Bruksanvisning

Press

1

: Move the louver in

the desired vertical direction.

Press

2

: Swing the air

automatically and press again to

stop.

For horizontal direction, adjust

3

manually.

Note:

● Do not move the louver manually by others.

● The louver may automation positioning by some operation mode.

.

j

TIMER (White)

k

OPERATION (White)

PRECAUTIONS FOR SAFETY

DANGER

Do not install, repair, open or remove the cover. It may

expose you to dangerous voltages. Ask the dealer or the

specialist to do this.

●

Turning off the power supply will not prevent potential electric

shock.

●

The appliance shall be installed in accordance with national

wiring regulation.

●

Means for disconnection from the supply having a contact

separation of at least 3 mm in all poles must be incorporated

in the fixed wiring.

WARNING

Do not expose your body directly to cool air for a long time.

●

Do not insert your fnger or any article into the air inlet/outlet.

●

When an abnormality (burning smell, etc.) occurs, stop the

air conditioner and disconnect the power supply or turn off

the breaker.

●

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of

the appliance by a person responsible for their safety.

●

Children should be supervised to ensure that they do not play

with the appliance.

●

Do not use any refrigerant different from the one specifed

(R410A) for complement or replacement. Otherwise,

abnormally high pressure may be generated in the

refrigeration cycle, which may result in a failure or explosion

of the product or an injury to your body.

CAUTION

Do not wash the unit with water. It may cause an electric

shock.

●

Do not use this air conditioner for other purposes such as

preserving food, breeding animal, etc.

●

Do not step or put anything on the indoor/outdoor unit. It may

cause an injury or damage the unit.

●

Do not touch aluminium fn because it may cause an injury.

●

Before cleaning the unit, turn off the main switch or the circuit

breaker.

●

When the unit won’t be used for a long time, turn off the main

switch or the circuit breaker.

●

It is recommended that maintenance be performed by a

specialist when the unit has been operated for a long time.

●

The manufacturer shall not assume any liability for the

damage caused by not observing the description of this

manual.

●

●

●

Preparing Filters

1. Open the air inlet grille and remove the air f lters.

2. Attach the f lters. (see detail in the accessory sheet).

Loading Batteries (when use wireless operation.)

1. Remove the slide cover.

2. Insert 2 new batteries (AAA type)

following the (+) and (–) positions.

Clock Setup

1. Push

by tip of the pencil.

If timer indication is f ashing, go to the next step 2.

2. Press

or : adjust the time.

3. Press

: Set the time.

Remote Control Reset

Push by tip of the pencil or

1. Remove the batteries.

2. Press

.

3. Insert the batteries.

j Infrared signal emitter

k Start/Stop button

l Mode select button (MODE)

m Temperature button (TEMP)

n Fan speed button (FAN)

o Swing louver button (SWING)

p Set louver button (FIX)

q On timer button (ON)

r Off timer button (OFF)

s Setup button (SET)

Clear button (CLR)

Memory and Preset button (PRESET)

One-Touch button (ONE-TOUCH)

High power button (Hi-POWER)

Power selection button (POWER-SEL)

Quiet button (QUIET)

Comfort sleep button (COMFORT SLEEP)

Filter reset button (FILTER)

Set clock button (CLOCK)

Check button (CHECK)

Reset button (RESET)

SWING

FAN

FIX

QUIET

Hi POWER

ONE-TOUCH

COMFORT

SLEEP

POWER-SEL

q

j

k

l

p

Note:

• The provided Remote Controller is a wireless type, which also can be used as a

wire. Please see “How to Connect The Remote Controller for Wired Operation”

located in installation instruction, in case of wired control is required.

• In wire operation, remote controller will return to initial condition (PRESET,

TIMER and CLOCK will return to initial condition) when user shutdown power

supply of Air conditioner.

12

13

15

17

20

19

21

18

11

16

14

m

n

s

o

r

21

18

11

16

14

12

13

15

17

20

19

Press the “ONE-TOUCH” button for fully automated operation that is

customized to the typical consumer preferences in your region of the world.

The customized settings control temperature air f ow strength, air f ow

direction and other settings to provide you alternate contact with

“ONE-TOUCH” of the button. If you prefer other settings you can select

from the many other operating functions of your Toshiba unit.

Press

ONE-TOUCH

: Start the operation.

To automatically select cooling or fan only operation

1. Press

MODE

: Select A.

2. Press

: Set the desired temperature.

3. Press

FAN

: Select AUTO, LOW , LOW+ , MED , MED+ ,

or HIGH

.

1. Press

MODE

: Select Cool or Fan only .

2. Press : Set the desired temperature.

Cooling: Min. 17°C, Fan Only: No temperature indication

3. Press

FAN

: Select AUTO, LOW , LOW+ , MED , MED+ ,

or HIGH .

COOLING / FAN ONLY OPERATION

7

AUTOMATIC OPERATION

6

ONE-TOUCH

5

PREPARATION BEFORE USE

2

INDOOR UNIT DISPLAY

1

REMOTE CONTROL

4

AIRFLOW DIRECTION

3
