Bruksanvisning Steren WR-810 UHF Mikrofon

Bruksanvisning

UHF CORDLESS MICROPHONE SET

WR-810 UHF

V0.3

1117m

Instruction manual

1. Place the reciver on a flat surface.

2. Insert the AC power connector to an electrical outlet and connect the adapter to the

receiver.

Microphones

1. Grill.

2. On, mute and off switch

3. Frequency indicator display

4. Battery compartment

5. Removable battery module

6. Rechargeable battery

Before using your new Steren´s product, please read this instruction manual to prevent

any damage.

Read this instruction manual to learn how to properly use the product.

Please, check the latest version on our page www.steren.com

“ The operation of this equipment is subject to the following two conditions: (1) it is

ro ecived siht )2( dna ecnerefretni lufmrah esuac ecived ro retupmoc siht taht elbissop

derisednu esuac yam taht ecnerefretni gnidulcni ,ecnerefretni yna tpecca tsu

m ecived

operation.”

CAUTION S

H IGHLIGHTS

• Do not use or store the equipment near wet places.

• Do not bump or drop the microphones.

• Clean only with a soft, dry cloth.

• emertxe ,erutsiom ro tsud ot desopxe era yeht fi senohporcim eht esu ton oD

temperatures or mechanical vibrations.

enohporcim hcaE .m 001 ot 06 neewteb egnar a sah tes enohporcim sseldroc sihT

includes a rechargeable battery that is charged in the base via USB, or if you require, you

can use two AAA batteries (not included).

The used frequency is UHF, offering best reception and avoids interferences from other

wireless devices. Each microphone has independent

volume control, status indicators, and

on/off switch. The receiver base has a display that shows the current frequency.

The USB ports delivers 9 V and are not compatible to recharge devices such as

smartphones or audio players.

• Wide response range

• Microphone with low battery indicator

• In-use, reception and transmission indicators

• Two antennas for better reception

• Volume control

• Modulation in frequency

• Balanced and unbalanced outputs

• 60 to 100 m range

Package content

• Two handheld microphones

• UHF receiver

C O NTRO L S

Receiver

Front panel

1. Power switch, power on/ off and charge.

2. USB ports for battery charging.

3. Antenna: Receive signals from the trans-

mitter microphone.

4. Independent Volume Control: Turn the

right knob to the right for increase the

volume, turn the left knob to the left for

decrease the volume.

gnidnopserroc ehT .rotacidni DEL FR .5

eht nehw sthgil DEL 2 ro 1 enohporcim

receiver receives the signal.

6. LED power indicator

Rear panel

7. Mix output

8. Balanced output

9. AC IN

10. AC / DC power converter

B A TTER Y RECHARG E B Y USB

1. Place the rechargeable battery to charge in the receiver base.

2. The LED charge indicator will light on.

3. Once the charge is complete, the LED charging indicator will turn off.

4. Remove the cover of the battery compartment and place the rechargeable battery in the

microphone USB port.

Do not exceed the charging time of the battery, to avoid damaging.

The USB ports delivers 9 V and are not compatible to recharge devices such as

smartphones or audio players.

B A TTER Y I NST ALLA T ION

1. Turn to open the battery compartment

cover.

elbavomer eht ni seirettab AA 2 tresnI .2

module and insert into the battery compartment.

3. Place the battery cover again.

I NSTRUCTION S

4. Press the power button. The power LED indicator will light on.

5. Turn on the microphones and adjust the volume level.

6. The LED of the corresponding microphone used channel RF1 or RF2 will light on.

SPECI F I C A T ION S

Microphone

Input: 3.7 V (lithium battery)

3 V

(2xAA)

Frequency response: 50 Hz – 20 kHz

Frequency stability: 0.005%

Sensitivity: -68 dB ± 3 dB

SNR: >100 dB

Receiver

Input: 12 V 2 A

Impedance: 600 Ω

AC/DC power converter

Input: 100 - 240 V~ 50 / 60 Hz 1A

Output: 12 V 2 A

Product: UHF cordless microphone set

Part number: WR-810UHF

Brand: Steren

WARRANTY

This Steren product is warranted under normal usage against defects in workmanship and materials to the original purchaser for

one year from the date of purchase.

CONDITIONS

1. This warranty card with all the required information, invoice, product box or package, and product, must be presented when

warranty service is required.

2. If the product is in the warranty time, the company will repair it free of charge.

3. The repairing time will not exceed 30 natural days, from the day the claim was received.

4. Steren sell parts, components, consumables and accessories to customer, as well as warranty service, at any of the addresses

mentioned later.

THIS WARRANTY IS VOID IN THE NEXT CASES:

If the product has been damaged by an accident, acts of God, mishandling, leaky batteries,failure to follow enclosed instructions,

improper repair by unauthorized personnel, improper safe keeping, among others.

a) The consumer can also claim the warranty service in the purchase establishment.

b) If you lose the warranty card, we can reissue it, if you show the invoice or purchase ticket.

RETAILER INFORMATION

Name of the retailer ___________________________________________________________________________________

Address ____________________________________________________________________________________________

Product __________________________________________________________________________

01 800 500 9000
