DAILY USE

1. SELECT A FUNCTION

Press to switch on the oven: the display will show

the last running main function or the main menu.

The functions can be selected by pressing the icon for

one of the main functions or by scrolling through a

menu: To select an item from a menu (the display will

show the first available item), press

or to select

the desired one, then press

to confirm.

2. SET THE FUNCTION

After having selected the function you require, you

can change its settings. The display will show the

settings that can be changed in sequence. Pressing

allows you to change the previous setting again.

TEMPERATURE / GRILL LEVEL / STEAM LEVEL

TEMPERATURE

When the value flashes on the display, press or to

change it, then press

to confirm and continue with

the settings that follow (if possible).

In the same way, it is possible to set the grill level:

There are three defined power levels for grilling: 3

(high), 2 (mid), 1 (low).

In “Forced Air + Steam” function, you can select the

amount of steam from the following values: STEAM 1,

STEAM 2.

Please note: Once the function has been activated, the

temperature/grill level can be changed using

or .

DURATION

DURATION

When the icon flashes on the display, press or

to set the cooking time you require and then press

to confirm. You do not have to set the cooking time

if you want to manage cooking manually (untimed):

Press

or to confirm and start the function. By

selecting this mode, you cannot program a delayed

start.

Please note: You can adjust the cooking time that has been

set during cooking by pressing

: press or to amend

it and then press

to conrm.

END TIME START DELAY

In many functions, once you have set a cooking time

you can delay starting the function by programming

its end time. The display shows the end time while

the

icon flashes.

END TIME

Press or to set the time you want cooking to end,

then press to confirm and activate the function.

Place the food in the oven and close the door: The

function will start automatically after the period of

time that has been calculated in order for cooking to

finish at the time you have set.

Please note: Programming a delayed cooking start time will

disable the oven preheating phase: The oven will reach the

temperature you require gradually, meaning that cooking

times will be slightly longer than those listed in the cooking

table. During the waiting time, you can press

or to

amend the programmed end time or press

to change

other settings. By pressing

, in order to visualize

information, it is possible to switch between end time and

duration.

. 6

th

SENSE

These functions automatically select the best cooking

mode, temperature and duration to cook, roast or

bake all the dishes available.

When required, simply indicate the characteristic of

food to obtain an optimal result.

WEIGHT / HEIGHT / PIZZA ROUNDTRAYLAYERS

KILOGRAMS

To set the function correctly, follow the indications on

the display, when prompted, and press

or to set

the required value then press

to confirm.

DONENESS / BROWNING

In some 6th Sense functions it is possible to adjust

the doneness level.

DONENESS

When prompted, press or to select the desired

level between rare (-1) and well done (+1). Press

or

to confirm and start the function.

In the same way, where allowed, in some 6th Sense

functions, it’s possible to adjust the browning level

between low (-1) and high (1).

. COOKING WITH STEAM

By selecting the “Forced Air + Steam” or one of the

several 6

th

Sense dedicated recipes it is possible cook

any kind of food thanks to the use of the steam.

Steam spreads more quickly and more evenly

through food compared to just the hot air typical of

Conventional Functions: this reduce cooking times,

locking in food’s precious nutrients and ensuring you

obtain excellent, truly delicious results with all your

recipes. Through the complete duration of the steam

cooking the door must be kept closed.

To proceed with steam cooking, it will be necessary

to provide water to the boiler located inside the oven

using the extractable drawer on the control panel.
