service center (Monday - Friday 8:30AM
- 5:00PM ET) at (866) 902-9690 if anything is
missing.
Parts included (See Fig. 2)
A. Power head assy. x 1
B. Lower round nozzle x 1
C. Lower flat nozzle x 1
D. Support harness x 1
E. Manual x 1
WARNING: If any parts are damaged or
missing, do not operate this tool until the missing
parts are replaced. Failure to heed this warning
could result in serious personal injury.
NOTE! Always recycle the packaging in
accordance with local recycling laws.
TECHNICAL SPECIFICATIONS
Item No. Y0LBX145T00
Voltage/Capacity 120 V DC / 2.5 Ah Li-ion
Running Speed 3 Speed settings
Max. Air Speed 145 MPH
Max. Air Volume 580 CFM
Motor
Brushless
Charger
Input: 100~120 V, 50/60 Hz,
Output: 120 V DC, 4 A
Charging Time
40 Minutes
Weight 14.1 lbs.
Battery pack type
Y0L120BAT2.5 (not included)
Charger type
Y0L120CGR (not included)
INTENDED USE
The blower is intended for use to blow / sweep
grass, yard debris, leaves, paper and similar
objects around a residential yard. Do not operate
your blower indoors. Do not use the blower for
any other purpose because of the increased risk
or accidents and damage to the blower. Never
attempt to modify the blower in any way.
The machine is to be used only for its prescribed
purpose. any other use is deemed to be a
case of misuse. The user/operator and not the
manuafacturer will be liable for any damage or
injuries of any kind caused as a result of this.
SAFETY SYMBOLS
The purpose of safety symbols is to attract your
attention to possible dangers. The safety symbols
and the explanations with them deserve your
careful attention and understanding. The symbol
warnings do not, by themselves, eliminate any
danger. The instructions and warnings they give
are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and
understand all safety instructions in this
Operator’s Manual, including all safety alert
symbols such as “DANGER,” “WARNING,”
and“CAUTION” before using this tool. Failure to
following all instructions listed below may result in
electric shock, re, and/or serious personal injury.
DAMAGE PREVENTION AND INFORMATION
MESSAGES
These inform the user of important information
and/or instructions that could lead to equipment
or other property damage if they are not
followed. Each message is preceded by the word
“NOTICE”, as in the example below:
NOTICE: Equipment and/or property damage
may result if these instructions are not followed.
Fig. 3
Fig. 5
Fig. 7
Fig. 4
Fig. 6
Fig. 8
Fig. 9
120v
LITHIUM-ION
TM
120V Battery Pack
Max. 113 F
120V Battery Pack Model: YF120BAT2.5
Merotec Inc. 3655 Kennesaw North Industrial
Use and store indoors only.
WARNING
Made in China at a SUMEC manufacturing facility.
Voltage: 120 V D.C. Battery Capacity: 2.5 Ah
E331782
GARDENING APPLIANCE
Use only for SUMEC 120V charger YF120CGR.
Parkway, Kennesaw, GA30144
120v
LITHIUM-ION
TM
120v
LITHIUM-ION
TM
120v
LITHIUM-ION
TM
120v
LITHIUM-ION
TM
120v
LITHIUM-ION
TM
120v
LITHIUM-ION
TM
Fig. 10
