Bruksanvisning

INSTRUCTIONS FOR USE

GB

1.

Lid handle.

2.

Lock.

3.

Seal.

4.

Divider.

5.

Defrost water drain plug.

6.

Control panel.

7.

Side motor cooling grille.

8.

Upper edge.

9.

Condenser (located at the rear)

INSTALLATION

•

Please refer to the chapter “BEFORE USING THE

APPLIANCE”.

•

Unpack the appliance.

•

Remove the 4 protection pieces inserted between lid

and appliance.

•

Warning: two of the four protection pieces must be

fitted in the seat of the condenser plastic supports,

located at the rear of the product.

This is necessary to ensure the correct distance from

the wall.

•

Ensure that the defrosting water drainage plug (if provided) is

correctly positioned

(5)

.

•

For best operation of the appliance and in order to avoid

damage when the lid is opened, leave a space of at least

7 cm from the rear wall and 7 cm at the sides.

•

Fit the accessories (if provided).

Switching on the appliance

•

The appliance is factory set for optimum operation at a

temperature of -18°C.

•

Plug in the appliance.

•

The green LED lights up (if provided).

•

Also the red LED (if provided) will switch on because the

temperature inside the appliance is not yet sufficiently low for

food storage. The red LED will normally switch off within the

first six hours after the appliance is switched on.

•

After connecting the appliance to the mains supply

and when the optimal temperature has been reached

(this phase takes about 1 hour during which the lid

will not open), ensure that the fast freeze button is

not pressed (the yellow LED, if provided, is off)

•

Place food inside the product only when the red LED

(if provided) has switched off.

•

Thanks to the efficient lid seal, the appliance lid will not

re-open easily immediately after closing.

Wait a few minutes before re-opening the lid of the

appliance.

Te m p e r a t u r e A d j u s t m e n t

Use the thermostat to select the ideal storage temperature.

To adjust the internal temperature, proceed as follows:

•

Turn the thermostat knob



to 1 for a storage temperature that

is less cold.

•

Turn the thermostat knob to 6 / for a colder storage

temperature.

•

When the appliance is only partially full, it is advisable to set

the thermostat to lower positions (towards “E”, if indicated

on the thermostat scale).

Climatic Class Amb. T. (°C) Amb. T. (°F)

SN From 10 to 32 From 50 to 90

N From 16 to 32 From 61 to 90

ST From 18 to 38 From 64 to 100

T From 18 to 43 From 64 to 110

1.

Temperature

adjustment thermostat.

2.

Red LED (if provided)

: Indicates that the appliance

temperature is not sufficiently low.

3.

Green LED (if provided)

:

indicates that the appliance

is on.

4.

Yellow/orange illuminated button

(if provided)

:

activates/deactivates the fast freeze function. It lights up

when the fast freeze function is active.

The exact configuration of the controls may vary

according to the model.

BEFORE USING THE APPLIANCE

Your new appliance is designed exclusively for domestic use

and for storing frozen food, freezing fresh food and making

ice cubes.

Regulations require that the appliance is earthed.

The manufacturer declines all liability for injury to

persons or animals and for damage to property

resulting from failure to observe the above procedures

and reminders.

1.

After unpacking, make sure that the appliance is

undamaged and that the lid closes perfectly tight.

Any damage must be reported to your dealer within

24 hours after delivery of the appliance.

2.

Wait at least two hours before switching the appliance

on in order to ensure the refrigerant circuit is fully

efficient.

3.

Installation of the appliance and electrical connections

must be carried out by a qualified electrician,

in accordance with the manufacturer's instructions and

local safety regulations.

4.

Clean the inside of the appliance before using it.

•

Before connecting the appliance to the mains supply,

ensure that the voltage corresponds to that given on the

rating plate located on the rear of the appliance.

•

Electrical connections must be made in accordance

with local regulations.

FREEZING FOOD

Preparation of fresh food for freezing

•

Before freezing, wrap and seal fresh food in: aluminium

foil, cling film, air and water-tight plastic bags, polyethylene

containers with lids, provided they are suitable for freezing

foods.

•

Food must be fresh, mature and of prime quality in order

to obtain high quality frozen food.

•

Fresh vegetables and fruit should preferably be frozen as

soon as they are picked to maintain the full original

nutritional value, consistency, colour and flavour.

•

Always leave hot food to cool before placing in the

appliance.

Freezing fresh food

•

Place foods to be frozen in direct

contact with the walls of

appliance:

A) - foods to be frozen,

B) - foods already frozen.

•

Avoid placing foods to be frozen

in direct contact with food

already frozen.

•

For best and fastest freezing,

foods should be split into small

portions; this will also be useful

when the frozen items are to

be used.

1.

At least 24 hours before storing fresh food in the

appliance, press the fast freeze button. For appliances

without this button, turn the thermostat to .

2.

Place the food to be frozen and keep the lid of the appliance

closed for 24 hours. At the end of this period, switch off the

fast freeze button (if provided).

A

B

FOOD STORAGE

Refer to the table on the appliance

Classification of frozen foods

Put the frozen products

into the appliance and

classify them; The

storage date should be

indicated on the packs,

to allow use within

expiry dates.

Advice for storing

frozen food

When purchasing

frozen food products:

•

Make sure that the package is intact (frozen food in

damaged packaging may have deteriorated). If the package

is swollen or has damp patches, it may not have been

stored under optimal conditions and defrosting may have

already begun.

•

When shopping, leave frozen food purchases until last and

transport the products in a thermally insulated cool bag.

•

Once at home, place the frozen foods immediately in the

appliance.

•

Avoid, or reduce temperature variations to the minimum.

Respect the best-before date on the package.

•

Always observe the storage information on the package.

Note:

Eat fully or partially defrosted foods immediately.

Do not refreeze unless the food is cooked after it has

thawed. Once cooked, the thawed food can be

refrozen.

If there is a long power failure:

•

Do not open the appliance lid except to place ice

packs (if provided) over the frozen foods on the right

and left of the appliance. This will slow down the rise

in temperature.

MONTHS

FOOD
