12 AMP 3-in-1 Blow/Vac/Mulch EN
3
Table 1
Minimum gauge for extension cords
Ampere
rating
Volts
Total length of cord
25ft
(7.62m)
50ft
(15.24m)
100ft
(30.48m)
150ft
(45.72m)
More
than,
Amps
Not
more
than,
Amps
120V AWG(mm
2
)
10 12 -
18(0.82) 16(1.3) 14(2.1) 12(3.3)
Figure 1
Method of securing extension cord
CORD
SET
APPLIANCE CORD
(A) TIE CORD AS SHOWN
(B) CONNECT PLUG AND
RECEPTACLE
FOR ALL DOUBLE-
INSULATED APPLIANCES
1) Replacement Parts
When servicing use only identical replacement parts.
2) Polarized Appliance Connections
To reduce the risk of electric shock, this appliance has
a polarized plug (one blade is wider than the other)
and will require the use of a polarized extension
cord. The appliance plug will fit into a polarized
extension cord only one way. If the plug does not
fit fully into the extension cord, reverse the plug. If
the plug still does not fit, obtain a correct polarized
extension cord. A polarized extension cord will
require the use of a polarized wall outlet. This plug
will fit into the polarized wall outlet only one way.
If the plug does not fit fully into the wall outlet,
reverse the plug. If the plug still does not fit, contact
a qualified electrician to install the proper wall outlet.
Do not change the equipment plug, extension cord
receptacle, or extension cord plug in any way.
SAVE THESE
INSTRUCTIONS
ADDITIONAL SAFETY
WARNINGS
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions
should always be followed, including the following:
READ ALL INSTRUCTIONS
BEFORE USING THIS
APPLIANCE
WARNING – To reduce the risk of fire,
electric shock, or injury:
1)
Do not leave appliance when plugged in. Unplug
from outlet when not in use and before servicing.
2)
To reduce the risk of electric shock – Do not use on
wet surfaces. Do not expose to rain. Store indoors.
3) Do not allow to be used as a toy. Close attention
is necessary when used by or near children.
4) Use only as described in this manual. Use only
manufacture’s recommended attachments.
5) Do not use with damaged cord or plug. If
appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped
into water, return it to a service center.
6)
Do not pull or carry by cord, use cord as a handle,
close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord.
Keep cord away from heated surfaces.
7)
Do not handle plug or appliance with wet hands.
8) Do not put any object into openings. Do not use
with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce air flow.
9) Keep hair, loose clothing, fingers, and all parts of
body away from openings and moving parts.
10) Turn off all controls before unplugging.
11) Use extra care when cleaning on stairs.
12) Do not use to pick up flammable or combustible
liquids, such as gasoline, or use in areas where
they may be present.
13)
Do not pick up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
14)
Do not use without dust bag and/or filters in place.
15) Do not unplug by pulling on cord. To unplug,
grasp the plug, not the cord.
16) This appliance is provided with double
insulation. Use only identical replacement
parts. See instructions for Servicing of Double-
Insulated Appliances.
