2

Freezing fresh food

• Place foods to be frozen in direct contact with the walls

of appliance:

A) - foods to be frozen,

B) - foods already frozen.

• Avoid placing foods to be frozen in direct contact with

food already frozen.

• For best and fastest freezing, foods should be split into

small portions; this will also be useful when the frozen

items are to be used.

• If minimum quantities of food are introduced (up to 1/4

of the maximum freezing power stated on the rating

plate), the operation of the appliance will be controlled

automatically by the “6th Sense” function without any

need for intervention from the user.

• When freezing higher quantities of food, up to the

maximum freezing capacity of the appliance, indicated

on the rating plated, proceed as follows:

1. At least 24 hours before storing fresh foods inside the

product for freezing, activate the fast freezing function

by pressing (4) for approximately 3 seconds. The

green LEDS (3) ash in sequence.

2. Introduce the food to freeze inside the appliance, and

keep the door of the appliance closed for 24 hours.

After this period the food will be frozen.

The fast freezing function can be deactivated manually by

pressing (4).

If the fast freeze function is not manually deactivated, it

will be automatically deactivated by the appliance after

50 hours.

FOOD STORAGE

Refer to the table on the appliance.

Classication of frozen foods

Load and classify the frozen foods; it is advisable

to indicate the storage date on the packs, to ensure

consumption before the expiry dates listed in months in

Fig. 6 for each type of food.

Advice for storing frozen food

When buying frozen food, make sure that:

• The packaging is intact (food in damaged containers

may have deteriorated). If a package is swollen or has

damp patches, the product may not have been stored

in optimum conditions and therefore undergone partial

defrosting.

• When shopping, leave frozen food purchases until last

and carry them in a thermally insulated bag.

• On arriving home, immediately place the frozen food in

the appliance.

• Avoid or minimise temperature variations. Observe the

expiry date on the packaging.

• Always follow the storage instructions on frozen food

packages.

Note:

Eat fully or partially defrosted foods immediately.

Do not refreeze unless the food is cooked after it has

thawed. Once cooked, the food can be refrozen.

In case of a prolonged power failure:

• Do not open the appliance door, except to place ice

packs (if provided) over the frozen foods on the right and

left side of the appliance. This will slow down the rise

in temperature.

APPLIANCE DEFROSTING

The appliance should be defrosted when the thickness of

ice on the walls reaches 5-6 mm.

• Disconnect the appliance from the power supply.

• Remove food from the appliance and put it in a very cool

place or a thermally insulated bag.

• Leave the appliance door open.

• Remove the internal defrost water drain plug (depending

on model) (Fig. 8).

• Remove the external defrost water drain plug (depending

on model) and reposition it as shown in Fig. 8.

• Use the separator (depending on model) inside the

product as a recipient for any remaining water, (D) as

shown in Fig. 8. If there is no separator, use a shallow

container.

• Defrosting can be sped up by using a spatula to detach

the frost from the appliance walls.

• Remove the frost from the bottom of the appliance.

• In order to avoid permanent damage to the

appliance interior, do not use pointed or sharp

metal instruments to remove the ice.

• Do not use abrasive products or heat up the interior

articially.

• Dry the inside of the appliance thoroughly.

• Ret the plug after defrosting.

CHANGING THE LID LIGHT BULB (if provided)

• Disconnect the appliance from the mains power supply.

• Remove the diuser by following the sequence of steps

shown in the gure.

• Unscrew the light bulb and replace it with an identical

bulb of the same wattage and voltage.

• Ret the diuser and plug in the appliance.

TROUBLESHOOTING GUIDE

1. The red LED ashes.

• Is there a power failure?

• Is a defrosting operation in progress?

• Has fresh food recently been introduced?

• Is the appliance lid properly closed?

• Is the appliance placed near a heat source?

• Are the ventilation grille and condenser clean?

2. All LEDs ash at the same time.

• Contact the After-Sales Service.

3. The appliance is too noisy.

• Is the appliance perfectly horizontal?

• Is the appliance in contact with other furniture or

objects that may cause vibrations?

• Has the packaging been removed from under the

appliance?

Note: Gurgling noises from the refrigerating circuit after the

compressor cuts out are perfectly normal.

4. All LEDs are o and the product is not working.

• Is there a power failure?

• Is the plug properly inserted in the socket?

• Is the electric cable intact?

5. All LEDs are o and the product is working.

• Contact the After-Sales Service.

6. The compressor runs continuously.

• Have hot foods been put in the appliance?

• Has the appliance lid been left open for a long time?

• Is the appliance placed in a very warm room or near

heat sources?
