Bruksanvisning Sony WM-FX127 Walkman Kassettbandspelare

Bruksanvisning

3-810-698-16(1)

1Insert a cassette.

2Set the FM/AM/TAPE

(RADIO OFF) selector to

TAPE (RADIO OFF).

3Select NORM or CrO2/

METAL mode to match

the tape type.

4Press 9 PLAY.

Playing Cassettes

FX325FX323

FX325

TAPE

(RADIO OFF)

AMFM

PLAY

AVLS

NORM

LIMIT

2

pSTOP

MODE

DIR

FM/AM/

TAPE

(RADIO OFF)

VOLUME

NORM CrO

2/

METAL

0 )

9PLAY

Cassette holder

ON

OFF

M

A

X

8

6

4

2

M

I

N

M

A

X

8

6

4

2

M

I

N

HIGH

LOW

ON

OFF

Operating the Cassette Player

To wind the tape Press 0 or ).

To change sides* Set the DIR switch.

To play both sides once* Set MODE to Å.

To play both sides Set MODE to a.

repeatedly*

To adjust the volume

Turn the VOLUME control.

To stop Press p STOP.

* except for FX121/FX121V/FX127

Notes on playing cassettes

•Do not use cassettes longer than 90 minutes except for long

continuous playback.

•If the tape is playing but no sound comes out, the batteries

may be weak. Replace all dry batteries with new ones or

recharge all rechargeable batteries.

•If your Walkman has not been used for a long time, run the

Walkman for a few minutes before inserting a cassette.

•Do not wind the headphones cord around the Walkman.

The buttons may be kept pressed, causing unnecessary battery

usage.

•Do not open the cassette holder while the tape is running.

Using MEGA BASS (FX323/FX325)

Set the MEGA BASS switch to ON to produce deep and

powerful sound. Turn the HIGH and LOW controls to

get the desired tone (FX325).

When using MEGA BASS

If the AVLS switch is set to LIMIT, the MEGA BASS effect is

reduced.

Using DOLBY NR (FX325)

Set the DOLBY NR switch to ON to play Dolby NR

processed tapes.

ON

OFF

DOLBY NR

OWNER’S RECORD

The model number is located at the rear and the

serial number is located at the rear (FQ01)/inside the

cassette holder (other models).

Record the these numbers in the spaces provided below.

Refer to them whenever you call upon your Sony

dealer regarding this product.

Model No.

Serial No.

Featuring

AVLS (Automatic Volume Limiter

System)

The AVLS switch allows you to limit the maximum volume of

your Walkman personal stereo without degrading the sound

quality.

•When the AVLS switch is set to LIMIT (around 85 dB), the

volume will be kept at a moderate level without the

degradation of the sound quality, even if you attempt to turn

the volume up higher.

•When the AVLS switch is set to LIMIT, the playback sound

may be distorted or unstable according to the music (especially

the bass boosted part). If this happens, turn down the volume.

•When the AVLS switch is set to NORM, you will be able to

enjoy the full volume capability of your Walkman personal

stereo.

Radio Cassette Player

WM-

FX121/FX121V/FX127/FX321/

FX321V/FX323/FX325/FQ01

Operating Instructions

WALKMAN is a registered trademark of Sony Corporation.

Sony Corporation © 1996 Printed in Malaysia

For the customers in the U.S.A.

Getting Started

Using with Batteries

Insert two AA (R6) batteries in correct polarity.

AA (R6) x 2

DC IN 3V

Notes

•When you are not going to use your Walkman for a long time,

remove the batteries to prevent damage from battery leakage

and corrosion.

•When the sound becomes unstable or cannot be heard, replace

the old batteries with new ones.

•The battery life may shorten depending on the operation of the

unit.

Using External Power Sources

You can connect the following external power sources

through the DC IN 3 V jack located on the bottom. (When

you plug a cord into the DC IN 3 V jack, the internal

batteries are automatically bypassed.)

• House current using an AC-E30HG AC power adaptor

Notes

•Use only the recommended

AC-E30HG AC power adaptor (not

supplied). Do not use any other

AC power adaptor.

•Specifications for AC-E30HG varies for each area. Check your

local voltage and the shape of plug before purchasing.

Polarity of the plug

Using With a Rechargeable Battery

(FX127)

Before using, charge the rechargeable battery with the

supplied charger.

Charging time is about 4 hours.

After 4 hours, remove the batteries.

Open the battery

compartment lid

and insert the

rechargeable battery

after charging.

Notes

•The name plate indicating operating voltage, power consump-

tion, etc. is located on the bottom exterior of the charger.

•The battery may become warm during charging.

•Use only the rechargeable battery NC-AA (WM) with the

supplied battery charger.

•If the rechargeable battery is new or it has not been used for a

long time, it may not be charged completely. (The playing time

is shorter.)

•The rechargeable batteries can be charged about 300 times.

When using headphones/earphones

Wear the “L” marked side to the left ear and the “R”

marked side to the right ear.

NORM

CrO

2 /

METAL

Betyg

Mer om denna bruksanvisning

Vi förstår att det är trevligt att ha en pappersbruksanvisning för din Sony WM-FX127 Walkman Kassettbandspelare. Du kan alltid ladda ner bruksanvisningen från vår hemsida och skriva ut den själv. Om du vill ha en originalbruksanvisning rekommenderar vi att du kontaktar Sony. De kanske kan tillhandahålla en originalbruksanvisning. Letar du efter bruksanvisningen för din Sony WM-FX127 Walkman Kassettbandspelare på ett annat språk? Välj ditt föredragna språk på vår hemsida och sök efter modellnumret för att se om vi har det tillgängligt.
