PREPARATION FOR USE
Unpacking and Setup
* Carefully remove the unit from the display carton and remove all packing material from the unit itself.
* Remove any descriptive labels that may be found on either the front or top cabinet of the unit. Do not
remove any labels located on either the back or button cabinet of the unit.
* The detachable AC power cord is packed in the carton separately from the unit. Make sure that the
AC power cord is not accidentally discarded with the carton or packing material.
* Press the CD Door OPEN Button to open the CD compartment door. There is a white card in the CD
compartment which is Intended to prevent the CD pickup from moving during shipment of the product.
Remove this card from the CD compartment before use.
Power Sources
This portable audio system is designed to operate on either 120V AC 60Hz house current or 12V DC,
using 8 D batteries (UM-1), not included. Attempting to operate this unit from any other power source
may cause damage to unit, which is not covered by your warranty.
AC Operation
Unwind the AC cord and extend it to its full length, insert the small end of the AC cord into the AC socket
on the back cabinet of the unit. Insert the other and of the AC cord into any convenient 120V AC 60Hz
household outlet .
,
,
SPECIFICATIONS
POWER SUPPLY
AC: 120V-60Hz
DC: 12V(UM-1x8)
RADIO FREQUENCY COVERAGE:
FM: 88-108 MHz
AM: 530-1710 kHz
GENERAL
Headphone: 3.5mm Stereo jack plug 8-32 ohm
Speakers: 8 ohm
CD PLAYER
Pick Up: 3-Beam. Semiconductor Laser
Encoding: 8 x Over sampling
D/A: 1 - Bit Dual D/A Converter
CASSETTE PLAYER
Tape: Standard normal bias
Recording System: DC bias
Erasing System: Magnetic erase
AC Plug
AC Outlet
-2-
-3-
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near
water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. Install in accordance with
the manufacturer´s instructions.
8. Do not install near any heat sources
such as radiators, heat registers, stoves, or
other apparatus (including amplifier) that
produce heat.
9. Do not defeat the
safety purpose of the
polarized or
grounding-type plug.
A polarized plug has two blades with one
wider than the other. A grounding type plug
has two blades and a third grounding prong.
The wide blade or the third prong are
provided for your safety. If the provided plug
does not fit into your outlet, consult an
electrician for replacement of the obsolete
outlet.
10.
Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11.
Only use attachments/accessories
specifier by the manufacturer.
12.
Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injur y from tip-over.
13.
Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14.
Refer all servicing to qualified service
Personnel. Ser vicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15.
Battery usage CAUTION – To
prevent battery leakage which may result in
bodily injury, property damage, or damage
to the unit:
Install all batteries correctly,+ and - as
marked on the unit.
Do not mix batteries ( old and new or
carbon and alkaline, etc.).
Remove batteries when the unit is not used
for a long time.
IMPORTANT SAFETY INSTRUCTION
AC Polarized
Plug
