DAILY USE

1. LOADING LAUNDRY.

• Prepare the laundry, following the

recommendations given in the section “HINTS AND

TIPS”. - Open the door and load the laundry into the

drum, without exceeding the maximum load capacities

indicated in the Programme Chart.

• Close the door, pressing until the latch

audibly locks, and check that there is no

laundry trapped between the door glass

and the rubber seal.

2. OPEN THE WATER TAP

Check that the Washer dryer is connected correctly

to the water mains. Open the water tap.

3. SWITCHING ON THE Washer dryer MACHINE.

Press button ; the lamp ashes slowly.

4. SELECTING A PROGRAMME AND CUSTOMISING A CYCLE.

The following functions are possible with this appliance:

• Wash only

• Wash and dry

• Dry only

Wash only

Select the required programme with the PROGRAMME

selector dial. The display will show the name and duration of

the cycle. The Washer dryer machine automatically displays

the maximum temperature and spin speed settings possible

for the selected programme. Adjust the temperature and/or

spin speed settings if needed with the relative buttons.

• Press button to cycle through progressively lower

temperature settings until cold wash is set (“- -“) shown on

display.

• Press button to cycle through progressively lower spin

speed settings until the spin cycle is turned o (“- -“ shown

on display).

Pressing the button again sets the highest possible setting.

Select the required options (if necessary).

• Press the button to select the option; the respective button

lamp illuminates.

• Press the button again to cancel the option; the lamp

extinguishes.

! If the selected option is not compatible with the

programme set, an error warning tone sounds and the

wording “No Selection” is shown on the display. The option is

not selected.

Wash and dry

To wash and dry a load with no interruption between the

wash and dry cycles, make sure that the load does not

exceed the maximum permissible drying load for the

selected programme (see the column “Max. load for drying

cycle” in the Programme chart).

1. Follow the instructions given in the paragraph “Wash Only”

to select and, if necessary, customise the required

programme.

2. Press to select the required drying mode. Two drying

modes are available: automatic or timer.

- Automatic drying with selectable levels:

In automatic drying mode, the Washer dryer machine dries

the laundry until the set level of dryness is reached. Pressing

button once automatically selects the highest drying level

available for the selected programme. Press the button again

to reduce the drying level.

The following levels are available:

Cupboard extra dry : suitable for garments which need

to be dried completely, such as sponges and bathrobes.

Cupboard dry : laundry is completely dry and ready to be

put away in the wardrobe without ironing.

Hanger dry : laundry is left slightly damp to minimise

creasing. Garments must be hung to air dry completely.

Iron dry : garments are left reasonably damp to make

ironing easier.

- Timer drying mode:

Press button repeatedly to set timer drying mode. After

cycling through all the automatic drying levels, continue

pressing button until the desired time is displayed.

Values from 180 to 30 minutes are settable.

To wash a load of laundry larger than the maximum

permissible load for drying (see the column “Max. load

for drying cycle” in the Programme chart), remove a few

garments once the washing cycle has nished before

starting the drying cycle. Proceed as follows:

1. Follow the instructions given in the paragraph “Wash Only” to

select and, if necessary, customise the required programme.

2. Do not include a drying cycle.

3. Once the washing cycle is nished, open the door and

remove a few garments to reduce the load. Now follow the

instructions for “Dry only”.

N.B.: always allow a cooling down period after drying before

opening the door.

When using the two preset cycles “Wash & Dry 45’” and “Wash

& Dry 90’”, it is not necessary to select and start a drying cycle.

Dry only

This function is used to simply dry a wet load washed

previously in the Washer dryer or by hand.

1. Select a suitable programme for the laundry you want to dry

(e.g. select cotton to dry wet cotton laundry).

2. Press button to dry without a wash cycle.

3. Press to select the required drying mode. Two drying modes

are available: automatic drying by levels or drying by time.

- Automatic drying with selectable levels:

In automatic drying mode, the Washer dryer machine dries

the laundry until the set level of dryness is reached. Pressing

button once automatically selects the highest drying

level available for the selected programme. Press the button

again to reduce the drying level.

The following levels are available:

Cupboard extra dry : suitable for garments which need

to be dried completely, such as sponges and bathrobes.

Cupboard dry : laundry is completely dry and ready to be

put away in the wardrobe without ironing.

Hanger dry : laundry is left slightly damp to minimise

creasing. Garments must be hung to air dry completely.

Iron dry : garments are left reasonably damp to make

ironing easier.
