Bruksanvisning Timex TW2T30200VQ Allied Armbandsur

Bruksanvisning

3

ENGLISH 990-095926-05

ELAPSED TIME RING

If your watch is equipped with a rotatable outer ring on the face, with

numbers corresponding to minutes, you can use this Elapsed Time Ring to

time an activity from the start, or to mark the ending time for the duration of

an activity.

TO TIME AN ACTIVITY FROM THE START:

Set the Start/Stop triangle at the time (hour or minute) when you start the

activity (As shown on the left in the illustration shown below). At completion,

you can see how long the activity took.

TO MEASURE THE TIME REMAINING:

Set the triangle to the hour or minute position when you wish to complete the

activity, and check the watch periodically for progress towards that goal.

In the illustration shown on the previous page on the right you can stop when

the minute hand reaches the 20 minutes past the hour position.

TACHYMETER RING

The tachymeter feature can be used to measure speed in miles per hour

(MPH), nautical miles per hour (knots) or kilometers per hour (KPH) using the

sweep second hand and the scale on the wall above the watch face. You

need to know the actual distance you are covering in miles or km.

Start the chronograph with the second hand at zero (the twelve o’clock

position). Within the rst minute, the second hand will point to the rate for a

one-mile (or one kilometer) course: if it takes 45 seconds, the hand will point

to 80 at that position – 80 MPH or 80 KPH.

If within the rst minute, a distance greater than one mile or kilometer is

covered, multiply the tachymeter number by the distance to get the actual

rate: if you went 1.2 miles in 45 seconds, multiply the 80 by 1.2 – 96 MPH.

COMPASS RING

If your watch is equipped with a movable ring around the dial marked at

the letters “N”, “E”, “W”, “S” (for the four compass directions) or compass

degrees, you can use this feature to nd an approximate compass

directional reading.

1. Lay the watch on a at surface, or hold it so that the face is parallel to the

ground.

2. Locate the sun and point the hour hand at the sun.

3. In the A.M., rotate the ring until the “S” (south) marker is halfway between

the hour hand and 12:00 (after the hour hand or within the shortest

distance between the hour hand and 12:00).

4. In the P.M., rotate the ring until “S” is before the hour hand and halfway

between the hour hand and 12:00.

12

1

2

3

4

5

6

7

8

9

10

11

N

S

W

E

HOW TO ADJUST BRACELET

(Variations of the following bracelet sections apply to all watch models).

SLIDING CLASP BRACELET

1. Open locking plate.

2. Move clasp to desired bracelet length.

3. Exert pressure while holding locking plate and slide clasp back and forth

until it engages in grooves on underside of bracelet.

4. Press locking plate down until it snaps closed. Clasp can be damaged if

excessive force is used.

FOLDOVER CLASP BRACELET

1. Find spring bar that connects bracelet to clasp.

2. Using a pointed tool, push in spring bar and gently twist bracelet to

disengage.

3. Determine wrist size, then insert spring bar in correct bottom hole.

4. Push down on spring bar, align with top hole and release to lock in place.

FIG. 1 FIG. 2 FIG. 3

BRACELET LINK REMOVAL

REMOVING LINKS:

1. Place bracelet upright and insert pointed tool in opening of link.

2. Push pin forcefully in direction of arrow until link is detached

(pins are designed to be difcult to remove).

3. Repeat until desired number of links are removed.

RE-ASSEMBLY:

1. Rejoin bracelet parts.

2. Push pin back into link in opposite direction of arrow.

3. Press pin down securely into bracelet until it is ush.

BATTERY

Timex strongly recommends that a retailer or jeweler replace battery. Battery

type is on watch back. If present, push/short internal reset switch after

replacing battery. Battery life estimates are based on certain assumptions

regarding usage; battery life may vary depending on actual usage.

DO NOT DISPOSE OF BATTERY IN FIRE. DO NOT RECHARGE. KEEP

LOOSE BATTERIES AWAY FROM CHILDREN.

TIMEX INTERNATIONAL WARRANTY

http://www.timex.com/productWarranty.html

©2019 Timex Group USA, Inc. TIMEX, INDIGLO and QUICKDATE are

registered trademarks of Timex Group B.V. and its subsidiaries.
