Bruksanvisning Whirlpool AKZ9S 8270 NB Ugn

Bruksanvisning

FIRST TIME USE

1. SELECT THE LANGUAGE

You will need to set the language and the time

when you switch on the appliance for the first time:

“English” will show on the display.

English

Press or to scroll through the list of available

languages and select the one you require.

Press

to confirm your selection.

Please note: The language can subsequently be changed

by selecting “LANGUAGE” in “SETTINGS” menu, available by

pressing

.

2. SET THE POWER CONSUMPTION

The oven is programmed to consume a level of

electrical power that is compatible with a domestic

network that has a rating of more than 3 kW (16): If

your household uses a lower power, you will need to

decrease this value (13).

POWER

Press or to select 16 “High” or 13 “Low” and press

to confirm.

3. SET THE TIME

After selecting the power, you will need to set the

current time: The two digits for the hour will flash on

the display.

CLOCK

Press or to set the current hour and press : The

two digits for the minutes will flash on the display.

Press

or to set the minutes and press to

confirm.

Please note: You may need to set the time again following

lengthy power outages. Select “CLOCK” in “SETTINGS”

menu, available by pressing

.

. SET THE WATER HARDNESS LEVEL

In order to allow the oven to work eciently, and

to guarantee that it regularly prompts the user to

perform Descale cycle when needed, it is important

to set the correct water hardness level. To set it, switch

on the oven by pressing

, press Settings and

use navigation buttons

and to select “WATER

HARDNESS”. Press

to conrm. Use navigation

buttons

and to select the correct level for the

water of your area, based on the following table:

WATER HARDNESS LEVELS TABLE

Level

°dH

German

degrees

°fH

French

degrees

°Clark

English

degrees

1 Very soft 0-6 0-10 0-7

2 Soft 7-11 11-20 8-14

3 Mid 12-16 21-29 15-20

4 Hard 17-34 30-60 21-42

5 Very hard 35-50 61-90 43-62

Press to confirm.

For Water Hardness level, “Hard” is preset.

5. HEAT THE OVEN

A new oven may release odours that have been left

behind during manufacturing: this is completely

normal.

Before starting to cook food, we therefore

recommend heating the oven with it empty in

order to remove any possible odours. Remove any

protective cardboard or transparent film from the

oven and remove any accessories from inside it. Heat

the oven to 200 °C for around one hour, ideally using

a function with air circulation (e.g. “Forced Air” or

“Convection Bake”).

Please note: It is advisable to air the room after using the

appliance for the rst time.

• SMART CLEAN

The action of the steam released during this

special low-temperature cleaning cycle allows

dirt and food residues to be removed with ease.

Pour 200 ml of drinking water on the bottom of

the oven and only activate the function when the

oven is cold.

SETTINGS

For adjusting the oven settings.

When “ECO” mode is active the brightness of the display

will be reduced to save energy and lamp switches o after

1 minute. It will be reactivated automatically whenever any

of the buttons are pressed.When “DEMO” is “On” all

commands are active and menus available but the oven

doesn’t heat up. To deactivate this mode, access “DEMO”

from “SETTINGS” menu and select “O”.

By selecting “FACTORY RESET”, the product switches o and

then it returns to rst switch on. All settings will be deleted.

FAVORITES

For retrieving the list of 10 favorite functions.
