Bruksanvisning

5019 312 11080

Programme

Temperature

(°C)

Load

(kg)

Water

(l)

Energy

(kWh)

Approx. Programme Duration (hrs : min)

without “Rapid” with “Rapid”

Cotton / Antibacterial 95 6.0 53* 1.91 2:05 –

Cotton ** 60 6.0 48 1.02 4:00 2:30

Cotton ** 60 3.0 35 0.76 2:10 ***

Cotton 40 6.0 48 0.65 2:50 2:00

Cotton ** 40 3.0 35 0.57 2:00 ***

Synthetics 60 3.0 50* 0.90 2:05 1:14

Synthetics 40 3.0 40 0.50 1:50 0:59

Delicates 40 1.5 50 0.55 0:45 –

Daily load 40 3.0 40 0.45 1:00 –

Speed 15' 30 3.0 30 0.15 0:15 –

Wool 40 1.0 55 0.55 0:45 –

Handwash 40 1.0 40 0.55 0:35 –

Lingerie 30 1.0 40 0.40 0:31 –

1. Load the machine, close the drum doors and check

that they are properly locked.

2. Add detergent and eventual additives as described on

the front page and in your Instructions for use.

3. Close the lid.

4. Turn the programme selector to the desired

programme and temperature. The lamp next to the

“Start(Pause)” button flashes.

CONSUMPTION DATA

PREPARATION OF THE WASH CYCLE

“DOOR OPEN” INDICATION

Before starting and after end of a programme, the lamp

lights to show the the lid can be opened. As long as a

wash programme is running, the lid remains locked and

must on no account be forced open. In case you have

an urgent need to open it during a running programme,

refer to “Cancel (Reset) a running programme before

the end”.

“Rapid” button

• Enables quicker washing by shortening the

programme duration.

• Recommendable for small loads or only lightly soiled

laundry.

“Intensive rinse” button

• The amount of water is increased to ensure a more

intensive rinse.

• This option is particularly suitable for areas with very

soft water, washing baby linen and people with skin

allergies.

“Rinse hold” button

• The laundry remains in the last rinse water without

progressing to the final spin cycle to avoid creasing

and prevent colours from changing.

• This option is particularly recommended for the

“Synthetics”, “Daily load” and “Delicates”

programmes.

• It is useful if you want to postpone spinning to a later

time, or if you want to drain out only.

• If you select “Rinse hold”, do not leave items to

soak for too long.

• As soon as the appliance stops in the rinse hold, the

“Rinse hold” lamp of the sequence indicator lights up

and the lamp next to the “Start(Pause)” button flashes.

Terminate the “Rinse hold” option:

• Press the “Start(Pause)” button; the programme

will terminate automatically with the final spin cycle

for the present wash programme.

Whirlpool is a registered trademark of Whirlpool USA.

PROGRAMME START

Open the tap and press the “Start(Pause)” button.

The indication lamp next to the “Start(Pause)” button

lights up. The programme sequence indicator shows the

current programme phase, running from left to right

through Wash, Rinse, Spin/Drain. When the programme

phrase is finised, the corresponding indication goes out.

• Note: If there is a power interruption or if the

appliance is disconnected during the cycle, the

programme will run again from the point where it

was interrupted.

PROGRAMME END

• All the lights of the programme sequence indicator

are off, and the “Door open” indication lights up.

1. Turn the programme selector to the “Off/O”

position.

2. Close the water tap.

3. Open lid and drum and unload the machine.

4. Leave the lid open for some time to allow the

interior of the machine to dry.

CHANGE PROGRAMME AND/OR OPTIONS

AFTER PROGRAMME START

1. Press the “Start(Pause)” button to pause the

programme. The light flashes.

2. Select the new programme, any options and another

spin speed if you want.

3. Press the “Start(Pause)” button again. The new

programme continues at the same position where

the previous programme was interrupted. Do not

add detergent for this programme.

CANCEL (RESET) A RUNNING PROGRAMME

BEFORE THE END

The “Reset” button cancels a programme before the

end. Press the “Reset” button for at least 3 seconds.

Any existing water is drained out before the door can be

opened.

SELECT THE DESIRED OPTION(S)

Selecting or deselecting an option can be done at

any time during the programme. The option will be

applied as long as the corresponding programme

phase has not been executed yet.

“Cold wash” button

• Water is heated only up to 20°C.

• Suitable for delicate laundry items with wash

temperature recommendation of max. 30°C on the

care label.

• Selectable only on the lowest temperature

step of each programme.

“Prewash” button

• Only for heavily soiled loads (for example sand,

granular dirt) . Increases the cycle time by

approximately 20 min.

Consumption values were measured in normalized conditions in compliance with standard IEC/EN 60 456. Consumption data in the

home may vary with respect to the values in the table in relation to the water supply pressure and temperature, the load and the type

of wash. Water and energy consumption refer to the default setting of the programmes; selecting special options or modifying spin

speed or temperature will change the consumption data.

The programme duration may differ from the values indicated above as it depends on the operation conditions applicable at that

time (see also “Troubleshooting Guide” in your Instructions for Use).

* To reduce the water temperature, some cold water is added at the end of the main wash cycle, before the pump drains the water out.

** Reference programmes for Energy Label.

*** Automatic adaption of programme duration after detection of wash load.

• If you do not wish to spin the clothes, turn the

programme selector knob to the “Drain”

programme and press the “Start(Pause)” button.

“Variable spin” button

• Every programme has a predefined spin speed.

• Press the button to set another spin speed.

• If spin speed “0” is selected, the final spinning is

cancelled but intermediate spin peaks remain during

the rinse. The water is drained out only.

FAILURE INDICATIONS

In a case of any failures of irregularities, consult the

“Troubelshooting Guide” in Instruction for Use.

“Service”

Lighting up of the “Service” indication can be caused by a

fault in an electrical component.

“Water tap closed”

The washing machine has no or insufficient water supply;

the water tap might be closed or the water inlet hose

kinked.

“Clean pump”

Waste water is not pumped out. The drain hose may be

kinked or the filter must be cleaned (see “Cleaning the

filter” in your Instructions for Use).
